- Page 1 XL FRAME Installation, Maintenance, Safety and Usage Instructions Manual ATTENTION! READ ALL SAFETY INFORMATION, INSTALLATION AND USAGE INSTRUCTIONS PRIOR TO INSTALLATION AND USAGE. See growplaymonkeybars.com for step by step video instructions and any updates to these instructions.
-
Page 2: Table Of Contents
General care Retain this Manual. ● Inspect before and after each use. ● Replace any worn, deteriorated, defective or missing parts immediately and only through Growplay. ● Tighten all hardware, including elements that secure the system ● to the ground. -
Page 3: Textile Deterioration
Use general-purpose grease on steel connection areas. ● Avoid cleaning steel components excessively; it may reduce the effectiveness of their protective ● coatings. Textile deterioration Remove textile parts, and store them – in their original packaging – in a cool, dry and dark place when ●... - Page 4 X3.1.1.1 Maintain a minimum depth of 9 inches of loose-fill materials such as wood mulch/chips, ● engineered wood fiber (EWF), or shredded/recycled rubber mulch for equipment up to 8 feet high; and 9 inches of sand or pea gravel for equipment up to 5 feet high. NOTE: An initial fill level of 12 inches will compress to about a 9-inch depth of surfacing over time.
-
Page 5: Due Care When Installing Product
X3.1.5.3 For tire swings, extend surfacing in a circle whose radius is equal to the height of the ● suspending chain or rope, plus 6 feet in all directions. This information has been extracted from the CPSC publications “Playground Surfacing — Technical Information Guide”... -
Page 6: Pre-Assembly And Installation Tips
Pre-assembly and installation tips ASSEMBLY: TWO PERSONS REQUIRED Before starting assembly, please carefully read the following information: Items required for assembly: Ladder, rubber mallet and spanner. ● Two people are required to assemble the frame. ● DO NOT FULLY TIGHTEN BOLTS UNTIL FRAME IS ASSEMBLED. ●... - Page 8 Typical Clamp, Swing Hook and Foot Assembly...
-
Page 10: Boxes And Parts
Boxes and parts DESCRIPTION Quantity Barcode TUBE KIT A1-1 A1-1-B 0794712825562 TUBE KIT A2-1 A2-1 0794712825579 TUBE KIT A3-1 A3-1-B 0794712825586 TUBE KIT A4-1 A4-1 0794712825593 A5-1 0794712825609 TUBE KIT A5-1 TUBE KIT A6-1 A6-1 0794712825616 A7-1 0794712825623 CLAMP KIT A7-1 ACCESSORY KIT B1-1 0794712825630... - Page 11 Box A2-1 Contents Box A3-1-B Contents...
- Page 12 Box A4-1 Contents Box A5-1 Contents Box A6-1 Contents...
- Page 13 Box A7-1 Contents...
- Page 14 Box B1-1 Contents...
-
Page 15: Assembly Instructions
Assembly Instructions... - Page 48 Installing Spiral Ground Anchors...
- Page 49 IMPORTANT: Spiral Ground Anchors are for soft sand and spikes are for hard ground. If spiral anchors break, the ground is too hard and you should use spikes.
- Page 51 and remove allen/hex keys. Repeat anchor process for the other feet indicated above.
