- Page 1 Stackable Battery Pack Pack Installation & Operation Manual BR-BOX-LV 5KWH BR-BOX-LV 10KWH BR-BOX-LV 20KWH BR-BOX-LV 30KWH...
-
Page 2: Table Of Contents
Content 1. Preface 2. Label Explanation 3. Product Description 4. Product Advantages 5. Product Technical Parameters • 5.1 Product Appearance • 5.2 Specification • 5.3 Interface Overview • 5.4 Battery Management System • 5.4.1 Overcharge Protection • 5.4.2 Overdischarge Protection •... -
Page 3: Preface
This manual will provide detailed product information and installation instructions for users of the wall-mounted series products of SHENZHEN BASENGREEN TECHNOLOGY CO.LTD (hereinafter referred to as BASENGREEN). Please read this manual carefully, and put this manual in a place where you can install, operate, and obtain it conveniently. -
Page 4: Label Explanation
BASENGREEN, YOUR RELIABLE POWER 2. Label Explanation The label contains the following information Guangdong Basengreen New Energy Co.,Ltd Rechargeable LiFePO4 Battery Product Name Product Model BR-BOX-LV 5KWH 43.2Vdc-58.4Vdc Battery Voltage Operation Range Maximum Charge Current 100A Maximum Discharge Current 100A 100Ah/51.2V/5120Wh... -
Page 5: Product Advantages
BASENGREEN, YOUR RELIABLE POWER 4. Product Advantages a. Built-in Battery Management System (BMS): Overcharge, overdischarge, overcurrent, temperature control, short circuit and other protection functions. b. Passive Balance Function: There is a voltage equalization function during the charging. c. High Cost Performance: High safety performance, long service life, stable and reliable quality. -
Page 6: Specification
BASENGREEN, YOUR RELIABLE POWER 5.2 Specifications Item Specifications Model BR-BOX-LV 5KWH BR-BOX-LV 10KWH BR-BOX-LV 20KWH BR-BOX-LV 30KWH Nominal Voltage 51.2V 51.2V 51.2V 51.2V Operating Voltage 43.2V-57.6V 43.2V-57.6V 43.2V-57.6V 43.2V-57.6V Nominal Capacity 100Ah 200Ah 400Ah 600Ah Total Energy 5120Wh 10240Wh 20480Wh... -
Page 7: Interface Overview
BASENGREEN, YOUR RELIABLE POWER 5.3 Interface Overview Position Item Description The positive terminal of the battery, can be connected to the positive pole of the inverter through a cable for DC output The negative terminal of the battery, can be connected to the... -
Page 8: Battery Management System
BASENGREEN, YOUR RELIABLE POWER 5.4 Battery Management System（BMS） 5.4.1 Overcharge Protection When the voltage of any single cell or whole battery pack is higher than the set value during the charging, and the duration reaches the limited time, the system enters the over charging protection state automatically, the charging MOS is turned off at the same time, and the battery cannot be charged. -
Page 9: Installation And Configuration
BASENGREEN, YOUR RELIABLE POWER 6. Installation and configuration 6.1 Packing a. After receiving the battery, open the box to check the battery surface if get any broken, crack,s or other bad phenomena; if get that, please do not install, and need to contact the supplier, and wait for the supplier's reply before proceeding to the next step. -
Page 10: Recommended Tools
BASENGREEN, YOUR RELIABLE POWER 6.2 Installation Procedure a. Use a multi-meter to measure whether the positive and negative cable wires are conducting, and check whether the positive and negative terminal connections are loose. b. The battery should be switched off before wiring to ensure that there is no DC output from the battery. - Page 11 BASENGREEN, YOUR RELIABLE POWER Installation Diagrams of 20KWH Installation Diagrams of 20KWH...
-
Page 12: Connection
BASENGREEN, YOUR RELIABLE POWER BASENGREEN, YOUR RELIABLE POWER 7. Connection 7.1 Precautions Before Connecting The Inverter a. Use a multi-meter to measure whether the positive and negative cable wires are conducting, and check whether the positive and negative terminal connections are loose. -
Page 13: Pin Definition
BASENGREEN, YOUR RELIABLE POWER 7.2 Pin Definition RJ45 plug 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 a. RS485/CAN Communication cable connection Pin definition is as follows: Define RS485-B RS485-A CAN-H CAN-L b. -
Page 14: Dip Code Switch Definition And Setting
BASENGREEN, YOUR RELIABLE POWER 7.3 Dip Code Switch Definition and Setting ADD switch is an 8-bit DIP switch to manually distribute the communication address of parallel batteries. The BMS will only recognize the DIP address once it is reset, so please reset the BMS when the DIP address is changed (the BMS must be reset in the standby state). -
Page 15: Operation
BASENGREEN, YOUR RELIABLE POWER 8. Operation 8.1 Check Before Power on a. Check all positive, negative cables and communication lines are connected correctly and safely. b. Check the battery is firmly installed, easy to operate and maintain, and check ventilation. -
Page 16: Operation Of Upper System
BASENGREEN, YOUR RELIABLE POWER LED Flashing Faulty Specification Battery capacity LED Normal/warning/ Status protection ● ● ● ● ● ● Sleep Power off ALL OFF Stand by Light Normal ALL OFF Light Normal Display according to the actual SOC Over Current Alarm Light... -
Page 17: Log In
BASENGREEN, YOUR RELIABLE POWER 9.1 Log in a. The upper system communication cable connects to the RS485 port on the battery and then to the USB port on the PC/Laptop b. Download and open the upper system software c. Modify the language d. -
Page 18: Operation Of The Communication Protocol Switch
BASENGREEN, YOUR RELIABLE POWER 9.2 Operation of The Communication Protocol Switch Connect to the upper system and follow the path: INFO—Parallel Group Display—CAN Type/RS485 Type—Read—Choose the protocol—Set... -
Page 19: Communication Compatible List
BASENGREEN, YOUR RELIABLE POWER 9.3 Communication Compatible List... -
Page 20: Storage
BASENGREEN, YOUR RELIABLE POWER 10. Storage a. External terminals of the battery pack are insulated and protected. b. If the battery pack is stored for a long period of time without use, it is recommended that it be charged 30%-60%, and it is prohibited to store it completely uncharged. - Page 21 BASENGREEN, YOUR RELIABLE POWER Attention! a. It is forbidden to use or place the battery under high temperatures (in the hot sun or in a very hot car), otherwise, it may cause the battery to overheat, catch fire or fail to function, and shorten its life; the recommended temperature for long-term battery storage is 10-45°C;...
- Page 22 Need additional information? Just Contact BASEN! BASENGREEN YOUR RELIABLE POWER Fax: (+86)0755-84737145 Tex: (+86)130 0887 9993 Email: info@Basengroup.com Website: www.basenpower.com Shenzhen Basen Technology Co., Ltd. Add: Room 303,Building 3, 1980 Culture and Technology Industrial Park, Donghuan Road,Longhua District,Shenzhen...
