Owner/Operator Manual
Ser # 990-55-117
MODEL 990
Custom Eliminator
Custom Eliminator

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 990 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Spudnik 990

Summary of Contents for Spudnik 990

  • Page 1 Owner/Operator Manual Ser # 990-55-117 MODEL 990 Custom Eliminator Custom Eliminator...
  • Page 2 Operating Manual Overview The purpose of this Spudnik Operating Manual is to make the user familiar with this machine and to assure the machine is used for what it has been designed to do. This Operating Manual contains important information on how to...
  • Page 3 Mission Statement Our mission is to consistently provide high quality, reliable, safe and well-designed products and services to meet and exceed the needs of our customers. Service Centers Phone: (208) 785-0480 E-Mail: spudnik@spudnik.com Web Site: www.spudnik.com...

  • Page 4: Table Of Contents

    Operators manual MODEL 990 Table of Contents Warranty Policy ..................4 Safety ......................5 General Safety Practices ................6 Hydraulics Safety Practices ...............7 Transporting Safety Practices ..............8 Operation Safety Practices ................9 Safety Labels .....................10 Maintenance ....................12 Machine Parts Breakdown ……….……………..……………………..14 Schematics ………..................57 Page 3...

  • Page 5: Warranty Policy

    30 days of noticing the defect and (d) make the product available to the dealer or service center within a reasonable period of time, transportation charges prepaid. The selling dealer has no authority to make any representation or promise on behalf of Spudnik, or to modify the terms or limitations of this warranty in any way.

  • Page 6: Safety

    When you see this symbol, be alert to the possibility of injury or death. You are responsible for the safe operation and maintenance of your Spudnik Eliminator. All operators and anyone doing work or maintenance on the Eliminator must be trained in the operation, maintenance procedures, and related SAFETY information contained in this manual.

  • Page 7: General Safety Practices

    Operators manual MODEL 990 SAFETY General Safety and Accident Prevention Regulations The primary responsibility for safe operation of the Spudnik Eliminator is with the owner/operator. OSHA (Occupational Safety and Health Administration) requires that all operator’s be OSHA (Occupational Safety and Health Administration) requires that all operator s be trained at the time of initial assignment, and annually thereafter by the employer, in the safe operation of the machine.

  • Page 8: Hydraulics Safety Practices

    Operators manual MODEL 990 SAFETY Specific Safety Instructions Risk of injury when hitching up or unhitching machines to and from the tractor. Never allow persons to stand between the tractor and the machine unless the towing vehicle is secured against rolling away by means of the parking brake and/or chocks.

  • Page 9: Transporting Safety Practices

    Operators manual MODEL 990 SAFETY Transporting Safety Practices Check to see if all bolts on tow tongue are in good condition, in place, and secure. Remove the pin from the towable gearbox wheel drive. Release hydraulic pressure to the elevator lift cylinder.

  • Page 10: Operation Safety Practices

    Operators manual MODEL 990 SAFETY Operating Safety Practices Eliminator should be operated on a flat secure surface. When using leveling jacks, make sure that the jacks are on secure ground. Do not lift the wheels off of the ground. Do not allow anyone to climb on or under the Eliminator while in operation.

  • Page 11: Safety Labels

    Operators manual MODEL 990 SAFETY Safety Labels  Keep Safety labels and signs clean and legible at all times, Keep Safety labels and signs clean and legible at all times,  Replace Safety labels and signs that are missing or have become illegible.
  • Page 12 Operators manual MODEL 990 MAINTENANCE The hydraulic system used to power auxiliary functions uses Dexron III ATF (automatic transmission fluid) for prime mover. Hydraulic reservoir fill level should be checked at start of each season, and filled as needed. Hydraulic oil reservoir has a 5-gallon capacity.

