Hardware Installation
Install two AAA rechargeable batteries in the mouse and two AAA rechargeable
1.
batteries in the keyboard.
2.
You can connect the receiver to a USB port of a
3.
Turn on your computer.
Software Installation
1. Make sure the mouse and keyboard is connected to the computer.
2. Put the Setup disk (or CD) into the disk drive.
3. Follow the instructions on the screen to finish the software installation.
Replace Batteries
If you feel the mouse does not move smooth as usual or the keyboard does not work
when typing, then the batteries have lost their charge, so please replace them.
Furthermore, do not mix or use different types of batteries at the same time. You
should set up the channel every time you replace the batterires.
ID channel setting
The channel buttons are factory preset. The green LED, the data transmission indica-
tor, on the receiver will be lit when the keyboard or mouse is in normal operation. If
your keyboard/mouse does not work, then you have to set the ID channel setting.
Please press the button on the receiver first (RB) and press the button under the
mouse (MB) and the keyboard (KB) within twenty seconds. So you press RB, MB
and KB to set the channel setting.
Charging
If you need to buy new batteries to recharge, please choose two Ni-MH
(Nickel-Metal-Hydride) AA rechargeable batteries, 1.2V, 1300 to 1600 mAH or AAA
rechargeable batteries, 1.2V, 600 to 800 mAH. Please do not mix or use other types
of batteries in the battery charger such as Li-ion, Ni-Cd, Alkaline, etc. The red LED
on the receiver shows the battery-recharging status (from LED completely "on" to
"off" for battery full).
PC.
1
Advertisement
Table of Contents
Related Manuals for Genius 19ENB
Summary of Contents for Genius 19ENB
-
Page 1: Hardware Installation
3. Follow the instructions on the screen to finish the software installation. Replace Batteries If you feel the mouse does not move smooth as usual or the keyboard does not work when typing, then the batteries have lost their charge, so please replace them. -
Page 2: Button Assignments
USB connector into the PC directly and remember do not put the batteries in the wrong direction, use the same types of batteries, and do not recharge via the USB hub, that will make your receiver, main-board and hub burn or become non-usable easily. - Page 3 Provides traditional mouse functions such as click, double click and drag. Right Button You can assign this button frequently used keyboard and mouse func- tions in addition to features like EasyJump, Auto-Panning, Zoom, etc. Roller ButtonYou can assign this button frequently used keyboard and mouse func- tions in addition to features like EasyJump, Auto-Panning, Zoom, etc.
- Page 4 Click this function and the pan icon appears. You can move the mouse in any direction in a document or a spreadsheet. The farther you move the pointer from the pan icon, the faster you can pan in that direction. Click this function and Office EasyJump Frisbee will always be on the screen and the button will change to .
- Page 5 Note: All the functions related to Office applications are programmable. Place the cursor on the function icon you want to change, and click the right button to select or reset the unit from the pop-up menu. From the dialog box, you can choose another function to use in the EasyJump Frisbee.
- Page 6 Press the “Ctrl” key and move the “Magic-Roller” forward (or backward) to set the Zoom In/Out function. You can also use just one hand to Zoom In/Out: set the right button to be the “Ctrl” function, press the right button and move the “Magic-Roller”...
- Page 7 Customize the Software This section shows you how to customize the software. To open the software control panel, you can double-click on the icon in the task bar or select the “Software” icon from the program group. Close the Software Click the right button on the taskbar, and select “Close Software”...
