FLSH Bracket
1 / 8 " D e p t h O n - w a l l B r a c k e t
WAL L MOUN T K I T
Wood Screw
Bonded Washer
Flip Toggle
Trusshead Screw
4x
4x
2x
2x
NOTE: Not all parts in the Wall Mount Kit will be used during install
FL S H BR AC K E T PART S
Wall Plate
Template
2x
1x
NOTE: Template may look different based on speaker style. The template for the Horizon Speaker is shown.