  • Page 13: Maintenance

    Operators manual MODEL 990 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS 1. Center any machine that feeds the Eliminator squarely to the elevator. This allows the potatoes to spread out evenly and provides better sizing and dirt elimination. 2.Adjust the elevator to the required height to eliminate drop.
  • Page 14 Operators manual MODEL 990 8761-ELEVATOR 990 84"x16'6" CHN ELEV 36MM NO SKID PAN Item Quantity Title Subject Item Quantity Title Subject Number Number ANGLE, CYL. STOP, 1/4"x1-1/2"x1-1/2"x12" 172608 SHFT,QK,1-3/4"x93"12,9,9,5 BLIND 3/8"KEY 050628 ASSY,BC,84"x11MMx36MM 2D1S CUSH 4Bx39'4" 352799 SPRCKT,CAST,10T 36MM 1-3/4"BORE 3/8"DKST 321629 BOLT,HINGE,36",BELT ELEV #550 5/8"...

  • Page 15: Machine Parts Breakdown

    Operators manual MODEL 990 8761-TIPOUT 990 84"ELEV DRV TIPOUT ELEC VAR SPD7.5HP Item Quantity Title Subject Number BOLT,HINGE,36",BELT ELEV #550 5/8" x 9" 181226 BRNG,PB,1-3/4" BORE VPS-128 231083 CHN,RLR,80 PITCH x 6.167 LNF 351275 GRBX,PAR,14:1,10HP,215TC D BROWN MDL580 571277 LABEL,CAUTION,MOVING,DRIVES,CAN CAUSE...
  • Page 16 Operators manual MODEL 990 8761-ELEV-RETURN 990 84"x21'-0" FULL RTRN CONV 9"FS ELEV Item Quantity Description Part # Number ARM,TORQUE,HYD,DRV,4 HOLE 1/2" x 12" 901495 BELT,FLAT,12" 1/32" x 1/32" 150# x 7.042 LNF 261000 BELT,FLAT,2-1/4",1/32" x 1/32" 150#x12.167LNF 261449 BELT,FLAT,2-1/4",1/32" x 1/32" 150#x9.167LNF 261449 BELT,FLAT,84"...
  • Page 17 Operators manual MODEL 990 8761-RLR-STR 990 96"RLL SCT RLR-STR SPUDNIK REAR HANG ITEM DESCRIPTION PART #: CPLG,HYD,90DEG,6801-6-8 (6MJ-8MB) 601323 CPLG,HYD,STR,6400-6-8 (6MJ-8MB) 601477 CYL,3.00"x8",TIE ROD,20.25",REPHASE 602628 CYL,3.25"x8",TIE ROD,20.25",REPHASE 602629 HINGE, RLR, DSCHRG-PIVOT, LH 194336 HINGE, RLR, DSCHRG-PIVOT, RH 194337 RLRSTR,96" 995 DSCHRG-PIVOT 132937 VALVE,ACCESORY,STD.LEVER M8x1.25x150mm...
  • Page 18 Operators manual MODEL 990 132937-PB RLRSTR,96" 995 DSCHRG-PIVOT Item Quantity Description Part # Item Quantity Description Part # Number Number ADJUSTER,ROLLERS,RST HARV-2005 173319 ROLLERSTAR FRAME 96'' 194335 ASSY,BRUSH,RST,96IN 133305 SHEET,LETDOWN,RST-SCR,96 173979 BAR,HOLD DOWN,RLR-STR TRANS. ROLLS 133025 SHEET,SS,16GA 030062 BOLT,HEX,HD,5/8"-11UNC x 2" GR 5...
  • Page 19 Operators manual MODEL 990 132937-PB RLRSTR,96" 995 DSCHRG-PIVOT Item Quantity Description Part # Item Quantity Description Part # Number Number ADJUSTER,ROLLERS,RST HARV-2005 173319 ROLLERSTAR FRAME 96'' 194335 ASSY,BRUSH,RST,96IN 133305 SHEET,LETDOWN,RST-SCR,96 173979 BAR,HOLD DOWN,RLR-STR TRANS. ROLLS 133025 SHEET,SS,16GA 030062 BOLT,HEX,HD,5/8"-11UNC x 2" GR 5...
