COMPACT FRAME FREE STANDING
Assembly, Maintenance and User
Instructions Manual
growplaymonkeybars.com/pages/assembly-installation
WARNING!
GROWPLAY MONKEYBARS ® PTY. LTD.
READ ALL PRECAUTIONS AND INSTRUCTIONS IN THIS MANUAL
BEFORE USING THIS EQUPIMENT.
ABN: 36 627 796 141
KEEP MANUAL IN A SAFE PLACE FOR FUTURE
P.O Box 2527, Clarkson, WA, 6030
TOTAL WEIGHT CAPACITY = 300KG
Model: CP20 – REV 2
AGE OF USERS 3+
Advertisement
Related Manuals for growplay CP20 - REV 2
Summary of Contents for growplay CP20 - REV 2
- Page 1 COMPACT FRAME FREE STANDING Assembly, Maintenance and User Instructions Manual growplaymonkeybars.com/pages/assembly-installation WARNING! GROWPLAY MONKEYBARS ® PTY. LTD. READ ALL PRECAUTIONS AND INSTRUCTIONS IN THIS MANUAL BEFORE USING THIS EQUPIMENT. ABN: 36 627 796 141 KEEP MANUAL IN A SAFE PLACE FOR FUTURE P.O Box 2527, Clarkson, WA, 6030...
-
Page 2: Before You Begin
Thank you for purchasing Growplay Monkey Bars. With regular maintenance, your set will provide many years of backyard fun. Before you start to assemble your new GROWPLAY MONKEY BAR SET please ensure that you have read this important information and that it is communicated to all users prior to use. -
Page 3: For The User
• Wear clothing that does not have loops, hooks, drawstrings, or anything else that can get caught on the frame. USER INSTRUCTIONS 1. GROWPLAY MONKEY BARS are designed for up to 6 persons and not exceeding total weight of 300kg. 2. AGE OF USERS 3+ 3. - Page 4 ASSEMBLY: TWO PERSONS Before starting assembly, please carefully read the following information. • Two people are required to assemble frame. • DO NOT FULLY TIGHTEN BOLTS UNTIL FRAME IS ASSEMBLED. • Place all parts in one cleared area and remove the packaging material. Do not throw away material until assembly is complete.
- Page 5 IMPORTANT! ENSURE GROUND IS LEVEL. USE GROUND ANCHOR SCREWS ON 4 OUTSIDE LEGS TO SECURE FRAME BEFORE USE. LEVEL GROUND GROUND ANCHOR WASHER BASE PLATE...
- Page 6 IMPORTANT! ONLY FULLY TIGHTEN BOLTS ONCE FRAME IS ASSEMBLED. FINGER TIGHTEN ONLY DURING ASSEMBLY. REFER TO PART NUMBERS PRINTED ON ALL TUBULAR PARTS DURING ASSEMBLY. TYPICAL CHICAGO BOLT ASSEMBLY TYPICAL RUNG ASSEMBLY THE SAFETY BOLT IS SHOWN AS RED IN THIS MANUAL TO INDICATE THAT THIS SPECIAL FASTERNER IS REQUIED TO LOCATE POSITION OF TUBE AND...
- Page 9 FRONT LEGS: IMPORTANT! LAY PARTS OUT AS SHOWN. PART NUMBERS ARE PRINTED ON TUBULAR PARTS HOLES MUST BE FACING INWARDS! CP20D1 CP20D1 CP20D2 CP20D2 PLACE SHORT TEE’S AS SHOWN. FACING INWARDS WITH BOTS UPWARDS. LEAVE LOOSE. DO NOT TIGHTEN. SECURE BASE PLATE PLATE...
- Page 10 TOP SIDE RAILS: IMPORTANT! LAY PARTS OUT AS SHOWN. SLIDE 3 WAY TEE ONTO PART CP20A2 FIRST AND ALIGN WITH HOLE. INSERT SAFETY CP20E1K BOLT FINGER TIGHT. NOTE NOTE END CAPS TO REAR THAT THE BOLT IS OUTWARDS WITH THE KINK INWARDS AS SHOWN.
- Page 11 BOTTOM SIDE RAILS: IMPORTANT! LAY PARTS OUT AS SHOWN. PART NUMBERS ARE PRINTED ON TUBULAR PARTS CONNECT PARTS TOGETHER, CP20B1 HAND TIGHTEN CHICAGO BOLTS. CP20B1 CP20B2 SAFETY BOLT HOLES AS SHOWN TO REAR. THIS CP20B2 WILL LOCATE THE TUBE IN FINAL ASSEMBLY. CP20B1 CP20B1 CP20B2...
