Assembly, Maintenance and User
Instructions Manual
WARNING !
GROWPLAY MONKEYBARS ® PTY. LTD.
READ ALL PRECAUTIONS AND INSTRUCTIONS IN THIS MANUAL
BEFORE USING THIS EQUPIMENT.
ABN : 36 627 796 141
KEEP MANUAL IN A SAFE PLACE FOR FUTURE
P.O Box 2527,Clarkson, WA , 6030
REFERENCE.MAXIMUM OCCUPANCY = 10 USERS @ <50KG
Model :GP1-REV 9 2021
TOTAL WEIGHT CAPACITY = 500KG
AGE OF USERS 3+

Advertisement

loading
Need help?

Need help?

Do you have a question about the GP1 and is the answer not in the manual?

Questions and answers

Related Manuals for growplay GP1

Summary of Contents for growplay GP1

  • Page 1 Assembly, Maintenance and User Instructions Manual WARNING ! GROWPLAY MONKEYBARS ® PTY. LTD. READ ALL PRECAUTIONS AND INSTRUCTIONS IN THIS MANUAL BEFORE USING THIS EQUPIMENT. ABN : 36 627 796 141 KEEP MANUAL IN A SAFE PLACE FOR FUTURE P.O Box 2527,Clarkson, WA , 6030 REFERENCE.MAXIMUM OCCUPANCY = 10 USERS @ <50KG...

  • Page 2: Before You Begin

    BEFORE YOU BEGIN Thank you for purchasing a Growplay Monkey bar gym. With regular maintenance, your set will provide many years of backyard fun. Before you start to assemble your new GROWPLAY MONKEY BAR SET please ensure that you have read this important information and that it is communicated to all users prior to use.

  • Page 3: Electrocution Hazard

    ELECTROCUTION HAZARD Growplay monkey bars are made from metal . They are not grounded and will conduct electricity. For obvious reasons and electrocution hazard exists. NO lights , heaters, electrical and extension cords or any household electrical device or appliances are to be permitted on or in the frame at any time.
  • Page 4 ASSEMBLY Before starting assembly , please carefully read the following information. • This frame can be successfully assembled by one person alone, however two people is recommended. • Place all parts in one cleared area and remove the packaging material. Do not throw away material until assembly is complete.
  • Page 5 Ensure ground is level and use ground anchor pegs provided to ensure stability.
  • Page 6 ASSEMBLY PROCUDURE Take your time. This is how your frame should look by the time your finished. Top view of finished frame. Note orientation of support bars for best stability.
  • Page 7 WARNING ! ENSURE THAT THE RED WARNING LOCATOR TAPE CAN NOT BE SEEN. IF YOU CAN NOT SEE THE RED TAPE THEN THE TUBE IS IN CORRECTLY. ENSURE THAT YOU CHECK AND TIGHTEN EACH CONNECTOR SEVERAL TIMES BEFORE USE. WHEN WE SAY TIGHT, WE MEAN AS TIGHT AS YOU CAN POSSIBLY GO.
  • Page 8 REMOVE LADDERS FROM BOX 1 AND BOX 2 • INSTALL SHORT TEES FOR DIP BARS ( LEAVE LOOSE ) ONE SIDE . • INSTALL SHORT TEE CLAMPS AT EQUAL HEIGHTS FOR MONKEY BARS. DO NOT FULLY TIGHTEN UNTIL NEXT STEP. SLIDE ON ADDITIONAL CLAMPS IF ATTACHING MK1800 OR MK2400...
  • Page 9 PLACE LADDERS ON SIDE AND INSERT MONKEY RUNGS ( BOX 3 ) INTO CLAMPS. ENSURE THAT RED TABS ARE NOT SHOWING BEFORE TIGHTENING. BOX 3 STAND FRAME UP AND INSERT DIP BARS INTO CLAMPS AND TIGHTEN ONCE IN POSITION.
  • Page 10 INSTALL TOP TEE CLAMPS LOOSLY AS SHOWN AND PASS THROUGH TOP TUBE. NOTE THIS IS THE 2 X GREAY TUBES WITH NO HEIGHT MARKINGS! MEASURE 600MM TO END OF TUBE . NOTE END CAP POSITION. SLIDE SWING CLAMPS INTO PLACE. 600MM...
  • Page 11 INSTALL BLUE FIREMANS POLE BLACK END CAPS FACING OUTWARDS BOTH ENDS. INSTALL SECOND TOP TUBE AND SWING CLAMPS...
  • Page 12 INSTALL CLAMPS AS SHOWN.
  • Page 13 SET TOP CLAMP HEIGHT 1150MM INSTALL CARGO NET AND CLAMPS AS SHOWN.
  • Page 14 SET TOP CLAMP HEIGHT...
  • Page 15 ATTACH SWING CLAMPS NOW FOR ANY ACCESSORIES! INSERT BLUE CROSS BAR POLE INTO CLAMPS AND TIGHTEN. ATTACH SWING CLAMP FROM ANY ACCESSORY IF REQUIRE AT THIS STAGE.
  • Page 16 INSERT FRAME INTO TOP CLAMPS AND TIGHTEN. ENSURE THAT POLES ARE VERTICAL.
  • Page 17 TYPICAL MONKEY RING FINAL STEP. CHECK AND LOOP ATTACHMENT. LOOP TIGHTEN ALL CONNECTIONS OVER AND UNDER ANY BAR TWICE! POSITION.

  • Page 18: Maintenance Information

    MAINTENANCE INFORMATION This product was manufactured using quality materials and crafted to provide you and your family with many years of enjoyment and exercise. Proper maintenance care will help to prolong the life and reduce the possibility of injury. The following guidelines should be followed.