  • Page 20 Operators manual MODEL 990 133305-PB ASSY,BRUSH,RST,96IN ITEM DESCRIPTION PART #: BELT,96" RLR-STR VINE BRUSH,2011 262035 BRACKET,BRUSH,RST,96IN 196495 Page 19...
  • Page 21 Operators manual MODEL 990 133025-PB BAR,HOLD DOWN,RLR-STR TRANS. ROLLS ITEM DESCRIPTION PART #: PLATE 174342 UHMW,1/4x2-1/2x14-1/2 981958 Page 20...
  • Page 22 Operators manual MODEL 990 132935-PB RLR, CLOD,96'', ROLLSTR, 995 Item Quantity Description Part # Number ARM,PIVOT,CLODROLLER,LH,6340-2006 193798 ARM,PIVOT,CLODROLLER,RH,6340-2006 193799 BOLT,HEX,HD,1/2"-13UNC x 2" GR 5 501089 BRNG,2BOLT,FLNG,1-7/16".ECC LOCK 231322 BRNG,SLEEVE,2" ODx1.75"x1.75LG 231262 COLLAR,SHAFT,SET,SCREW,5/8" 501900 SCRAPER,ROLLERSTAR,96'' 194339 SHAFT 050398 SIDE PANAL,CLOS RLLR,RST HARV-2005...
  • Page 23 Operators manual MODEL 990 133306-PB ROLLERSTAR DRIVE ASSY, 96" ITEM DESCRIPTION PART #: ITEM DESCRIPTION PART #: ANGLE,TENTION,M-SEP,6440-2007 173980 IDLER,60,PITCH,5/8" BORE 15 TOOTH 881079 ARM,TENSION,FRONT,RST,HARV-2005 192789 SHAFT,RLLRSTR,AIRHD 6200-2004 050071 ARM,TENSION,REAR,HARV-2005 192790 SPRCKT, H80BS18x1-1/4 BORE 5/16" KEYWAY 881145 BOLT,EYE,1/2"x8" w/NUT PLATED 502410 SPRCKT,H60BS13x1-7/16"...
  • Page 24 Operators manual MODEL 990 821904-PB SHFT,ELIM,96",ELM/ELM SPRDR-UNIT Item Quantity Description Part # Number COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 Page 23...
  • Page 25 Operators manual MODEL 990 821903-PB SHFT,ELIM,96",ELM/FNG-FULL SPRDR-UNIT Item Quantity Description Part # Number COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,FINGER,1-1/2"BORE 3" HUB 981287 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 Page 24...
  • Page 26 Operators manual MODEL 990 821902-PB SHFT,ELIM,96",ELM/FNG-HLF SPRDR-UNIT Item Quantity Description Part # Number COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,FINGER,1-1/2"BORE 3" HUB 981287 ROLL,RUBBER,FINGER,LH 1-1/2"BR 2-1/4"HUB 981289 ROLL,RUBBER,FINGER,RH 1-1/2"BR 2-1/4"HUB 981290 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 Page 25...
  • Page 27 Operators manual MODEL 990 821988-PB SHFT,ELIM,96",FINGER,HF SPRDR ROLL ITEM DESCRIPTION PART #: COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,FINGER,1-1/2"BORE 3" HUB 981287 ROLL,RUBBER,FINGER,LH 1-1/2"BR 2-1/4"HUB 981289 ROLL,RUBBER,FINGER,RH 1-1/2"BR 2-1/4"HUB 981290 SHFT,SQ,96",1-1/2"x94-1/4" LG RND,DBL SP 196501 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 Page 26...
