Chapter 3 Reinstalling the ODD/HDD
Chapter 3 Reinstalling the ODD/HDD
Chapter 3 Reinstalling the ODD/HDD
Chapter 3 Reinstalling the ODD/HDD
Chapter 3 Reinstalling the ODD/HDD
1. After you remove the top shield, you will see the ODD/HDD bracket.
2. Disconnect the ODD/HDD SATA power cable, and take out the ODD/HDD
bracket.
3. Disconnect all the ODD/HDD SATA power cables inside the chassis.
4. Then you can change the new ODD/HDD to upgrade your system.
1 5
1 5
1 5
1 5
1 5
