It is recommended to install protective pads under all legs and supports to avoid damage or scratches when placing furniture on
a wood floor or other hard surface, and to limit indentation and prevent discoloration if placing on carpet.
PARTS LIST
NO.
1
2
3
ASSEMBLY INSTRUCTIONS
Convertible Studio Sofa with pull-out bed
DRAWING
9525RF-3CL
QTY
1 PC
2 PC S
2 PCS
Page: 1/3
DESCRIPTION
Seat Frame
Arm
Back Cushion
Advertisement
Related Manuals for Homelegance Hancock 9525RF-3CL
Summary of Contents for Homelegance Hancock 9525RF-3CL
- Page 1 ASSEMBLY INSTRUCTIONS 9525RF-3CL Convertible Studio Sofa with pull-out bed It is recommended to install protective pads under all legs and supports to avoid damage or scratches when placing furniture on a wood floor or other hard surface, and to limit indentation and prevent discoloration if placing on carpet. PARTS LIST DESCRIPTION DRAWING...
- Page 2 STEP 1 : STEP 2 : Place Back Cushion (3) to the Back Rest as shown . Align brackets on the arms (2) to each side of the seat frame (1) and push down to connect. STEP 3 : Use as Bed Step 3.2: Step 3.1: Lift up the pull out bed cushion as shown .
- Page 3 STEP 4 : Use as Sofa Step 4.2: Restore the pull out bed under the seat frame as shown. Step 4.1: Fold the Back Rest to upright position. STEP 5 : Completed. CARE INTRUCTION FOR FABRIC FURNITURE In order to maintain the original appearance of your funiture, please follow below care procedures. Avoid exposing furniture directly to sunlight or heating and air conditioning outlets.