  • Page 28 Operators manual MODEL 990 821899-PB SHFT,ELIM,96'',RLRSTR,FRONT Item Quantity Description Part # Number COLLAR,SHAFT,SET,SCREW,1-3/4" 502331 ROLL,RUBBER,FINGER,12POINT,1-3/4 HEX,A 981795 ROLL,RUBBER,FINGER,12POINT,1-3/4 HEX,B 981796 SHFT,HEX,1-3/4"x105.625"LG RLRSTR,96"990 050397 WASHER,2.875 OD,1-7/8IN HEX ID,0.625T 175099 Page 27...
  • Page 29 Operators manual MODEL 990 821900-PB SHFT,ELIM,96'',RLRSTR,FRONT Item Quantity Description Part # Number COLLAR,SHAFT,SET,SCREW,1-3/4" 502331 ROLL,RUBBER,FINGER,12POINT,1-3/4 HEX,A 981795 ROLL,RUBBER,FINGER,12POINT,1-3/4 HEX,B 981796 SHFT,HEX,1-3/4"x105.625"LG RLRSTR,96"990 050397 Page 28...
  • Page 30 Operators manual MODEL 990 8761-ELEV-RETURN 990 84"x21'-0" FULL RTRN CONV 9"FS ELEV Item Quantity Description Part # Number ARM,TORQUE,HYD,DRV,4 HOLE 1/2" x 12" 901495 BELT,FLAT,12" 1/32" x 1/32" 150# x 7.042 LNF 261000 BELT,FLAT,2-1/4",1/32" x 1/32" 150#x12.167LNF 261449 BELT,FLAT,2-1/4",1/32" x 1/32" 150#x9.167LNF 261449 BELT,FLAT,84"...
  • Page 31 Operators manual MODEL 990 8617-SCISSOR_BOX 990 96"x3+12+5 ROLL SCSSR REAR HNG R-STR Item Quantity Description Part # Item Quantity Description Part # Number Number BAR,SLIDE,ELIM 1/4x2x100 SQ TUBE 194456 LINKAGE ARM ELIM SCISSOR ADJ 22 INCH 191378 BOLT,WELD,ALL THREAD 3/4" x 5"...
  • Page 32 Operators manual MODEL 990 8617-HYD-CYL-ADJ 990 96" CYLINDER HYD SCISSOR ADJ DSCHRG Item Quantity Description Part # Number ARM,HYD,SCSSR,ROLL,ADJUST,98" WIDE 194299 CPLG,HYD,90DEG,6801-6-8 (6MJ-8MB) 601323 CPLG,HYD,STR,6400-6-8 (6MJ-8MB) 601477 CYL,3.00"x12",TIE ROD,22.25",1.375",3/4 602621 VALVE,ACCESORY,STD.LEVER M8x1.25x150mm 602474 VALVE,CHECK,METRO,#409-04-1084 601213 Page 31...
  • Page 33 Operators manual MODEL 990 8617-TRANS_ROLLS 990 96" TRANS TBL 5ROLL FIXED SCISSR ADJ Item Quantity Description Part # Number BRCKT,TRANS. ROLL LEFT w/SHEAR 195096 BRCKT,TRANS. ROLL RIGHT w/SHEAR 195097 COLLAR,SHAFT,SET,SCREW,3/4 501901 NUBBIN,1"ODx3/4"LONG DT 3/8" 181041 SHFT,ELIM,96",ELM/ELM FUL D/SPR CMPLT SS 821894 SHFT,ELIM,96",ELM/ELM HLF D/SPR CMPLT SS...
  • Page 34 Operators manual MODEL 990 821894-PB SHFT,ELIM,96",ELM/ELM FUL D/SPR CMPLT SS Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,DBL,HD60B14 1-1/4" BORE 881203 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB)
  • Page 35 Operators manual MODEL 990 821895-PB SHFT,ELIM,96",ELM/ELM HLF D/SPR CMPLT SS Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,ELIM,HALF,1-1/2" SQUARE BORE 981285 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,DBL,HD60B14 1-1/4" BORE 881203 WASHER,FLAT,1-1/4"...
