Wheel Bearing Tool Set, Iveco Daily
GEDORE Automotive GmbH
Breslauer Straße 41
78166 Donaueschingen
Postfach 1329
78154 Donaueschingen - GERMANY
KL-0041-800
KL-0041-803
Phone.: +49 (0) 771 / 8 32 23-0
Fax: +49 (0) 771 / 8 32 23-90
0041-800e180406.docx
Email: info@gedore-automotive.com
Internet: www.gedore-automotive.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KL-0041-800 and is the answer not in the manual?

Questions and answers

Related Manuals for Gedore KL-0041-800

Summary of Contents for Gedore KL-0041-800

  • Page 1 Wheel Bearing Tool Set, Iveco Daily KL-0041-800 KL-0041-803 0041-800e180406.docx GEDORE Automotive GmbH Breslauer Straße 41 Postfach 1329 Phone.: +49 (0) 771 / 8 32 23-0 Email: info@gedore-automotive.com 78166 Donaueschingen 78154 Donaueschingen - GERMANY Fax: +49 (0) 771 / 8 32 23-90...
  • Page 2 Le plus grand soin possible a été apporté à la rédaction de ce document. Toutefois, nous n’assumons aucune responsabilité pour des erreurs, omissions ou défauts d’impression éventuels. Une reproduction, même en partie, ne peut être effectuée qu’après autorisation écrite préalable de GEDORE Automotive GmbH. Tous droits réservés.

  • Page 3: Table Of Contents

    4.1 Removing the Wheel Hub and Wheel Bearing: .................. 7 4.2 Installing the Wheel Bearing and Wheel Hub: ..................9 5. Care and Storage .......................... 12 6. Maintenance and Repair by the GEDORE Automotive Service Centre ........12 7. Spare Parts List ..........................12 8. Accessories ............................ 12 9.

  • Page 4: Essential Safety Notices

     Make sure there is sufficient space available beneath the wheel hub.  Read and adhere to the workshop press manufacturer’s safety instructions and regulations.  Only use the genuine spare parts and accessories from GEDORE Automotive. CAUTION The wheel bearing housing and/or support plate can cause injuries to feet and toes if dropped.

  • Page 5: Personal Protective Equipment

    1.3 Intended Use The KL-0041-800 wheel bearing tool set is designed to be used in conjunction with an appropriate workshop press and is only intended for the quick and professional removal/installation of wheel hubs as well as wheel bearing units from/to the front axle of Iveco Daily vehicles.

  • Page 6: Product Description

    Used in conjunction with an appropriate workshop press, the KL-0041-800 wheel bearing tool set allows for the quick and professional removal and installation of the wheel hubs as well as wheel bearing units found at the front axle of Iveco Daily vehicles.

  • Page 7: Example Of Use

    GEDORE Automotive. Activate workshop press pump and press out wheel hub from wheel bearing. (Fig. 5 A) During removal, monitor the necessary pressing force/load applied on the pressure gauge of the workshop press. Chapter © Copyright by GEDORE Automotive GmbH, Germany 0041-800e180406.docx hu-gm...
  • Page 8 Operate workshop press pump and press out wheel bearing from wheel bearing housing. (Fig. 7 A) During removal, monitor the necessary pressing force/load applied on the pressure gauge of the workshop press. Chapter © Copyright by GEDORE Automotive GmbH, Germany 0041-800e180406.docx hu-gm...

  • Page 9: Installing The Wheel Bearing And Wheel Hub

    When installing the circlip, there is a risk that it could be ejected and cause injuries to your eyes.  Always wear safety goggles. Using an appropriate tool, install wheel bearing circlip in accordance with the manufacturer’s instructions. (Fig. 9) Chapter © Copyright by GEDORE Automotive GmbH, Germany 0041-800e180406.docx hu-gm...
  • Page 10 Fig. 11 A. Tighten wheel bolts to 60 Nm. 7. Tighten central fastening nut in accordance with the manufacturer’s instructions. (Fig. 11 B) Next, loosen wheel bearing housing and remove it from holding fixture KL-0041-803 (accessory). Chapter © Copyright by GEDORE Automotive GmbH, Germany 0041-800e180406.docx hu-gm...
  • Page 11  Observe and do not exceed the maximum load capacity of the workshop press.  Read and adhere to the workshop press manufacturer’s safety instructions and regulations.  Only use the genuine spare parts and accessories from GEDORE Automotive. Activate workshop press pump and press dust cap into wheel ’B’...

  • Page 12: Care And Storage

    For safety reasons, as soon as damage is noticed on the wheel bearing tool set, immediate steps must be taken to prevent it from being used. For professional inspection and repair of the wheel bearing tool set, please contact the GEDORE Automotive Service Centre. Address: GEDORE Automotive GmbH Breslauerstraße 41...
