48230KITS/48300KITS
Assembly Instructions
If any parts are missing, damaged or worn, stop using this KITS. Repair the KITS with
Read these instructions carefully before beginning assembly. Failure to follow these
Carefully unpack all parts and identify them with the parts list before attempting to
assemble the KITS. Remove all cardboard and plastic covering from DIY KITS parts.
Please examine all packing material before discarding it.
WARNING:
manufacturer supplied parts.
IMPORTANT:
instructions may result in serious injury.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 48230KITS and is the answer not in the manual?

Questions and answers

Related Manuals for BASENGREEN 48230KITS

Summary of Contents for BASENGREEN 48230KITS

  • Page 1 48230KITS/48300KITS Assembly Instructions WARNING: If any parts are missing, damaged or worn, stop using this KITS. Repair the KITS with manufacturer supplied parts. IMPORTANT: Read these instructions carefully before beginning assembly. Failure to follow these instructions may result in serious injury.
  • Page 2 ALL DIY kIT accessories are included in the DIY box Wire pre-installation...

  • Page 3: Packing List

    Packing list Please check the product carefully after receiving it, if any accessories are missed, please contact BASEN. (Pre-installed) Front plate*1 (Pre-installed) (Pre-installed) (Pre-installed) (Pre-installed) Shell*1 Cover plate*1 Balance bars*2 Handle*2 (Pre-installed) (Pre-installed) (Pre-installed) (Pre-installed) LCD Display*1 Temperature 16S voltage BASEN GREEN 16S 200A BMS*1 NTC leads*1...
  • Page 4 Romove the BMS front plate(D), the cover plate(B), and the balance bars(C)
  • Page 5 Put the fiberglass insulation plate...
  • Page 6 Cell difference within 20mV Place the battery cells in the chassis, separated by fiberglass insulation plate...
  • Page 9 Linking Balance bars and Flexible busbar Installation of Equalizer...
  • Page 10 Linking Equalizer Cables Each wire has a corresponding label Link the other end of the Flexible busba according to the corresponding value.
  • Page 12 Put the BMS front plate(D) on, plug the voltage acquisition lead P+ lead to the main positive, and B- lead to the main negative, then put the B+ lead on, and stick the temperature NTC leads(H) on the cells by heat proof tape. B+ lead Voltage acquisition port P+ lead...
  • Page 13 Check every connection, the voltage between the main positive and the negative is >52V, then turn the button on, the LCD and the indicator work out, then the assembly operation is completed. Unbox and install video: https://www.youtube.com/watch?v=6FZf448Nujk&t=22s OFF/ON Operation of Upper System Firstly, connect the USB to RS485 Cable from Battery to the PC/Laptop, dip switch 1 on the front plate, download the PC software and open it.
  • Page 15 BASEN BMS is equipped with Bluetooth function, please contact our sales representative or visit our website to get the latest Bluetooth APP. How to switch the communication protocol. Open the PC software and follow the path: INFO—Parallel Group Display—CAN Type/RS485 Type—Read—Choose the protocol—Set...
