Summary of Contents for BASENGREEN BR-PC-15KWH
- Page 1 Floor Mounted Battery Pack Installation & Operation Manual BR-PC-15KWH BR-PC-16KWH BR-PC-30KWH...
-
Page 2: Table Of Contents
Content 1. Preface _________________________________________________________________________________________ 01 2. Label Explanation ______________________________________________________________________________ 02 3. Product Advantages ___________________________________________________________________________ 02 4. Product Technical Parameters_________________________________________________________________ 03 4.1 Specification ________________________________________________________________________________ 03 4.2 Interface Overview__________________________________________________________________________ 03 4.3 Battery Management System (BMS)________________________________________________________ 05 4.3.1 Overcharge Protection ________________________________________________________________ 05 4.3.2 Overdischarge Protection ____________________________________________________________ 05 4.3.3 Overcurrent Protection _______________________________________________________________ 05 4.3.4 Over Temperature Protection ________________________________________________________ 05 4.3.5 Low Temperature Protection _________________________________________________________ 05... -
Page 3: Preface
BASENGREEN, YOUR RELIABLE POWER 1. Preface This manual will provide detailed product information and installation instructions for users of the Floor mounted series products. Please read this manual carefully, and put this manual in a place where you can install, operate, and obtain it conveniently. -
Page 4: Label Explanation
BASENGREEN, YOUR RELIABLE POWER 2. Label Explanation The label contains the following information Product Name Rechargeable LiFePo4 Battery Product Name Rechargeable LiFePo4 Battery Product Name Rechargeable LiFePo4 Battery Battery Type LiFePO4 (LFP) Battery Type LiFePO4 (LFP) Battery Type LiFePO4 (LFP) -
Page 5: Product Technical Parameters
BASENGREEN, YOUR RELIABLE POWER 4. Product Technical Parameters 4.1 Specification Item Specifications BR-PC-LV BR-PC-LV BR-PC-LV Model 15KWH 16KWH 30KWH Nominal Voltage 51.2V 51.2V 51.2V Operating Voltage 43.2V-57.6V 43.2V-57.6V 43.2V-57.6V Nominal Capacity 300AH 314AH 600AH Total Energy 15360Wh 16076Wh 30720Wh Configuration... - Page 6 BASENGREEN, YOUR RELIABLE POWER 10 11 12 13 Position Item Description The negative terminal of the battery, can be connected to the negative pole of the inverter through a cable for DC output. The positive terminal of the battery, can be connected to the positive pole of the inverter through a cable for DC output.
-
Page 7: Battery Management System (Bms)
BASENGREEN, YOUR RELIABLE POWER 4.3 Battery Management System（BMS） 4.3.1 Overcharge Protection When the voltage of any single cell or whole battery pack is higher than the set value during the charging, and the duration reaches the limited time, the system enters the over charging protection state automatically, the charging MOS is turned off at the same time, and the battery cannot be charged. -
Page 8: Installation And Configuration
BASENGREEN, YOUR RELIABLE POWER 5. Installation and configuration 5.1 Packing a. After receiving the battery, open the box to check the battery surface if get any broken, cracks or other bad phenomena; if get that, please do not install, and need to contact the supplier, and wait for the supplier's reply before proceeding to the next step. -
Page 9: Connection
BASENGREEN, YOUR RELIABLE POWER 6. Connection 6.1 Precautions Before Connecting The Inverter a. Use a multi-meter to measure whether connection of the positive and negative cables are conducting, and check whether that connections are loose. b. The battery should be switched off before wiring to ensure that there is no DC output from the battery. -
Page 10: Rj45 Connector Diagrams Of Inverter's Port
BASENGREEN, YOUR RELIABLE POWER 6.2 RJ45 Connector Diagrams of Inverter's port CANH CANL RS485A RS485B RJ45 plug RJ45 Connector Diagrams Communication CANH->pin4 Inverter CANL->pin5 Brand：DEYE, Growatt, Goodwe, Solis CANH->pin7 Inverter CANL->pin8 Brand: Victron RS485B->pin1 Inverter RS485A->pin2 Brand: Pylon, Growatt RS485B->pin3 Inverter RS485A->pin5... -
Page 11: Precautions Before Connecting The Inverter With Battery In Parallel
BASENGREEN, YOUR RELIABLE POWER 6.3 Precautions Before Connecting The Inverter with The Battery Pack in Parallel a. Use a multi-meter to measure whether connection of the positive and negative cables are conduct- ing, and check whether that connections are loose. -
Page 12: Battery & Inverter Connection
BASENGREEN, YOUR RELIABLE POWER 6.4 Battery & Inverter Connection Connect the positive and negative cables of the battery to the positive and negative terminals of the DC input of the inverter, insert the RJ45 crystal plug at one end of the distributed inverter communication cable to the RS485 of the battery, and connect the other end to the BMS terminal of the inverter according to the defined line voltage, and then connect the battery to the inverter. - Page 13 BASENGREEN, YOUR RELIABLE POWER 4-BIT Dip Switch Position Address Illustration 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4...
