TRASSIR TR-D2353WDZIR7 Manual

Specification
Model TR-D2353WDZIR7
Image sensor 1/2.7" CMOS 5МP
Resolution 5MP(2592x1920) 4MP(2560x1440)
3MP(2304x1280) 2MP(1920x1080)
Frame rate 50Hz: 5MP@25fps
60Hz: 5MP@30fps
Electronic shutter speed 1/2 ~ 1/1 000 s
Day/Night mode Mechanical ICR
Sensitivity 0.002Lux (F1.3)
IR range
up to 70 m
Lens (mm) 2.7 - 13.5 (motorzoom)
Field of view (horiz./vert.)
91˚-30˚±5˚ / 66˚-22˚±5˚
Axes setting Pan: 0˚-360˚
Tilt: 0˚-90˚
Rotation: 0˚-360˚
WDR Real WDR (120dB)
Digital noise reduction
Video compression Н.265+ / Н.265 / H.264
Bitrate up to 8Mbps
Local storage MicroSD up to 256GB
Audio Built-in microphone
Audioinput / Audiooutput
Alarm inputs/outputs
Corridor mode
IVS
RTC
Power supply PoE (802.3af) / 12V DC
PoE Class
Power consumption DC: 8.2W
PoE: 11.8W
Case material
Dimensions (mm) 222.86 x 79.03 x 74.76
Weight Net/Gross (g) 640 / 830
Protection IP67, IK08
Power surge TVS 4000V
suppressor
Working temperature -50°C ... +60°C
Cold start
Technical support
www: helpdesk.trassir.com
mail: helpdesk@trassir.com
3D DNR
1 / 1
Yes
Yes
Yes
0
Metal
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
-50°C
TR-D2353WDZIR7
Outdoor IR Bullet Network Camera
IK08
Note: read user manual before using
Website: www.trassir.com
For any inquiry: info@trassir.com
