X58 Extreme
®
Intel
X58+ ICH10R Chipsets
EuP
EuP
Ready
Product Brief
Worldwide First EuP Ready Motherboard!
- System Bus up to 6400 MT/s; Intel
QuickPath Interconnect
- Triple Channel DDR3 2000 (OC) with 6 DIMM
slots
- 3 x PCI Express 2.0 x 16 slots
(Double-wide slot spacing between each
PCI-E slot)
- 1 x Power eSATA/USB connector
®
- NVIDIA
Quad SLI™ and SLI™
- ATI™ CrossFireX™, 3-Way CrossFireX™
and Quad CrossFireX™
- 7.1 CH, ALC890 Audio Codec
- Smart Switch Design
- Dr. Debug
- TPM support
- ASRock Instant Boot, Instant Flash,
Smart BIOS, ASRock OC Tuner,
Intelligent Energy Saver
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
Detail Specification
Platform
CPU
Chipset
Memory
Expansion Slot
Audio
LAN
Rear Panel I/O
Connector
®
Smart Switch
BIOS Feature
Support CD
Unique Feature
Hardware Monitor
OS
Certifications
Accessories
ww w. a s ro ck. c om
- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
- All Solid Capacitor design (100% Japan-made high-
quality Conductive Polymer Capacitors)
- Intel
®
Socket 1366 Core™ i7 Processor Extreme Edition /
Core™ i7 Processor Supports Intel
®
Technology
®
- System Bus up to 6400 MT/s; Intel
Interconnect
- Advanced V8 Power Phase Design
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
- Northbridge: Intel
®
X58
- Southbridge: Intel
®
ICH10R
- Dual Channel DDR3 memory technology
- 6 x DDR3 DIMM slots
- Supports DDR3 2000(OC)/1866(OC)/1600(OC)/1333
(OC)/1066 non-ECC, un-buffered memory
- Supports DDR3 ECC, un-buffered memory with Intel
®
Workstation 1S Xeon
processors 3500 series
- Max. capacity of system memory: 24GB
- Supports Intel
®
Extreme Memory Profile (XMP)
- 3 x PCI Express 2.0 x16 slots (blue @ x16 mode, orange
@ x4 mode) (Double-wide slot spacing between each
PCI-E slot)
- 2 x PCI Express x1 slots
- 2 x PCI slots
- Supports ATI
TM
CrossFireX
TM
, 3-Way CrossFireX
TM
Quad CrossFireX
®
TM
- Supports NVIDIA
SLI
and Quad SLI
- 7.1 CH Windows
®
Vista™ Premium Level HD Audio with
Content Protection
- DAC with 110dB dynamic range (ALC890 Audio Codec)
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Coaxial SPDIF Out Port
- 1 x Optical SPDIF Out Port
- 7 x Ready-to-Use USB 2.0 Ports
- 1 x Powered eSATAII/USB Connector
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- 1 x IEEE 1394 Port
- 1 x Clear CMOS Switch
- HD Audio Jack: Side Speaker / Rear Speaker / Central /
Bass / Line in / Front Speaker / Microphone
- 6 x SATAII 3.0 Gb/s connectors, support RAID (RAID 0,
RAID 1, RAID 10, RAID 5 and Intel
®
Matrix Storage), NCQ,
AHCI and Hot Plug functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x COM port header
- 1 x HDMI_SPDIF header
- 1 x IEEE 1394 header
- 1 x TPM header
- CPU/Chassis/NB/Power FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 1 x Power Switch
- 1 x Reset Switch
- 1 x Clear CMOS Switch
- 8Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU, DRAM, NB, SB,VTT Voltage Multi-adjustment
- Supports I. O. T. (Intelligent Overclocking Technology)
- Supports Smart BIOS
- Drivers, Utilities, AntiVirus Software (Trial Version)
- ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU/Chassis/NB/Power Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
®
®
- Microsoft
Windows
XP / XP 64-bit / Vista
64-bit compliant
- FCC, CE, WHQL
- 1 x ASRock SLI_Bridge_2S Card
- Quick Installation Guide, Support CD, I/O Shield
- Floppy/ATA 133 Cables
- 4 x SATA Data Cables (Optional)
- 2 x SATA 1 to 1 Power Cables (Optional)
Dynamic Speed
QuickPath
®
TM
and
TM
TM
TM
/ Vista
