- Page 1 POWER INVERTER WITH PURE SINE WAVE TSI PRO Series Installation and Operating Instructions...
-
Page 2: Table Of Contents
1. First familiarise yourself with the safety instructions on p. 2. 2. Install the ECTIVE TSI PRO inverter in accordance with the instructions on p. 9. 3. Ensure that the inverter is switched off, connect your supply battery and, if necessary, the shore power, taking into account the instructions in the ‘Connections and commissioning’... - Page 3 TSI PRO inverters are of course compatible with all ECTIVE batteries and, in addition to conventional wet batteries, also support advanced batteries with AGM, gel or lithium batteries. With practical func-...
-
Page 4: Scope Of Delivery
Scope of Delivery Products in the ECTIVE TSI PRO series include the following elements. Please check that the scope of delivery is complete before installation and commissioning: ■ 1 × ECTIVE TSI PRO Inverter High-quality inverter with grid priority circuit. Please refer to the list below for the technical details of your model. - Page 5 Observe the maximum total output of the connected loads. Some loads require a short-term ■ starting current at start-up, which can be significantly higher than the regular operating current. For this purpose, ECTIVE TSI PRO inverters can supply 150 % power for 10 seconds or 200 % power for 2 seconds. ■...
-
Page 6: Product Overview
Product Overview Regardless of which model of the ECTIVE TSI PRO series you have chosen, the connections and opera- ting elements are arranged according to the following overview. Please observe the technical specifica- tions and performance values applicable to your model when using it. - Page 7 Connections and operating elements (TSI 10 PRO, TSI 15 PRO, TSI 20 PRO) Connections and operating elements (TSI 25 PRO, TSI 30 PRO) ECTIVE TSI Pro Inverter | Product Overview...
- Page 8 Connections and operating elements (TSI 10 PRO, TSI 15 PRO, TSI 20 PRO) Plug for shore power connection Status LEDs (see next page) 230 V socket Connection for remote control Residual current circuit breaker with USB port overcurrent protection Protective earthing Main switch: On/Off/ECO/UPS mode ECTIVE TSI Pro Inverter | Product Overview...
- Page 9 Residual current circuit breaker with Connection for remote control overcurrent protection USB port 230 V socket AC power output Main switch: On/Off/ECO/UPS mode Shore power connection Status LEDs (see next page) Protective earthing ECTIVE TSI Pro Inverter | Product Overview...
- Page 10 Useful accessories not included in scope of delivery. With the ECTIVE RC PRO remote control, you always have many relevant values of your system in view and can conveniently choose between ECO, UPS mode and pure inverter operation at any time.
-
Page 11: Installation
Installation Please observe the following installation instructions when installing your ECTIVE TSI PRO inverter: ■ Disconnect the inverter from the power supply before installing or working on the device. Never open the housing of the inverter. ■ Only mount or screw the inverter to solid mounting surfaces. - Page 12 The inverter can be mounted both horizontally and vertically. Minimum distance for sufficient ventilation The distance between ventilation elements and the nearest surface must be at least 10 cm. Ventilation slots and fans must not be covered. ECTIVE TSI Pro Inverter | Installation...
- Page 13 When installing in confined spaces, observe the minimum distance of 10 cm in front of the ventilation elements! ECTIVE TSI 10 PRO ECTIVE TSI 15 PRO ECTIVE TSI 20 PRO ECTIVE TSI 25 PRO ECTIVE TSI 30 PRO 6 mm Protruding connections Mounting panel ECTIVE TSI Pro Inverter | Installation...
-
Page 14: Connections And Commissioning
In addition, all instructions in the ‘Safety instructions’ section must be followed to ensure safe operation. Inverters of the ECTIVE TSI PRO series are intended exclusively for use in stand-alone, so-called ■ ‘off-grid’ areas. Never connect an AC voltage source to the 230 V output of the inverter (earthed socket)! Such a connection poses a risk to life as well as immediate and irreparable damage to the inverter. - Page 15 Fuse Fuse Supply Supply Battery Battery Small Device (USB) RC PRO Remote Control Small Device (USB) Shore Power 230 V Consumer 230 V Shore RC PRO Consumer AC Consumers Power Remote Control ECTIVE TSI Pro Inverter | Connections and Commissioning...
- Page 16 12 V batteries! In the following example, three ECTIVE LC 100 LiFePO4 batteries with a capacity of 100 Ah each were connected in parallel. The total capacity is 300 Ah and is therefore sufficient to operate a TSI 30 PRO as intended.
- Page 17 Personal protection in the TN network Inverters from the ECTIVE PRO series provide a so-called TN grid. This is an ‘earthed system’ - the neutral point of the system is directly earthed via the operating earth electrode and all bodies of the individual loads are connected to the operating earth electrode (PE).
