- Page 1 PrMMB-UT I N S T A L L A T I O N G U I D E...
- Page 2 Questions? Call Customer Service 1.888.213.5015 Mon-Fri 8am-6pm EST Visit us online for product support, guides and videos www.leonspeakers.com/support...
- Page 3 PrMMB-UT : Profile Ultra-Thin MatchMount Bracket Leon’s Profile Ultra-Thin MatchMount Bracket can be used to mount your Leon Profile speakers on the wall, beside any TV. This versatile bracket offers multiple points of adjustment for a perfect fit, every time.
- Page 4 Bracket Hardware *Not to scale MatchMount Bracket : PrMMB-UT...
-
Page 5: Parts List
~ Drywall Anchor ~ Bracket ~ Bonded Washer ~ Wood Screw Parts List *Not to scale For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST... - Page 6 Align & level Templates with top and side edges of TV Templates can be secured with masking tape Template - 6 - MatchMount Bracket : PrMMB-UT...
- Page 7 Align Brackets level with Templates and mark Pilot Holes Mark holes towards top of Bracket Bracket - 7 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 8 Remove Brackets and drill* Pilot Holes at mark locations for Wood Screws or Drywall Anchors *3/32” bit for Wood Screws *5/16” bit for Drywall Anchors Carefull to not damage TV while drilling - 8 - MatchMount Bracket : PrMMB-UT...
- Page 9 Attach Brackets to wall using Bonded Washers with Wood Screws or Drywall Anchors Remove Templates before securing Brackets Drywall Anchor/Screw Bonded Washer Wood Screw Bracket - 9 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 10 Measure depth from face of TV to the Wall and adjust speaker Mounting Bolts to match Mounting Bolts come pre-installed - 10 - MatchMount Bracket : PrMMB-UT...
- Page 11 Side View Front View Hang speakers by securing Top Mounting Bolts in Brackets Mounting Bolts come pre-installed - 11 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 12 Side View Extend T-Bar Bolts on bottom of speaker to wall Set T-Bar Bolts horizontally to prevent rocking T-Bar Bolts come pre-installed - 12 - MatchMount Bracket : PrMMB-UT...
- Page 13 Side View Adjust Mounting Bolts and T-Bar Bolts to align speakers with TV T-Bar Bolts can adjust speaker tilt Front of speakers aligned with front of TV - 13 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 14 Side View Adjust Lock Nuts to secure assembly Lock Nuts come pre-installed - 14 - MatchMount Bracket : PrMMB-UT...
- Page 15 Tighten all Screws & Connections and connect Wiring to Speakers Ensure flush TV/Speaker alignment before tightening - 15 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 16 715 W. Ellsworth Road Ann Arbor, Michigan 48108 | 1.888.213.5015 | www.leonspeakers.com...
