- Page 1 POWER INVERTER WITH PURE SINE WAVE CSI PRO Series Installation and Operating Instructions...
-
Page 2: Table Of Contents
1. First familiarise yourself with the safety instructions on p. 2. 2. Install the ECTIVE CSI PRO inverter in accordance with the instructions on p. 9. 3. Ensure that the inverter is switched off, connect your supply battery and, if necessary, the shore power, taking into account the instructions in the ‘Connections and commissioning’... -
Page 3: Welcome
Thank you for choosing an ECTIVE CSI PRO inverter! Devices in the CSI PRO series are among the most advanced inverters from ECTIVE. They provide high- quality alternating current with a pure sine wave, which can also be used to operate sophisticated and complex electronic loads: Power just like from a 230 V earthed socket at home - anytime and anywhere. -
Page 4: Scope Of Delivery
Scope of Delivery Products in the ECTIVE CSI PRO series include the following elements. Please check that the scope of delivery is complete before installation and commissioning: ■ 1 × ECTIVE CSI PRO Inverter High-quality inverter with integrated IUoU charger. Please refer to the list below for the technical details of your model. - Page 5 Observe the maximum total output of the connected loads. Some loads require a short-term ■ starting current at start-up, which can be significantly higher than the regular operating current. For this purpose, ECTIVE CSI PRO inverters can supply 150 % power for 10 seconds or 200 % power for 2 seconds. ■...
-
Page 6: Product Overview
On the following pages you will find an overview of the connections and operating elements on the various models in the ECTIVE CSI PRO series. Please note the technical specifications and performance values applicable to your model when using it. - Page 7 Connections and controls (All CSI PRO models) Direct current connection positive pole* * Connections for e.g. battery CSI 10, CSI 15: M8 Direct current connection negative pole* CSI 20, CSI 25, CSI 30: M10 ECTIVE CSI Pro Inverter | Product Overview...
- Page 8 DIP switch for selecting the battery overcurrent protection technology 230 V socket Charge level LEDs Plug for shore power connection Protective earthing Main switch: On/Off/ECO/UPS mode Status LEDs (see next page) Connection for remote control USB port ECTIVE CSI Pro Inverter | Product Overview...
- Page 9 DIP switch for selecting the battery overcurrent protection technology 230 V socket Charge level LEDs Main switch: On/Off/ECO/UPS mode Alternating current output Status LEDs (see next page) Shore power connection Connection for remote control Protective earthing USB port ECTIVE CSI Pro Inverter | Product Overview...
- Page 10 Float: Float charging AC-In: Shore power is present ABS: Residual charge (absorption) By-Pass: Mains priority circuit Bulk: Main charge 12. Wake up: Reactivation of the battery after blocking by BMS (only for LiFePO ECTIVE CSI Pro Inverter | Product Overview...
-
Page 11: Installation
Installation Please observe the following installation instructions when installing your ECTIVE CSI PRO inverter: ■ Disconnect the inverter from the power supply before installing or working on the device. Never open the housing of the inverter. ■ Only mount or screw the inverter to solid mounting surfaces. - Page 12 The inverter can be mounted both horizontally and vertically. Minimum distance for sufficient ventilation The distance between ventilation elements and the nearest surface must be at least 10 cm. Ventilation slots and fans must not be covered. ECTIVE CSI Pro Inverter | Installation...
- Page 13 When installing in confined spaces, observe the minimum distance of 10 cm in front of the ventilation elements! ECTIVE CSI 10 PRO ECTIVE CSI 15 PRO ECTIVE CSI 20 PRO ECTIVE CSI 25 PRO ECTIVE CSI 30 PRO 6 mm Protruding connections Mounting panel ECTIVE CSI Pro Inverter | Installation...
