INSTALLATION and USER'S MANUAL
Stella Table Manual
G30/G31 (Propane-Butane/Propane)
D
H
H1
H2
D
D1
D2
[mm]
383
360
23
941
862
366
Copyright Planika Sp. z o.o.
www.planikafires.com
IG0370#00
17.04.2024
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stella Table and is the answer not in the manual?

Questions and answers

Summary of Contents for Planika Stella Table

  • Page 1 INSTALLATION and USER’S MANUAL Stella Table Manual G30/G31 (Propane-Butane/Propane) [mm] Copyright Planika Sp. z o.o. www.planikafires.com IG0370#00 17.04.2024...
  • Page 2: Table Of Contents

    T IS OBLIGATORY TO READ AND KEEP THIS INSTRUCTION MANUAL TABLE OF CONTENTS INTRODUCTION ................................. 3 SAFETY INSTRUCTIONS .............................. 4 Safety instruction regarding the use of the gas cylinders................. 5 INSTALLATION ................................5 3.1. Box contents ..............................5 3.2. Unboxing and installation ..........................
  • Page 3: Introduction

    INTRODUCTION The Stella Table Manual is a decorative fuel-effect gas appliances destined only for outdoor use. It is obligatory to acquaint oneself with the below installation manual and user’s manual before committing to the installation and use of the Stella Table Manual.
  • Page 4: Safety Instructions

    When not being used the Stella Table Manual is to be protected from atmospheric conditions and the main valve of the gas cylinder needs to be turned off. • If the Stella Table Manual is not in use for a longer period of time (e.g. winter time), we advise you to store it inside. •...
  • Page 5: Safety Instruction Regarding The Use Of The Gas Cylinders

    • In case of heavy wind the Stella Table Manual needs to be immediately turned off and one needs to await until the heavy wind passes. • In case of noticing any sort of gas leaks the fireplace as well as the main valve of the gas cylinder need to be turned off.
  • Page 6: Unboxing And Installation

    • Place Stella Table Manual on a flat, paved surface outside of the building, preferably on the place of final installation. Leave sufficient space on the side of the appliance where control panel is located (minimum 1 m).
  • Page 7: Gas Cylinder Montage (Only Lpg Version)

    3.5.1. Connection and replacement of the gas cylinder (LPG version) The Stella Table Manual is delivered together with an elastic gas linkage which, on one end is connected to the valve of the device and on the other end to the 37mbar regulator (in the twist-on version) ready to be connected to the gas cylinder.
  • Page 8 place while others require the use of a wrench. Tighten securely (left thread). Using the tool pay attention not to fasten the connection too tightly as this may damage the seal. • Quick-release: For this type of connection no tool is required. On/off regulation of gas connection is made through a switch on the regulator or on a special connector.
  • Page 9 Disconnection of the gas cylinder Twist-on connection Quick-release Turn off the Stella Table Manual – put it into the OFF position. The main and pilot burner need to be turned off. 2. Turn the bottle valve into the OFF position 2.
  • Page 10: Regulator Replacement (Lpg Version)

    3.5.3. Regulator replacement (LPG version) 1. You always need to use a pressure regulator between the gas bottle and the device. Replace the pressure regulator every 5 years. Allowed pressures: 30 mbar, 37 mbar (recommended), 50 mbar. Use only the regulators that comply with the EN16129 European Norm.
  • Page 11: Operating Instructions

    4. OPERATING INSTRUCTIONS Stella Table Manual fireplace has a control valve with a built-in ignition for the main burner (without pilot flame). The flame height of the main burner may be appropriately regulated with by turning the knob. Next to the knob is placed electric ignition button (powered by AAA battery).
  • Page 12: Regulation Of The Flame Size

    4.2. Regulation of the flame size • When the flame is burning the desired height of the flame may be adjusted and regulated by turning the knob clockwise or counter-clockwise. • To achieve a higher flame turn the knob counter-clockwise to “Hi” position. To achieve a lower flame turn the knob clockwise to “Lo”...
  • Page 13: Testing

    If the problem happens again please contact the dealer. 5.2. Checking the flame appearance. • Burn the Stella Table Manual on max flame height and check the appearance of the flame. • The flame should be linear and evenly placed on the whole length of the main burner.
  • Page 14: Troubleshooting

    7. TROUBLESHOOTING Warning! Montage, upkeep and service need to be conducted by a qualified professional with appropriate qualification, an appropriate company or the gas supplier. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION CLOSE THE VALVE ON THE GAS CYLINDER IMMEDIATELY. DO NOT USE THE DEVICE UNTIL LEAKS SMELL OF GAS HAVE BEEN REMOVED.
  • Page 15: Warranty

    9. WARRANTY Planika Sp. z o.o. grants the Client guarantee of quality for the smooth operation of the goods specified on the sales document. The warranty is determined for a given period from the date of purchase (based on the warranty card together with the receipt of purchase).
  • Page 16 SELLER Name: Address: Tel/fax: Date of sale: Seller’s seal and signature BUYER Name: Address: Tel/fax: Date of purchase: The gas fireplace should be installed by a qualified Installer in accordance with the applicable national building regulations and in accordance with the guidelines contained in the Installation and User's Manuals. I hereby declare that having read the User's Manual and the Guarantee Conditions.