-
Page 14: Operation
BASENGREEN, YOUR RELIABLE POWER 7. Operation 7.1 Check Before Power on a. Check all positive, negative cables and communication lines are connected correctly and safely. b. Check the battery is firmly installed, easy to operate and maintain, and check ventilation. - Page 15 BASENGREEN, YOUR RELIABLE POWER Specification Battery capacity LED Normal/warning/ Status protection ● ● ● ● ● ● ● ● Sleep Power off ALL OFF Normal Flash1 Stand by Warning Flash1 Normal Flash2 Warning (Not including Flash2 temperature ) ALM OFF when...
-
Page 16: Operation Of Bluetooth
The parameters can be made visible with the BASENGREEN App. Download: Android: "BASENGREEN” in Play Store iOS: "BASENGREEN" in Apple Store 8.1 Bluetooth a. For Android users, please visit the Google Play Store and search for 'BASENGREEN'. For iOS users, go to the Apple Store and look up 'BASENGREEN'. - Page 17 BASENGREEN, YOUR RELIABLE POWER b. Turn on Bluetooth and search for the corresponding product's Bluetooth code NOTE: 1.If you selected a battery to connect to and the app doesn't confirm the connection, it might be someone else is already connected to the battery. Only one device connects to the battery at the same time.
- Page 18 BASENGREEN, YOUR RELIABLE POWER c. Menu Bluetooth list: Check the Device list and connect it. Homepage: Check the status of battery-SOC, Volt, Current, Temperature, etc. Historical Data: Not available Setting: Base Message: Check the pack voltage, current, cycle time, etc.
-
Page 19: Operation Of Communication Protocol Switch(Via Bluetooth App)
BASENGREEN, YOUR RELIABLE POWER 8.2. Operation of Communication Protocol Switch(Via Bluetooth App) a. Connect to the Bluetooth app first(Chapter 9.1) b. Swipe left to find 'Inverter Configuration'. Set unlock code is 888888 c. Choose the communication protocol and set, the battery pack will be restart after few... -
Page 20: Operation Of Upper System
BASENGREEN, YOUR RELIABLE POWER 9. Operation of Upper System BASEN 48V battery pack supports to connect with our upper system to monitor the status of the battery and modify the communication protocol, please contact our sales representative or visit our website to get the latest upper system software. -
Page 21: Switching Communication Protocols Via Pc
BASENGREEN, YOUR RELIABLE POWER 9.2 Switching communication protocols via PC Connect to the upper system and follow the path: INFO—Parallel Group Display—CAN Type/RS485 Type—Read—Choose the protocol—Set... -
Page 22: Communication Protocol Switching Via Screen
BASENGREEN, YOUR RELIABLE POWER 9.3 Communication Protocol Switching via Screen 1. Introduction Touch Colorful Screen a. Colorful Display: Touch Screen, easy to operate. b. Multi-language: Arabic, English, German, Spanish, Italian, French, Polish, Romanian c. System Theme: Support Dark Theme 2. Switch the communication protocol a. - Page 23 BASENGREEN, YOUR RELIABLE POWER c. There are CAN/RS485 options, click ”Read” to check the currently protocol (Default communication protocol: Pylon) d. Choose the protocol and click the “write”button, it will shows”success” e. Back to the home page, Swipe left to go to the next view.
-
Page 24: Communication Compatible List
BASENGREEN, YOUR RELIABLE POWER 9.4 Communication Compatible List... -
Page 25: Storage
BASENGREEN, YOUR RELIABLE POWER 10. Storage a. External terminals of the battery pack are insulated and protected. b. If the battery pack is stored for a long period of time without use, it is recommended that it be charged 30%-60%, and it is prohibited to store it completely uncharged. - Page 26 BASENGREEN, YOUR RELIABLE POWER Attention! a. It is forbidden to use or place the battery under high temperatures (in the hot sun or in a very hot car), otherwise, it may cause the battery to overheat, catch fire or fail to function, and shorten its life; the recommended temperature for long-term battery storage is 10-45°C;...
- Page 27 Need additional information? Just Contact BASEN! BASENGREEN YOUR RELIABLE POWER Fax: (+86)0755-84737145 Tex: (+86)130 0887 9993 Email: info@Basengroup.com Shenzhen Basen Technology Co., Ltd. Add: Room 303,Building 3, 1980 Culture and Technology Industrial Park, Donghuan Road,Longhua District,Shenzhen...
