- Page 1 TcUMB IN STAL L ATIO N GUI DE 715 W. Ellsworth Road Ann Arbor, Michigan 48108 | 1.888.213.5015 | www.leonspeakers.com...
- Page 2 Visit us online for product support and installation guides. www.leonspeakers.com Questions? Call Customer Service 1.888.213.5015 Mon-Fri 8am-6pm EST...
- Page 3 TcUMB MOUNTING SYSTEM for SONOS PLAYBAR Thank you for purchasing the ToneCase UMB Mounting System. The TcUMB is designed to attach the SONOS PLAYBAR directly to the display and offers multiple points of articulation for a perfectly flush installation. For more information, visit www.leonspeakers.com.
-
Page 4: Bracket Hardware
Universal TV Mount Hardware Not to scale / Extra hardware included Metal Housing for SONOS PLAYBAR ® ® Bracket Hardware *Not to Scale For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST... - Page 5 The long slot of the Metal Housing should be ON TOP. Lateral adjustments can be made to the brass post if the spacing does not line up with the keyholes on the Playbar. - 5 - TONECASE: TcUMB MOUNTING SYSTEM...
- Page 6 NOTE: Image above also shows custom grill, not included. Place TV & TcUMB on clean, padded surface - 6 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 7 Align the Uprights with TV Mount Holes *Mount Rails provided by TV mount manufacturer *Use Nylon Spacers as needed Nylon Spacer Uprights 4x/8x - 7 - TONECASE: TcUMB MOUNTING SYSTEM...
- Page 8 Affix TV Mount Rails* with M6/M8 Screws and Split Lock Washers *Do not tighten screws completely in order to adjust the Uprights Metric Washer Split Lock Washer Nylon Spacer M8/M6 Screw 4x/8x - 8 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 9 Attach Swing Arms to Paddles and Uprights with Long Cap Screws* *Do not tighten Long Cap Screws completely Swing Arm Paddle Long Cap Screw - 9 - TONECASE: TcUMB MOUNTING SYSTEM...
- Page 10 Locate Square Nut on Metal Housing captured within top slot - 10 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 11 Slide Metal Housing forward until Paddles rest flat on back of Metal Housing *Allow 1”-2” space from bottom TV edge - 11 - TONECASE: TcUMB MOUNTING SYSTEM...
- Page 12 Tighten all 4 Long Cap Screws to secure Swing Arms/Paddles in position *Long Cap Screws require extra torque - 12 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 13 Slide Metal Housing flush with bottom of TV. Attach Paddles to Metal Housing by screwing Cap Screws into Square Nuts *Square Nuts are captured in slots on Metal Housing Cap Screw - 13 - TONECASE: TcUMB MOUNTING SYSTEM...
- Page 14 NOTE: Image above also shows custom grill, not included. Make final adjustments to Metal Housing and tighten all screws & connections. Proceed to mount TV/speaker assembly. IMPORTANT: Be sure to completely tighten the Uprights. Some screws require extra torque. - 14 - For assistance, call: 1.888.213.5015 | Mon-Fri 8am-6pm EST...
- Page 15 Visit us online for product support and installation guides. www.leonspeakers.com Questions? Call Customer Service 1.888.213.5015 Mon-Fri 8am-6pm EST...
- Page 16 715 W. Ellsworth Road Ann Arbor, Michigan 48108 | 1.888.213.5015 | www.leonspeakers.com...
