- Page 1 Wall Mounted Battery Pack Installation & Operation Manual BR-OW-LV 11.77KWH BR-OW-LV 14.33KWH BR-OW-LV 15.36KWH BR-OW-LV 16.07KWH...
- Page 2 1. Preface _________________________________________________________________________________________ 01 2. Label Explanation ______________________________________________________________________________ 02 3. Product Description ____________________________________________________________________________ 02 4. Product Advantages ___________________________________________________________________________ 02 5. Product Technical Parameters_________________________________________________________________ 03 5.1 Specification ________________________________________________________________________________ 03 5.2 Interface Overview__________________________________________________________________________ 04 5.3 Battery Management System (BMS)________________________________________________________ 06 5.3.1 Overcharge Protection ________________________________________________________________ 06 5.3.2 Overdischarge Protection ____________________________________________________________ 06 5.3.3 Overcurrent Protection _______________________________________________________________ 06 5.3.4 Over Temperature Protection_________________________________________________________ 06...
- Page 3 BASENGREEN, YOUR RELIABLE POWER 1. Preface This manual will provide detailed product information and installation instructions for users of the wall-mounted series products. Please read this manual carefully, and put this manual in a place where you can install, operate, and obtain it conveniently.
- Page 4 BASENGREEN, YOUR RELIABLE POWER 2. Label Explanation The label contains the following information Product Name Rechargeable LiFePo4 Battery Product Name Rechargeable LiFePo4 Battery Product Name Rechargeable LiFePo4 Battery Product Name Rechargeable LiFePo4 Battery Battery Type LiFePO4 (LFP) Battery Type LiFePO4 (LFP)
- Page 5 BASENGREEN, YOUR RELIABLE POWER e. Wide Working Temperature: -20℃ to 60℃, excellent high-temperature discharge performance. f. Convenient: Modular design, small size and lightweight, easy to install and maintain. 5. Product Technical Parameters 5.1 Specification Item Specifications BR-OW-LV BR-OW-LV BR-OW-LV BR-OW-LV Model 11.77KWH...
- Page 6 BASENGREEN, YOUR RELIABLE POWER 5.2 Interface Overview P.S: There will be some differences in the appearance of the battery due to the version. As shown in the picture Take BR-OW-LV14.33KWH as example...
- Page 7 BASENGREEN, YOUR RELIABLE POWER Position Item Description The negative terminal of the battery, can be connected to the negative pole of the inverter through a cable for DC output. The positive terminal of the battery, can be connected to the positive pole of the inverter through a cable for DC output.
- Page 8 BASENGREEN, YOUR RELIABLE POWER 5.3 Battery Management System（BMS） 5.3.1 Overcharge Protection When the voltage of any single cell or whole battery pack is higher than the set value during the charging, and the duration reaches the limited time, the system enters the over charging protection state automatically, the charging MOS is turned off at the same time, and the battery cannot be charged.
- Page 9 BASENGREEN, YOUR RELIABLE POWER 5.4 Optional Upgrade Feature Some BR-OW series models are equipped with the following optional upgraded features: touch color screen and led strip. Touch Colorful Screen • Colorful Display: Touch Screen, easy to operate. • Multi-language: Arabic, English, German, Spanish, Italian, French, Polish, Romanian •...
- Page 10 BASENGREEN, YOUR RELIABLE POWER 6. Installation and configuration 6.1 Packing a. After receiving the battery, open the box to check the battery surface if get any broken, cracks or other bad phenomena; if get that, please do not install, and need to contact the supplier, and wait for the supplier's reply before proceeding to the next step.
- Page 11 BASENGREEN, YOUR RELIABLE POWER Hanging the bracket Hammer Crimping tool for RJ45 terminal Crimping Tool Crimping tool for insulated electric connectors Crimping Plier Loosening/tightening screws Adjustable wrench 6.3 Notice for Installation a. The wall for installation should be a solid brick or cement wall with a strong load-bearing capacity, and the thickness of the wall should not be less than 100mm.
- Page 12 BASENGREEN, YOUR RELIABLE POWER Installation Diagram Expansion Bolts Fixed bracket Wall Notice: some of the models are equipped with fixed-direction wheels only. It can be removed by using a Phillips screwdriver Wheel release direction Battery...
- Page 13 BASENGREEN, YOUR RELIABLE POWER 7. Connection 7.1 Precautions Before Connecting The Inverter a. Use a multi-meter to measure whether connection of the positive and negative cables are conducting, and check whether that connections are loose. b. The battery should be switched off before wiring to ensure that there is no DC output from the battery.
- Page 14 BASENGREEN, YOUR RELIABLE POWER 7.2 RJ45 Connector Diagrams of Inverter's port CANH CANL RS485A RS485B RJ45 plug RJ45 Connector Diagrams Communication CANH->pin4 Inverter CANL->pin5 Brand：DEYE, Growatt, Goodwe, Solis CANH->pin7 Inverter CANL->pin8 Brand: Victron RS485B->pin1 Inverter RS485A->pin2 Brand: Pylon, Growatt RS485B->pin3 Inverter RS485A->pin5...
- Page 15 BASENGREEN, YOUR RELIABLE POWER 7.3 Precautions Before Connecting The Inverter with The Battery Pack in Parallel a. Use a multi-meter to measure whether connection of the positive and negative cables are conduct- ing, and check whether that connections are loose.
