- Page 1 POWER INVERTER WITH PURE SINE WAVE SSI PRO Series Installation and Operating Instructions...
-
Page 2: Table Of Contents
1. First familiarise yourself with the safety instructions on p. 2. 2. Install the ECTIVE SSI PRO inverter in accordance with the instructions on p. 7. 3. Ensure that the inverter is switched off, connect your supply battery and, if necessary, other power sources such as shore power or solar panels, taking into account the instructions in the ‘Connec-... -
Page 3: Welcome
Thank you for choosing an ECTIVE SSI PRO inverter! Devices in the SSI PRO series are the absolute top class of the ECTIVE inverter range. They provide high- quality alternating current with a pure sine wave, which can also be used to operate sophisticated and complex electronic loads: Power just like from a 230 V earthed socket at home - anytime and anywhere. -
Page 4: Scope Of Delivery
Scope of Delivery Products in the ECTIVE SSI PRO series include the following elements. Please check that the scope of delivery is complete before installation and commissioning: ■ 1 × ECTIVE SSI PRO-Inverter High-quality inverter with integrated IUoU charger, MPPT solar charge controller, Please refer to the list below for the technical details of your model. - Page 5 Observe the maximum total output of the connected loads. Some loads require a short-term ■ starting current at start-up, which can be significantly higher than the regular operating current. For this purpose, ECTIVE SSI PRO inverters can supply 150 % power for 10 seconds or 200 % power for 2 seconds. ■...
-
Page 6: Product Overview
Product Overview Regardless of which model of the ECTIVE SSI PRO series you have chosen, the connections and opera- ting elements are arranged according to the following overview. Please observe the technical specifica- tions and performance values applicable to your model when using it. - Page 7 ECTIVE SSI Pro Inverter | Product Overview...
- Page 8 Fault: An error has occurred (see p. 27) ABS: Residual charge (absorption) AC-In: Shore power is present Bulk: Main charge By-Pass: Mains priority circuit 13. Wake up: Reactivation of the battery after blocking by BMS (only for LiFePO ECTIVE SSI Pro Inverter | Product Overview...
-
Page 9: Installation
Installation Please observe the following installation instructions when installing your ECTIVE SSI PRO inverter: ■ Disconnect the inverter from the power supply before installing or working on the device. Never open the housing of the inverter. ■ Only mount or screw the inverter to solid mounting surfaces. - Page 10 The inverter can be mounted both horizontally and vertically. Minimum distance for sufficient ventilation The distance between ventilation elements and the nearest surface must be at least 10 cm. Ventilation slots and fans must not be covered. ECTIVE SSI Pro Inverter | Installation...
- Page 11 When installing in confined spaces, observe the minimum distance of 10 cm in front of the ventilation elements! ECTIVE SSI 10 PRO ECTIVE SSI 15 PRO ECTIVE SSI 20 PRO ECTIVE SSI 25 PRO ECTIVE SSI 30 PRO 6 mm Protruding connections Mounting panel ECTIVE SSI Pro Inverter | Installation...
-
Page 12: Connections And Commissioning
In addition, all instructions in the ‘Safety instructions’ section must be followed to ensure safe operation. Inverters of the ECTIVE SSI PRO series are intended exclusively for use in stand-alone, so-called ■ ‘off-grid’ areas. Never connect an AC voltage source to the 230 V output of the inverter (earthed socket)! Such a connection poses a risk to life as well as immediate and irreparable damage to the inverter. - Page 13 SSI 10, SSI 15: M8 SSI 20, SSI 25, SSI 30: M10 Using the connections Solar Panel 230 V Supply Battery Consumer Small Device (USB) RC PRO Remote Control AC Consumers Shore Power ECTIVE SSI Pro Inverter | Connections and Commissioning...
- Page 14 12 V batteries! In the following example, three ECTIVE LC 100 LiFePO4 batteries with a capacity of 100 Ah each were connected in parallel. The total capacity is 300 Ah and is therefore sufficient to operate an SSI 30 PRO as intended.
- Page 15 Personal protection in the TN network Inverters from the ECTIVE PRO series provide a so-called TN grid. This is an ‘earthed system’ - the neutral point of the system is directly earthed via the operating earth electrode and all bodies of the individual loads are connected to the operating earth electrode (PE).
-
Page 16: Operation
Integrated protective circuits, durable power electronics and intelligent microprocessor control of the ECTIVE SSI PRO inverters guarantee a high overload capacity. This means you can also use loads with high starting currents or short-term high peak consumption safely and without restrictions: ■... - Page 17 ECO Mode (Battery Priority) and UPS Mode (Mains Priority) Inverters in the ECTIVE SSI PRO series can be operated in ECO mode or in UPS mode. In ECO mode (battery priority), the inverter supplies the loads with power from the connected battery, even if the system is connected to shore power.
- Page 18 Disconnect the battery from the inverter by disconnecting the connecting cables or using a circuit ■ breaker to prevent deep discharge of the battery. Store the inverter out of the reach of children in a dry place, protected from direct sunlight. ■ ECTIVE SSI Pro Inverter | Operation...
-
Page 19: Battery And Solar Charger
Battery and Solar Charger Inverters in the ECTIVE SSI PRO series have an integrated battery charger with IUoU charging characteristic and an advanced MPPT solar charge controller. Integrated Battery Charger The right charging process for all battery technologies: In addition to standard wet batteries, the integrated multi-stage charger is also suitable for AGM, gel and LiFePo4 batteries (with BMS). - Page 20 100 % by pulse charging. In this way, it is constantly kept between 95 % and 100 % state of charge. Charge voltage 100 % Charge current 10 % Main Charge Residual Charge Float Charge (constant current) (constant voltage) ECTIVE SSI Pro Inverter | Battery and Solar Charger...
