Assembly, Maintenance and User
Instructions Manual
WARNING !
GROWPLAY MONKEYBARS ® PTY. LTD.
READ ALL PRECAUTIONS AND INSTRUCTIONS IN THIS MANUAL
BEFORE USING THIS EQUPIMENT.
ABN : 36 627 796 141
KEEP MANUAL IN A SAFE PLACE FOR FUTURE
REFERENCE. MAXIMUM OCCUPANCY = 10 USERS @ <50KG
Model :GP1-REV 8 2021
TOTAL WEIGHT CAPACITY = 500KG
AGE OF USERS 3+
Advertisement
Table of Contents
Related Manuals for growplay GP1-REV 8 2021
Summary of Contents for growplay GP1-REV 8 2021
- Page 1 Assembly, Maintenance and User Instructions Manual WARNING ! GROWPLAY MONKEYBARS ® PTY. LTD. READ ALL PRECAUTIONS AND INSTRUCTIONS IN THIS MANUAL BEFORE USING THIS EQUPIMENT. ABN : 36 627 796 141 KEEP MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE. MAXIMUM OCCUPANCY = 10 USERS @ <50KG...
-
Page 2: Before You Begin
Thank you for purchasing Growplay Monkey Bars. With regular maintenance, your set will provide many years of backyard fun. Before you start to assemble your new GROWPLAY MONKEY BAR SET please ensure that you have read this important information and that it is communicated to all users prior to use. -
Page 3: Electrocution Hazard
Wear clothing that does not have loops, hooks, drawstrings or anything else that can get caught on the frame. USER INSTRUCTIONS 1. GROWPLAY MONKEY BARS are designed for up to 10 persons and not exceeding total weight of 500kg. AGE OF USERS 3+ 3. - Page 4 ASSEMBLY Before starting assembly, please carefully read the following information. • This frame can be successfully assembled by one person alone, however two people is recommended. • Place all parts in one cleared area and remove the packaging material. Do not throw away material until assembly is complete.
- Page 5 Ensure ground is level and use ground anchor pegs provided to ensure stability.
- Page 6 ASSEMBLY PROCEDURE Take your time. This is how your frame should look by the time you are finished. Top view of finished frame. Note orientation of support bars for best stability.
- Page 7 Frame must be Typical swing hook secured down set up. Place around with ground tube and tighten anchor pegs with provided provided as spanner. Ensure shown (9 pegs that the direction is in total are correct for the provided.) swing to pivot ONE PER FOOT freely.
- Page 8 WARNING! ENSURE THAT THE RED WARNING LOCATOR TAPE CANNOT BE SEEN. IF YOU CANNOT SEE THE RED TAPE THEN THE TUBE IS IN CORRECTLY. ENSURE THAT YOU CHECK AND TIGHTEN EACH CONNECTOR SEVERAL TIMES BEFORE USE. WHEN WE SAY TIGHT WE MEAN AS TIGHT AS YOU CAN POSSIBLY GO.
- Page 9 490MM 490MM Equal spacing. 35mm thk foam slab for commode 4 way clamps Slide main swing bars through top and tighten 490mm from end. Place 3 x 4 way Clamps for shade sail accessory if applicable.
-
Page 12: Maintenance Information
MAINTENANCE INFORMATION This product was manufactured using quality materials and crafted to provide you and your family with many years of enjoyment and exercise. Proper maintenance care will help to prolong the life and reduce the possibility of injury. The following guidelines should be followed.