-
Page 14: Connections And Commissioning
In addition, all instructions in the ‘Safety instructions’ section must be followed to ensure safe operation. Inverters of the ECTIVE CSI PRO series are intended exclusively for use in stand-alone, so-called ■ ‘off-grid’ areas. Never connect an AC voltage source to the 230 V output of the inverter (earthed socket)! Such a connection poses a risk to life as well as immediate and irreparable damage to the inverter. - Page 15 CSI 25 PRO, CSI 30 PRO Small Device (USB) RC PRO Remote Control Small Device (USB) Shore Power 230 V Consumer 230 V Shore Power RC PRO Consumer AC Consumers Remote Control ECTIVE CSI Pro Inverter | Connections and Commissioning...
- Page 16 12 V batteries! In the following example, three ECTIVE LC 100 LiFePO4 batteries with a capacity of 100 Ah each were connected in parallel. The total capacity is 300 Ah and is therefore sufficient to operate a CSI 30 PRO as intended.
- Page 17 Personal protection in the TN network Inverters from the ECTIVE PRO series provide a so-called TN grid. This is an ‘earthed system’ - the neutral point of the system is directly earthed via the operating earth electrode and all bodies of the individual loads are connected to the operating earth electrode (PE).
-
Page 18: Operation
Integrated protective circuits, durable power electronics and intelligent microprocessor control of the ECTIVE CSI PRO inverters guarantee a high overload capacity. This means you can also use loads with high starting currents or short-term high peak consumption safely and without restrictions: ■... - Page 19 ECO Mode (Battery Priority) and UPS Mode (Mains Priority) Inverters in the ECTIVE CSI PRO series can be operated in ECO mode or in UPS mode. In ECO mode (battery priority circuit), the inverter supplies the loads with power from the connected battery, even if the system is connected to shore power.
- Page 20 Disconnect the battery from the inverter by disconnecting the connecting cables or using a circuit ■ breaker to prevent deep discharge of the battery. Store the inverter out of the reach of children in a dry place, protected from direct sunlight. ■ ECTIVE CSI Pro Inverter | Operation...
-
Page 21: Battery Charger
Battery Charger Inverters in the ECTIVE CSI PRO series have an advanced integrated battery charger with IUoU charging characteristic, which can be used to charge connected batteries directly with shore power. Integrated Battery Charger The right charging process for all battery technologies: In addition to standard wet batteries, the integrated multi-stage charger is also suitable for AGM, gel and LiFePo4 batteries (with BMS). - Page 22 100 % by pulse charging. In this way, it is constantly kept between 95 % and 100 % state of charge. Charge voltage 100 % Charge current 10 % Main Charge Residual Charge Float Charge (constant current) (constant voltage) ECTIVE CSI Pro Inverter | Battery Charger...
- Page 23 Useful accessories not included in scope of delivery. With the ECTIVE RC PRO remote control, you always have many relevant values of your system in view and can conveniently choose between ECO, UPS mode and pure inverter operation at any time.
- Page 24 Residual Charge) (Float Charge) LiFePO 14,6 V 14,8 V 13,8 V Calcium 15,0 V 13,8 V 14,6 V 13,4 V 14,4 V 13,4 V 14,2 V 13,2 V Constant Voltage 13,8 V 12,0 V ECTIVE CSI Pro Inverter | Battery Charger...
-
Page 25: Eco And Ups Mode
If shore power becomes available again after scenario 4 (emergency discharge down to 10.2 V), the batteries are charged immediately to prevent damage to the batteries as quickly as possible. Charging takes place until a battery voltage of 14.2 V is reached. ECTIVE CSI Pro Inverter | ECO and UPS Modes... - Page 26 Graphical Representation of the Scenarios Szenario in UPS Mode Shore Power Bypass Function Inverter Function Battery Voltage 11 V 10.5 V Charge Current Battery Charger Phase T2 T3 T4 T5 T8 T9 ECTIVE CSI Pro Inverter | ECO and UPS Modes...
- Page 27 UPS Mode (Mains Priority) Operating Conditions AC Charger By-Pass Inverter Shore power available ■ No shore power ■ Device is Turned Off Operating Conditions AC Charger By-Pass Inverter No shore power ■ ECTIVE CSI Pro Inverter | ECO and UPS Modes...
