Mounting & Installation
1) Remove the thermostat from its packaging.
2) Choose a mounting location so that the thermostat can
measure the temperature as accurately as possible.
- Choose a mounting location for the temperature probe as
per the instructions on Page 8.
- Prevent direct exposure to sunlight or other heating /
cooling sources.
3) Press and hold the release button on the bottom of the
thermostat to detach the front housing from the base plate.
4) Insert the 2 x AAA batteries provided and the thermostat
will turn on.
5) Plug the temperature sensor into the connector on the PCB.
6) Fix the base plate directly to the wall with the screws provided.
Attached the front housing to the base plate.
