Wohler HDCC-708MULTI Configuration Manual

Multi-purpose, 3g/hd/sd-sdi closed caption card: inserter, decoder, bridge, monitor, and transcoder
Hide thumbs Also See for HDCC-708MULTI:
Table of Contents

Advertisement

Quick Links

Download this manual
HDCC-708MULTI and
HDCC-B37MULTI
(CEA-608/CEA-708 and ARIB B37 Closed Caption/
Subtitle Card)
•
HDCC-708MULTI-OG2 (openGear Platform)
•
HDCC-708MULTI-2CH (MC-1RU Platform)
•
HDCC-B37MULTI-OG2 (openGear Platform)
•
HDCC-B37MULTI-2CH (MC-1RU Platform)
Multi-Purpose, 3G/HD/SD-SDI Closed
Caption Card: Inserter, Decoder, Bridge,
Monitor, and Transcoder
Configuration Guide
Firmware Version: V2.46
Software Version: V0.68
Part Number 821094, Revision A