- Page 21 Useful accessories not included in scope of delivery. With the ECTIVE RC PRO remote control, you always have many relevant values of your system in view and can conveniently choose between ECO, UPS mode and pure inverter operation at any time.
- Page 22 (Float Charge) LiFePO 14,6 V 14,8 V 13,8 V Calcium 15,0 V 13,8 V 14,6 V 13,4 V 14,4 V 13,4 V 14,2 V 13,2 V Constant Voltage 13,8 V 12,0 V ECTIVE SSI Pro Inverter | Battery and Solar Charger...
-
Page 23: Eco And Ups Mode
10.2 V), both power sources are charged simultaneously in order to prevent damage to the batteries as quickly as possible. Simultaneous charging takes place until a battery voltage of 14.2 V is reached. ECTIVE SSI Pro Inverter | ECO and UPS Modes... - Page 24 Graphical Representation of the Scenarios Szenario in UPS Mode Shore Power Bypass Function Inverter Function Battery Voltage 11 V 10.5 V Charge Current Solar Power night Battery Charger Phase T2 T3 T4 T5 T8 T9 ECTIVE SSI Pro Inverter | ECO and UPS Modes...
- Page 25 Solar power available ■ No shore power ■ No solar power ■ Device is Turned Off Operating Conditions AC Charger By-Pass Inverter Solar Charger ■ No shore power No solar power ■ ECTIVE SSI Pro Inverter | ECO and UPS Modes...
- Page 26 *For technical reasons, the ‘UPS’ LED may also shimmer slightly green depending on the lighting conditions. When the battery is charging, the ‘Power’ LED and the corresponding charging phase LED also light up. Please refer to the explanations in the section ‘Battery and Solar Charger’. ECTIVE SSI Pro Inverter | ECO and UPS Modes...
- Page 27 *For technical reasons, the ‘UPS’ LED may also shimmer slightly green depending on the lighting conditions. When the battery is charging, the ‘Power’ LED and the corresponding charging phase LED also light up. Please refer to the explanations in the section ‘Battery and Solar Charger’. ECTIVE SSI Pro Inverter | ECO and UPS Modes...
-
Page 28: Safety Features
Safety Features The following safety functions of the ECTIVE TSI PRO inverters protect the user, devices and battery during operation. ■ Overvoltage and Undervoltage Protection ■ Overheating Protection Switches the inverter off automatically if Switches the inverter off immediately at the set values are exceeded or undercut, internal temperatures above 75 °C. - Page 29 ‘Fault’ In the event of an error, observe the LED and the acoustic signal to identify the problem. Rectify the fault as quickly as possible by following the instructions in the ‘Troubleshooting’ section. ECTIVE SSI Pro Inverter | Safety Features...
-
Page 30: Troubleshooting
Possibility A: The connection to the loads has been broken. Check the connection between the inverter and the connected loads. ■ Possibility B: There is a short circuit on the loads. ■ Check the connected loads for short circuits. ECTIVE SSI Pro Inverter | Troubleshooting... - Page 31 Ensure that the inverter can cool down. CHARGER: The charger is not working The input voltage is outside the required minimum or maximum values. Use a power source with the correct voltage and frequency. ■ ECTIVE SSI Pro Inverter | Troubleshooting...
- Page 32 If none of the other solutions solve the problem, please contact our customer service. ■ Any questions? If you encounter problems that you cannot solve yourself, please contact our customer service. They will provide you with qualified help! ective.de/kontakt ECTIVE SSI Pro Inverter | Troubleshooting...
-
Page 33: Technical Specifications
11,0 ± 0,2V only with shore power) Return after undervoltage 14,2 ± 0,2V Working temperature -15 °C to 40 °C Storage temperature -40 °C to 85 °C Relative humidity 20 % to 90 % ECTIVE SSI Pro Inverter | Technical Specifications... -
Page 34: The Ssi Pro In The Ective Eco System
By the way: the modern ECTIVE RC PRO remote control can be used for convenient operation and monitoring of the relevant values. Would you like to add the right ECTIVE components to your system? We have put together a few sugge- stions here! Find out more at ective.de! - Page 35 ECTIVE LC Slim BT ECTIVE Solar Panels ECTIVE PRO inverters support solar panels up to 600 W and are therefore compatible with the entire ECTIVE solar panel range. Whether lightweight, flexible or portable for absolute independence: ECTIVE has the right solar panel series for every application.
-
Page 36: Service And Complaints
Please enclose the following with the return shipment: Copy of the invoice ■ (Service Form) ■ ■ Reason for return An exact and detailed error description ■ ECTIVE SSI Pro Inverter | Service and Complaints... -
Page 37: Warranty
Naturally, the inverters in the TSI PRO series are also covered by this voluntary warranty - with a validity period of three years after purchase! You can find more detailed information on the warranty conditions in the support area for ECTIVE PRO inverters: ective.de/mediafiles/Datenblatt/ective/Inverter-2024/Herstellergarantie-ECTIVE-Wechselrichter-Pro.pdf... -
Page 38: Stay In Touch
Our goal is to make your life easier with our ECTIVE products. No matter if you are on the road with your camper, your boat or just your backpack. No matter if it‘s a trip, a festival or a professional photo shoot: You should be able to fully concentrate on your adventure or project.