- Page 28 *For technical reasons, the ‘UPS’ LED may also shimmer slightly green depending on the lighting conditions. When the battery is charging, the ‘Power’ LED and the corresponding charging phase LED also light up. Please refer to the explanations in the section ‘Battery Charger’. ECTIVE CSI Pro Inverter | ECO and UPS Modes...
- Page 29 *For technical reasons, the ‘UPS’ LED may also shimmer slightly green depending on the lighting conditions. When the battery is charging, the ‘Power’ LED and the corresponding charging phase LED also light up. Please refer to the explanations in the section ‘Battery Charger’. ECTIVE CSI Pro Inverter | ECO and UPS Modes...
-
Page 30: Safety Features
Safety Features The following safety functions of the ECTIVE TSI PRO inverters protect the user, devices and battery during operation. ■ Overvoltage and Undervoltage Protection ■ Overheating Protection Switches the inverter off automatically if Switches the inverter off immediately at the set values are exceeded or undercut, internal temperatures above 75 °C. - Page 31 ‘Fault’ In the event of an error, observe the LED and the acoustic signal to identify the problem. Rectify the fault as quickly as possible by following the instructions in the ‘Troubleshooting’ section. ECTIVE CSI Pro Inverter | Safety Features...
-
Page 32: Troubleshooting
Possibility A: The connection to the loads has been broken. Check the connection between the inverter and the connected loads. ■ Possibility B: There is a short circuit on the loads. ■ Check the connected loads for short circuits. ECTIVE CSI Pro Inverter | Troubleshooting... - Page 33 Ensure that the inverter can cool down. CHARGER: The charger is not working The input voltage is outside the required minimum or maximum values. Use a power source with the correct voltage and frequency. ■ ECTIVE CSI Pro Inverter | Troubleshooting...
- Page 34 If none of the other solutions solve the problem, please contact our customer service. ■ Any questions? If you encounter problems that you cannot solve yourself, please contact our customer service. They will provide you with qualified help! ective.de/kontakt ECTIVE CSI Pro Inverter | Troubleshooting...
-
Page 35: Technical Specifications
11,0 ± 0,2V only with shore power) Return after undervoltage 14,2 ± 0,2V Working temperature -15 °C to 40 °C Storage temperature -40 °C to 85 °C Relative humidity 20 % to 90 % ECTIVE CSI Pro Inverter | Technical Specifications... -
Page 36: The Csi Pro In The Ective Eco System
The CSI PRO in the ECTIVE Eco System The inverters in the ECTIVE CSI PRO series fit perfectly into the ECTIVE ecosystem, as they are compa- tible with batteries of all technologies. As a powerful charge controller is installed directly, no external battery charger is required to charge supply batteries with shore power. - Page 37 ECTIVE adjust their input voltage so that the solar system always delivers maximum power. Supplement your mobile power supply with a charge controller from the ECTIVE SC, ECTIVE DSC or ECTIVE SC PRO series to utilise solar power and be truly independent:...
-
Page 38: Service And Complaints
Please enclose the following with the return shipment: Copy of the invoice ■ (Service Form) ■ ■ Reason for return An exact and detailed error description ■ ECTIVE CSI Pro Inverter | Service and Complaints... -
Page 39: Warranty
Naturally, the inverters in the TSI PRO series are also covered by this voluntary warranty - with a validity period of three years after purchase! You can find more detailed information on the warranty conditions in the support area for ECTIVE PRO inverters: ective.de/mediafiles/Datenblatt/ective/Inverter-2024/Herstellergarantie-ECTIVE-Wechselrichter-Pro.pdf... -
Page 40: Stay In Touch
Our goal is to make your life easier with our ECTIVE products. No matter if you are on the road with your camper, your boat or just your backpack. No matter if it‘s a trip, a festival or a professional photo shoot: You should be able to fully concentrate on your adventure or project.
