- Page 1 Profile Edge Installation Guide For assistance call (888) 213-5015 or visit www.leonspeakers.com REF-25-065_Profile_Edge_20221220...
-
Page 2: Product Overview
PRODUCT OVERVIEW ADDITIONAL HARDWARE Binding Screw HeadLOK™ Screw Plastic Snap Shim Left & Right PrMMB Display Mount HeadLOK™ Spider 2-7/8” Bracket Template Install template Drive Bit Edge Mounting Pack - Drawings not to scale PrMMB Bracket Bonded Washer Wood Screw Flip Toggle Trusshead Screw Foam Tape... - Page 3 Fig. 1 Screw Backboard to Wall Assemble and screw backboard to wall with 8 2-7/8” headlocks C provided as part of edge mounting pack. Use shim pack D as needed if wall is not flat. Fig. 2 Install PrMMB Align and level the PrMMB templates F with top and side of the backboard.
- Page 4 Fig. 4 Drill Pilot Holes * 3/32” bit for wood screws into stud * 1/2” bit for flip toggles into dry wall Remove brackets G and drill pilot holes at mark locations for wood screws or flip toggles. Fig. 5 Attach Bracket to Wall If mounting into a stud use 2 wood screws I and 2 bonded washers H...
- Page 5 Fig. 7 Mounting Setting Speaker Depth Bolt wall 1/8” T-Bar Adjust the pre-installed mounting bolts and T-bars on the back of speakers so speakers are approximately 1/8” off wall. *drawing not to scale Fig. 8 Install Speakers Mount the speakers to the wall by setting the mounting bolts on the back of your speakers into the top notch of the PrMMB brackets G .
- Page 6 Fig. 10 Mark the Template TV Mount Wall Plate Latch the TV mount wall plate to the TV mount uprights as if it were hung on the wall. Position the display mount installation template B with the lip held tightly against the top edge of the TV.
- Page 7 Fig. 13 Install Display Mount Following manufacturer’s specifications, insall your display mount to the TV mount wall plate. Fig. 14 Attach Display to Mount Attach the display to the mount. Ensure that the display is center with the backboard. Speakers may need to be removed from PrMMB brackets G in order to hang the display.
- Page 8 Fig. 16 Make Trim Connection For typical trim connections install the 8 binding screws A into the speakers as shown. Fig. 17 Install Grilles Magnetically attach the grilles to the speakers. NOTE: versions with linear bar grilles come with the linear bar grilles preinstalled.