  • Page 36 Operators manual MODEL 990 96"SCSSR HYD ADJ ELIM SIZING 4+12 ROLLS 8617-ROLLS-96inx15 Item Quantity Description Part # Number CHN,RLR,60 PITCH x 1.583 LNF 351005 SHFT,ELIM,96",ELM/ELM FL D/SPR CMP SS JK 821896 SHFT,ELIM,96",ELM/ELM FL TRNS CMPLT SS 821898 SHFT,ELIM,96",ELM/ELM HF TRNS CMPLT SS-1 821936 SHFT,ELIM,96",ELM/ELM HF TRNS CMPLT SS-2...
  • Page 37 Operators manual MODEL 990 821896-PB SHFT,ELIM,96",ELM/ELM FL D/SPR CMP SS JK Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL JACK 194297 SPRCKT,DBL,HD60B14 1-1/4" BORE 881203 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB)
  • Page 38 Operators manual MODEL 990 821898-PB SHFT,ELIM,96",ELM/ELM FL TRNS CMPLT SS Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 Page 37...
  • Page 39 Operators manual MODEL 990 821936-PB SHFT,ELIM,96",ELM/ELM HF TRNS CMPLT SS-1 Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,ELIM,HALF,1-1/2" SQUARE BORE 981285 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB)
  • Page 40 Operators manual MODEL 990 821897-PB SHFT,ELIM,96",ELM/ELM HF TRNS CMPLT SS-2 Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,ELIM,HALF,1-1/2" SQUARE BORE 981285 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB)
  • Page 41 Operators manual MODEL 990 821895-PB SHFT,ELIM,96",ELM/ELM HLF D/SPR CMPLT SS Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,ELIM,HALF,1-1/2" SQUARE BORE 981285 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,DBL,HD60B14 1-1/4" BORE 881203 WASHER,FLAT,1-1/4"...
  • Page 42 Operators manual MODEL 990 821893-PB SHFT,ELIM,96"ELM/ELM D/B HF D/S CMPLT SS Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,ELIM,HALF,1-1/2" SQUARE BORE 981285 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,DBL,HD60B14 1-1/4" BORE 881203 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB)
  • Page 43 Operators manual MODEL 990 8761-SIZE-CONV 990 84"x5' SIZING RETURN CONV. 9"FS HYD Item Quantity Description Part # Number ARM,TORQUE,HYD,DRV,4 HOLE 1/2" x 12" 901495 BELT,FLAT,12" 1/32" x 1/32" 150# x 7.042 LNF 261000 BELT,FLAT,12" 1/32" x 1/32" 150#x5.500LNF 8761-912 BELT,FLAT,84",1/32"x1/32"150#"C"SCTx10.000LNF 261877 BRNG,PB,1-7/16"...
  • Page 44 Operators manual MODEL 990 8761-PICKING-TBL 990 42"x16'SPLT TBL ELEC VARI SPD STRGHT Item Quantity Description Part # Number BELT,FLAT,18" 1/32" x 1/32" 150# x 9.667 LNF 261003 BELT,FLAT,42" 1/32" x 1/32" 150# x 32.667 LNF 261475 BRNG,PB,1-1/4" BORE,SET SCREW COLLAR SAS 231132 BRNG,PB,1-7/16"...
  • Page 45 Operators manual MODEL 990 FA5017 990 HANG ON CHUTES 16' FULL OR SPLIT TBL ITEM DESCRIPTION PART #: CHUTE,ELIM.HANG-ON,6"x 16" x 21" 194457 Page 44...