-
Page 18: Operation
Integrated protective circuits, durable power electronics and intelligent microprocessor control of the ECTIVE TSI PRO inverters guarantee a high overload capacity. This means you can also use loads with high starting currents or short-term high peak consumption safely and without restrictions: ■... - Page 19 ECO Mode (Battery Priority) and UPS Mode (Mains Priority) Inverters in the ECTIVE TSI PRO series can be operated in ECO mode or UPS mode. In ECO mode (battery priority), the inverter supplies the loads with power from the connected battery, even if the system is connected to shore power.
- Page 20 Disconnect the battery from the inverter by disconnecting the connecting cables or using a circuit ■ breaker to prevent deep discharge of the battery. Store the inverter out of the reach of children in a dry place, protected from direct sunlight. ■ ECTIVE TSI Pro Inverter | Operation...
-
Page 21: Eco And Ups Mode
If the shore power connection is disconnected a second time, the inverter switches back to inverter mode. The batteries are emergency discharged to a battery voltage of 10.2 V. If the battery voltage falls below this threshold, the batteries are no longer supplied with power. ECTIVE TSI Pro Inverter | ECO and UPS Modes... - Page 22 Graphical Representation of the Scenarios Szenario in UPS Mode Shore Power Bypass Function Inverter Function Battery Voltage 11 V 10.5 V Phase T2 T3 T4 T5 T8 T9 ECTIVE TSI Pro Inverter | ECO and UPS Modes...
- Page 23 ECO mode UPS Mode (Mains Priority) Operating Conditions By-Pass Inverter Shore power available ■ No shore power ■ Device is Turned Off Operating Conditions By-Pass Inverter No shore power ■ ECTIVE TSI Pro Inverter | ECO and UPS Modes...
- Page 24 Inverter: Device turns DC power from the battery into AC power for the consumers. AC-In: Shore power is available. *For technical reasons, the ‘UPS’ LED may also shimmer slightly green depending on the lighting conditions. ECTIVE TSI Pro Inverter | ECO and UPS Modes...
- Page 25 AC-In: Shore power is available. By-Pass: Shore power is directly passed through to the 230 V consumers. *For technical reasons, the ‘UPS’ LED may also shimmer slightly green depending on the lighting conditions. ECTIVE TSI Pro Inverter | ECO and UPS Modes...
-
Page 26: Safety Features
Safety Features The following safety functions of the ECTIVE TSI PRO inverters protect the user, devices and battery during operation. ■ Overvoltage and Undervoltage Protection ■ Overheating Protection Switches the inverter off automatically if Switches the inverter off immediately at the set values are exceeded or undercut, internal temperatures above 75 °C. - Page 27 ‘Fault’ In the event of an error, observe the LED and the acoustic signal to identify the problem. Rectify the fault as quickly as possible by following the instructions in the ‘Troubleshooting’ section. ECTIVE TSI Pro Inverter | Safety Features...
-
Page 28: Troubleshooting
Possibility A: The connection to the loads has been broken. Check the connection between the inverter and the connected loads. ■ Possibility B: There is a short circuit on the loads. ■ Check the connected loads for short circuits. ECTIVE TSI Pro Inverter | Troubleshooting... - Page 29 Switch off the inverter temporarily. Ensure that the inverter can cool down. Any questions? If you encounter problems that you cannot solve yourself, please contact our customer service. They will provide you with qualified help! ective.de/kontakt ECTIVE TSI Pro Inverter | Troubleshooting...
-
Page 30: Technical Specifications
11,0 ± 0,2V only with shore power) Return after undervoltage 14,2 ± 0,2V Working temperature -15 °C to 40 °C Storage temperature -40 °C to 85 °C Relative humidity 20 % to 90 % ECTIVE TSI Pro Inverter | Technical Specifications... -
Page 31: The Tsi Pro In The Ective Eco System
The TSI PRO in the ECTIVE Eco System The inverters in the ECTIVE TSI PRO series fit perfectly into the ECTIVE ecosystem, as they are compa- tible with batteries of all technologies. With an additional battery charger, these batteries can be charged directly using shore power. - Page 32 ECTIVE adjust their input voltage so that the solar system always delivers maximum power. Supplement your mobile power supply with a charge controller from the ECTIVE SC, ECTIVE DSC or ECTIVE SC PRO series to utilise solar power and be truly independent:...
-
Page 33: Service And Complaints
Please enclose the following with the return shipment: Copy of the invoice ■ (Service Form) ■ ■ Reason for return An exact and detailed error description ■ ECTIVE TSI Pro Inverter | Service and Complaints... -
Page 34: Warranty
ECTIVE batteries, solar panels and inverters in addition to the statutory warranty. Naturally, the inverters in the TSI PRO series are also covered by this voluntary warranty - with a validity period of three years after purchase! -
Page 35: Stay In Touch
Our goal is to make your life easier with our ECTIVE products. No matter if you are on the road with your camper, your boat or just your backpack. No matter if it‘s a trip, a festival or a professional photo shoot: You should be able to fully concentrate on your adventure or project.