- Page 16 BASENGREEN, YOUR RELIABLE POWER 7.4 Battery & Inverter Connection Connect the positive and negative cables of the battery to the positive and negative terminals of the DC input of the inverter, insert the RJ45 crystal plug at one end of the distributed inverter communication cable to the RS485 of the battery, and connect the other end to the BMS terminal of the inverter according to the defined line voltage, and then connect the battery to the inverter.
- Page 17 BASENGREEN, YOUR RELIABLE POWER 4-BIT Dip Switch Position Address Illustration 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4...
- Page 18 BASENGREEN, YOUR RELIABLE POWER 8. Operation 8.1 Check Before Power on a. Check all positive, negative cables and communication lines are connected correctly and safely. b. Check the battery is firmly installed, easy to operate and maintain, and check ventilation.
- Page 19 BASENGREEN, YOUR RELIABLE POWER Specification Battery capacity LED Normal/warning/ Status protection ● ● ● ● ● ● ● ● Sleep Power off ALL OFF Normal Flash1 Stand by Warning Flash1 Normal Flash2 Warning (Not including Flash2 temperature ) ALM OFF when...
- Page 20 The parameters can be made visible with the BASENGREEN App. Download: Android: "BASENGREEN” in Play Store iOS: "BASENGREEN" in Apple Store 9.1 Bluetooth a. For Android users, please visit the Google Play Store and search for 'BASENGREEN'. For iOS users, go to the Apple Store and look up 'BASENGREEN'.
- Page 21 BASENGREEN, YOUR RELIABLE POWER b. Turn on Bluetooth and search for the corresponding product's Bluetooth code NOTE: 1.If you selected a battery to connect to and the app doesn't confirm the connection, it might be someone else is already connected to the battery. Only one device connects to the battery at the same time.
- Page 22 BASENGREEN, YOUR RELIABLE POWER c. Menu Bluetooth list: Check the Device list and connect it. Homepage: Check the status of battery-SOC, Volt, Current, Temperature, etc. Historical Data: Not available Setting: Base Message: Check the pack voltage, current, cycle time, etc.
- Page 23 BASENGREEN, YOUR RELIABLE POWER 9.2. Operation of Communication Protocol Switch(Via Bluetooth App) a. Connect to the Bluetooth app first(Chapter 9.1) b. Swipe left to find 'Inverter Configuration'. Set unlock code is 888888 c. Choose the communication protocol and set, the battery pack will be restart after few...
- Page 24 BASENGREEN, YOUR RELIABLE POWER 10. Operation of Upper System BASEN 48V battery pack supports to connect with our upper system to monitor the status of the battery and modify the communication protocol, please contact our sales representative or visit our website to get the latest upper system software.
- Page 25 BASENGREEN, YOUR RELIABLE POWER 10.2 Switching communication protocols via PC Connect to the upper system and follow the path: INFO—Parallel Group Display—CAN Type/RS485 Type—Read—Choose the protocol—Set...
- Page 26 BASENGREEN, YOUR RELIABLE POWER 10.3 Communication Protocol Switching Via Classic Screen 1. Introduction There are 4 buttons on the side of screen : Enter the “MENU” page MENU : Confirm the change/enter the next page ENTER : Select items/turn pages : Back to the last page 2.
- Page 27 BASENGREEN, YOUR RELIABLE POWER d. Choose the protocol and click the “ENTER”button. e. All of the indicators will light up after 3-5 seconds, and then it has a “bee” sound. The screen will show the latest communication protocol, which means the protocol...
- Page 28 BASENGREEN, YOUR RELIABLE POWER 10.4 Communication Protocol Switching Via Touch Screen 1. Introduction Touch Colorful Screen a. Colorful Display: Touch Screen, easy to operate. b. Multi-language: Arabic, English, German, Spanish, Italian, French, Polish, Romanian c. System Theme: Support Dark Theme 2.
- Page 29 BASENGREEN, YOUR RELIABLE POWER c. There are CAN/RS485 options, click ”Read” to check the currently protocol (Default communication protocol: Pylon) d. Choose the protocol and click the “write”button, it will shows”success” e. Back to the home page, Swipe left to go to the next view.
- Page 30 BASENGREEN, YOUR RELIABLE POWER 10.5 Communication Compatible List...
- Page 31 BASENGREEN, YOUR RELIABLE POWER 11. Storage a. External terminals of the battery pack are insulated and protected. b. If the battery pack is stored for a long period of time without use, it is recommended that it be charged 30%-60%, and it is prohibited to store it completely uncharged.
- Page 32 BASENGREEN, YOUR RELIABLE POWER Attention! a. It is forbidden to use or place the battery under high temperatures (in the hot sun or in a very hot car), otherwise, it may cause the battery to overheat, catch fire or fail to function, and shorten its life; the recommended temperature for long-term battery storage is 10-45°C;...
- Page 33 Need additional information? Just Contact BASEN! BASENGREEN YOUR RELIABLE POWER Fax: (+86)0755-84737145 Tex: (+86)130 0887 9993 Email: info@basen-power.com Shenzhen Basen Technology Co., Ltd. Add: Room 303,Building 3, 1980 Culture and Technology Industrial Park, Donghuan Road,Longhua District,Shenzhen...