  • Page 46 Operators manual MODEL 990 FA5541 990 12"x16' RTRN CONV 3 BELT SPLIT TABLE Item Quantity Description Part # Number ARM,TORQUE,HYD,WHL,DRV,4 HOLE 3/8x11" 901576 BELT,FLAT,12" 1/32" x 1/32" 150#x1.042 LNF 261000 BELT,FLAT,12" 1/32" x 1/32" 150#x27.000LNF 261000 BELT,FLAT,12" 1/32" x 1/32" 150#x47.000LNF 261000 BELT,FLAT,12"...
  • Page 47 Operators manual MODEL 990 FA5057 990 PICKER PLATFORM 12"x120" PICK TABLE ITEM DESCRIPTION PART #: LADDER,PICKER PLATFORM,ELIM, 2 RUNG 193614 PIN, P ICKING TABLE PLATFORM 1/2"x3" G01577 PLATE,1/4" x 8" x 9-7/8" 022948 PLATE,ELIMINATOR,PLATFORM,MOUNTING 173467 PLATFORM,PICKING TABLE,12"x120",W/ RAIL 193612 Page 46...
  • Page 48 Operators manual MODEL 990 8761-XC-30INx12FT 990 CROSS CONV 30"x12' FLAT BELT (HYD) Item Quantity Description Part # Item Quantity Description Part # Number Number ARM,TORQUE,HYD,DRV,4 HOLE 1/2" x 12" 901495 SHLD,TAKEUP BEARING,#981572 TAKEUP 841286 BELT,FLAT,2-1/4",1/32" x 1/32" 150#x12.000LNF 261449 STOP,ROLL OUT,30" CROSS CONVEYOR 174904 BELT,FLAT,30"...
  • Page 49 Operators manual MODEL 990 FA6752 990 HYD STEERNG PVT TONGUE DSCHRG NARROW Item Quantity Description Part # Number AXLE MOUNT, ELIM, PIVOT STEERING, NARROW 194305 AXLE, ELIM, PIVOT STEERING, 8 HOLE G01377 BOLT,HEX,HD,9/16"-18UNFx1-1/2" GR5*FINE* 502250 BRACKET,HYD,SWIVEL STEERING,NARROW FRAME 194459 CPLG,HYD,90DEG,6801-6-8 (6MJ-8MB)
  • Page 50 Operators manual MODEL 990 FA6741 990 HYD WHEEL DRV TANDEM AXLE HVY PLNTRY ITEM DESCRIPTION PART #: AXLE,ELIM,SUPPORT,TANDEM,PIVOT,PLANETARY 194295 AXLE,ELIMINATOR,TANDEM,PLANETARY DRIVE 194289 COLLAR,SHAFT,SET,SCREW,2" 501954 CPLG,HYD,90DEG,6801-06-10,NWO(6MJ-10MB) 602662 CPLG,HYD,STR,6400-8-8 (8MJ-8MB) 601457 GRBX,PLNTRY,AUBURN,WHL DRV,34:1,W/ Q.D. 571429 HUB,ASSY,FOR 730 LONG GRBX 571123 MTR,HY,8.0CUIN,13T-SPLINE,SAE-A,TB-SERIE 602059 NUT,LUG,GRBX,WHL,DRV 9/16"-18 730 UBT-4...
  • Page 51 Operators manual MODEL 990 FA5135 990 HYDRAULIC JACKS 4 EACH Item Quantity Description Part # Number CPLG,HYD,90DEG,6801-6-8 (6MJ-8MB) 601323 CPLG,HYD,STR,6400-6-8 (6MJ-8MB) 601477 CYL,3.00"x12",TIE ROD,22.25",1.375",3/4 602621 JACK,ASSEMBLY,LEVELING,ELIMINATOR 131173 PLATE,1/4" x 5" x 5" G00598 VALVE,ACCESORY,SAFETY LEVER M8x1.25x160m 602473 VALVE,ACCESORY,SAFETY LEVERBRACKET 602472...
  • Page 52 Operators manual MODEL 990 FA5175 990 HYD UNIT 7-1/2 HP MTR 480V 3PH Item Quantity Description Part # Item Quantity Description Part # Number Number BUSHING,SH 1-3/8" BORE 781474 LABEL,HYDRAULIC,FILTER CHANGE EVERY200HR 300210 CLPG,HYD,TEE,6602-08-08-08(MJ-FJS-MJ) 602367 LABEL,OPEN CENTER HYDRAULIC SYSTEM 300120...
