- Page 1 LP01D Assembly Instruction LAURA PLUS for wooden doors...
- Page 5 A. Unpack the components of Lara Plus door frame B. Insert snap-on corners [10] and two-part expansion corners [9] into the vertical profiles of the rear trim [6 and 7] C. Assemble the vertical profiles [6 and 7] with the horizontal profile [8] of the rear trim D.
- Page 6 E. Tighten grub screws in the expansion corners [9], making sure that the profiles are joined evenly F. Make sure that well-assembled components of hinge fastening are present on the inner side of the door frame body G. Proceeding in the same way as in the case of rear trim, insert snap-on corners [10] and two-part expansion...
- Page 7 I. Tighten the bolt in the snap-on corner [10] through the service hole in the horizontal profile [3] until the profiles join J. Tighten grub screws in the expansion corners [9], making sure that the profiles are joined evenly K. Insert the wall seal [5] into the seat of the door frame’s rear trim along the whole circumference of profiles...
- Page 8 M. Correctly assembled door frame components - body and rear trim N. Insert the assembled door frame body into the construction opening. Door frame trims should rest evenly on the wall O. Check the door frame’s vertical and horizontal placement P.
- Page 9 R. Fill the gaps between the door frame and the construction opening with low-pressure caulking foam S. After caulking foam has dried, cut the excess off with a knife and remove the wedges T. In order to fasten the door frame body better in the construction opening, the profile can be drilled through...
- Page 10 W. Insert the rear trim into the door frame body, beginning from the door frame bottom. Assembly adhesive may be used to join the trim with the body permanently X. Install the trim evenly in the door frame body Y. Correctly assembled door frame in the opening Z.
- Page 11 2A. Using bolts [15] tighten hinges [16] to the door frame profile 2B. Place the seal [4] in the seat by trimming it appropriately in the door frame corners and to the profile length 2C. Place the door onto the door frame by lifting it using the wedge inserted under the door, which facilitates fixing...
- Page 12 Then apply caps onto the hinges [16] 2H. Final effect of a correctly assembled Laura Plus door frame...
- Page 13 Adjustment instruction of standard used hinges A - Oval opening that serves for fastening the hinge to the leaf and for adjusting it up and down (making the top gap even) B - Bolt for hinge adjustment right and left (making leaf’s side gaps even) C - Bolt for hinge adjustment front and back (making the leaf flush with wall surface) D - Bolt serving for unlocking/locking the position set by C bolt E - Round opening that serves for fastening the hinge to the door frame...
- Page 14 1. In order to adjust the leaf height (decrease or increase the top gap), loosen screws in openings [A] that hold all hinges in the leaf 2. Using a wedge (an adjustment washer for doors), lift the door to the desired height in such a way that the gap between the door frame and the leaf is about 3 mm.
- Page 15 The range of hinge adjustment in this plane is +/-1 mm 5. In order to adjust the gaps between the leaf and the door frame on the sides, tighten or loosen [B] bolt in the hinge, which makes the leaf move right or left.
- Page 16 ENG-0717.01-LP01D-TW...