- Page 12 FRONT SUPPORT BAR: IMPORTANT! LAY PARTS OUT AS SHOWN. SWING CLAMPS FOUND IN TP1 TRAPEZE BOX. CP20C1 CP20C2 SAFETY BOLT HOLES AS SHOWN! SLIDE ON SWING CLAMPS AND HAND TIGHTEN CHICAGO BOLTS. NOTE CLAMP SCREWS BOTH FACING INWARDS!! NOTE CLAMP BOLTS FACING INWARDS.
- Page 13 MONKEY BARS (MR1800KIT): IMPORTANT! LAY PARTS OUT AS SHOWN. TWO PEOPLE ARE NOW REQUIRED FOR REMAINING ASSEMBLY! STEP 1: POSITION CARGO NET ONTO LADDER AS SHOWN - NO LOOPS TO BOTTOM BRACING TO REAR SHORT TEE WITH NO LOOPS SAFETY BOLT STEP 2: CONNECT MONKEY BARS INTO CLAMPS.
- Page 14 TOP SIDE RAILS NOTE END CAPS TO REAR RIGHT HAND TOP RAIL STEP 3: PLACE RIGHT HAND TOP RAIL ONTO LADDER AS SHOWN AND TIGHTEN BOTTOM BOLTS ONLY. DON’T TIGHTEN THE SAFETY BOLT! SAFETY BOLT TO OUTSIDE STEP 4: SLIDE 1 X ROPE CLIMB AND 1 X SWING CLAMP AS SHOWN.
- Page 15 ONE PERSON IS REQUIRED TO TOP SIDE RAILS SUPPORT FRAME AT ALL TIMES! STEP 6: SLIDE 1 X CARGO LOOP, THEN 1 X SWING STEP 5: PLACE LEFT HAND CLAMP AS SHOWN (SWING TOP RAIL ONTO LADDER CLAMPS FOUND IN NS2 NOTE END CAPS TO REAR AS SHOWN AND TIGHTEN BOX)
- Page 16 CP20A1 STEP 7: ATTACH CP20A1 WITH CHICAGO BOLTS AND SLIDE ON REMINING ROPE CLIMBS. LEAVE LOOSE. STEP 8: GRAB FRONT SUPPORT BAR FOR NEXT STEP...
- Page 17 STEP 9: ATTACH FRONT SUPPORT BAR ONE SIDE AT A TIME. LOOSLY TIGHTEN WITH ALLEN KEY. SAFETY BOLT HOLES AS SHOWN TO INSIDE!!
- Page 18 THREAD LEG THROUGH CARGO NET AND INTO TOP CLAMP. ROTATE UNTIL SAFETY BOLT HOLE IS SHOWN AND INSERT SAFETY BOLT PLAN VIEW SAFETY BOLT HOLES AS SHOWN!! NOTE LEGS FACING OUTWARDS...
- Page 19 BOTTOM SIDE RAILS CP20B1 THREAD BOTTOM SIDE RAILS CP20B2 THROUGH CARGO NET AND INTO TOP CLAMP. ROTATE UNTIL SAFETY BOLT HOLE IS SHOWN AND INSERT SAFETY BOLT. REPEAT OTHER SIDE. SAFETY BOLT TO OUTSIDE...
- Page 20 WARNING: ACCESSORIES MUST ONLY BE ATTACHED IN POSITIONS AS SHOWN IN THESE INSTRUCTIONS. FAILURE MAY RESULT IN DEATH OR SERIOUS INJURY. ONCE ALL BOLTS ARE TIGHTENED ON FRAME, MOVE INTO POSITION. INSTALL PEGS TO HOLD BASE PLATE IN PLACE ONE CORNER AT A TIME, LOOSEN AND LIFT FRAME TO ONE SIDE LEAVING BASE PLATE IN PLACE.
-
Page 21: Final Step
FINAL STEP. START AT ONE CORNER OF THE FRAME AND DOUBLE CHECK ALL BOLTS ARE TIGHT. SMALL MOVEMENT IN FRAME IS NORMAL. CONGRATULATIONS! YOU HAVE ASSEMBLED YOUR GROWPLAY COMPACT MONKEY BAR! -
Page 22: Maintenance Information
MAINTENANCE INFORMATION This product was manufactured using quality materials and crafted to provide you and your family with many years of enjoyment and exercise. Proper maintenance care will help to prolong the life and reduce the possibility of injury. The following guidelines should be followed. - Page 23 growplaymonkeybars.com...