  • Page 53 Operators manual MODEL 990 8617-CANOPY 990 CANOPY ROOF 11'x14' Item Quantity Description Part # Number ANGLE,1/8"x1"x1" x 45" (CUT TO FIT) G00504 ANGLE,1/8"x1"x1" x 57" (CUT TO FIT) G00505 CANOPY,ROOF FRAME,11' WD x 14' LG ELIM 194313 SHEET,ROOFING,METAL,24" x 136"...
  • Page 54 Operators manual MODEL 990 8761-CURTAINS CURTAINS, CURTAIN FRAMES & HANGERS Item Quantity Description Part # Number CURTAIN,INTAKE,END,CUSTOM,132"Wx125"H 8671-990 CURTAIN,LEFT SIDE,CUSTOM,168"Wx125"H 8761-993 CURTAIN,OUTLET,END,CUSTOM,132"Wx125"H 8761-991 CURTAIN,RIGHT SIDE,CUSTOM,168"Wx125"H 8761-992 PIPE,END CURTAIN HANGER,11FT 174724 PIPE,SIDE CURTAIN HANGER,14FT 174979 SIDE CURTAIN FRAME 11'Wx7'H MDL 905 ELIM...
  • Page 55 Operators manual MODEL 990 8761-PUP-HITCH 990 ELIM 96" PUP HITCH DBL NO PAN CHN EL Item Quantity Description Part # Number BRACE,PUP,HITCH #550/1800 LEFT 2" ANGLE 171084 BRACE,PUP,HITCH #550/1800 RIGHT 2" ANGLE 171161 HITCH,PUP,96",DBL,ELIM,CHN ELEV w/NO PAN 196487 Page 54...
  • Page 56 Operators manual MODEL 990 8761-END-CROSS ELIM END CROSS CONV 42"x12' C-SECT BELT Item Quantity Description Part # Item Quantity Description Part # Number Number BELT,ASSY,12',XCONV,42"x24'0" "C" SECT 261987 SHFT,TK 1-7/16 x 49-1/2, (10-10-14) 821324 BRACE,ELIM,42"W,END X CONV FLAT 49"LONG 174720 SHLD,OVAL,HINGED,W/BACK,3"x9"x32"...
  • Page 57 Operators manual MODEL 990 FA5339 990 2 PUPS 480V 3PH / 230V 1PH TRUCK Item Quantity Description Part # Number CPLG,HYD,STR,2403-8-8 (8MJ-8MJ) 601659 EXTENSION,PUP,HITCH,20",DOUBLE/ASSY 171122 Page 56...

  • Page 58: Schematics

    Operators manual MODEL 990 Page 57...
  • Page 59 Operators manual MODEL 990 Page 58...
  • Page 60 Operators manual MODEL 990 Page 59...
  • Page 61 Operators manual MODEL 990 Page 60...
  • Page 62 Operators manual MODEL 990 Page 61...
  • Page 63 Operators manual MODEL 990 Page 62...
  • Page 64 Operators manual MODEL 990 Page 63...
  • Page 65 Operators manual MODEL 990 Page 64...
  • Page 66 Operators manual MODEL 990 Page 65...
  • Page 67 Operators manual MODEL 990 Page 66...
  • Page 68 Operators manual MODEL 990 Page 67...
  • Page 69 Operators manual MODEL 990 Page 68...
  • Page 70 Operators manual MODEL 990 Notes !! Page 69...
  • Page 75 Please fill out the letter below or email to warranty@spudnik.com to register the recently sold machine. Providing the customer name and address is optional and at your discretion. It will aid Spudnik in providing product updates to your customer should the necessity arise. The serial number and date the machine was delivered is mandatory.
