Chapter 6 Reinstalling the MXM card
Chapter 6 Reinstalling the MXM card
Chapter 6 Reinstalling the MXM card
Chapter 6 Reinstalling the MXM card
Chapter 6 Reinstalling the MXM card
1. Unscrew the screws of the heatpipe on the MXM card.
2. Use your fingers to pull the outer side of the heatpipe upward.
3. Finally you can take out the heatpipe and change a new MXM card.
1 8
1 8
1 8
1 8
1 8
