Homelegance 9630BE/GY-2L Assembly Instruction Manual

Legs and hardware are stored in the box, please
take out for assembly.
NOTE: Do not use power tools for assembly. Power tools increase the risk
of over tightening which lead to splitting or cracking the wood.
2L
M
C
RC
J
ASSEMBLY INSTRUCTION
ITEM NO: 9630BE/GY-2L
Location of KD parts
F
A
B
LEFT SIDE 2-SEATER WITH PULL-OUT BED AND USB PORTS, 2
ARMS WITH SHELVES
9630BE/GY-RC
RIGHT SIDE CHAISE WITH HIDDEN STORAGE, 2-SEATER'S
BACKS AND 2 PILLOWS
BOX
Dx6
Ex4
Ix4
Lx3
Ox12
Nx16
G
G
K
Page 1/7
2-SEATER PART LIST
Description
No.
POP-UP
A
SLEEPER SEAT
RSF ARM
B
(Arm for RC)
C
LSF ARM
ROUND PLASTIC LEG
D
50x50x50mm
E
CASTOR
F
BACK CUSHION LSF
PILLOW 18"x18"
G
(Packed in RC)
BACK REST
H
(Packed in RC)
I
MALE BRACKET
CHAISE PART LIST
No. Description
J
CHAISE SEAT
K
BACK REST
PLASTIC LEG
L 150x50x50mm
(packed in 2L)
BACK CUSHION RSF
M
(packed in 2L)
MALE BRACKET
I
(packed in 2L)
PILLOW 18"x18"
G
ROUND PLASTIC LEG
D
50x50x50mm(packed in 2L)
HARDWARE LIST :
Diagram
No. Description
O
SCREW
Ø8x45MM
N
SCREW
Ø8x25MM
Diagram Quantity
1
1
1
4
4
1
1
1
2
Diagram Quantity
1
1
3
1
2
1
2
Quantity
12
16
Not Included
