NOTE: Do not use power tools for assembly. Power tools increase the risk of over tightening which leads to splitting or cracking
the wood.
COMPONENT LIST (CHAIR)
NO.
A
B
HARDWARE LIST
NO.
1
2
3
Assembly Instruction
LSF POWER RECLINING CHAIR W/
POWER HEADREST,USB PORT
ITEM NO.: 9509MGY/DG-LRPWH
DRAWING
DRAWING
QTY
DESCRIPTION
BACK REST
1 PC
SEAT WITH POWER
1 PC
HEADREST WIRE
QTY
DESCRIPTION
1 PC
ADAPTOR
PLUG WITH
1 PC
WIRE
Y-CABLE
1 PC
QP-AI-P022-100-1
1/3
Advertisement
Related Manuals for Homelegance 9509MGY-LRPWH
Summary of Contents for Homelegance 9509MGY-LRPWH
- Page 1 QP-AI-P022-100-1 Assembly Instruction LSF POWER RECLINING CHAIR W/ POWER HEADREST,USB PORT ITEM NO.: 9509MGY/DG-LRPWH NOTE: Do not use power tools for assembly. Power tools increase the risk of over tightening which leads to splitting or cracking the wood. COMPONENT LIST (CHAIR) DRAWING DESCRIPTION BACK REST...
- Page 2 QP-AI-P022-100-1 STEP#1 Align the female brackets at the back rest onto the male brackets at the seat, insert back rest to the seat then push to the end and make sure it is fixed in position securely. Connecting the wire from back rest to seat for power headrest. Back Rest Installation STEP#2...
- Page 3 QP-AI-P022-100-1 STEP#5 Press (Close / Open) Headrest USB Port 5V/1A USB Port 5V/1A Chair Press (Close / Open) Control Switch CARE INSTRUCTION FOR POLYESTER: In order to maintain the original appearance of your polyester furniture, please follow below simple care procedure : Avoid exposing furniture directly to sunlight or heating and air conditioning outlets.
