4-1.

Serial Number And Rating Label Location

The serial number and rating information for the power source is located on the rear of the machine. Use the rating labels to determine input
power requirements and/or rated output. The serial number is located on the rear of the machine, for future reference, write serial number in
space provided on back cover of this
4-2.

Software Licensing Agreement

The End User License Agreement and any third-party notices and terms and conditions pertaining to third-party software can be found at
https://www.millerwelds.com/eula
4-3.

Information About Default Weld Parameters And Settings

NOTICE – Each welding application is unique. Although certain Miller Electric products are designed to determine and default to certain typical
welding parameters and settings based upon specific and relatively limited application variables input by the end user, such default settings are
for reference purposes only; and final weld results can be affected by other variables and application-specific circumstances. The appropriate-
ness of all parameters and settings should be evaluated and modified by the end user as necessary based upon application-specific require-
ments. The end user is solely responsible for selection and coordination of appropriate equipment, adoption or adjustment of default weld
parameters and settings, and ultimate quality and durability of all resultant welds. Miller Electric expressly disclaims any and all implied warran-
ties including any implied warranty of fitness for a particular purpose.
4-4.

Specifications

�
Do not use information in unit specifications table to determine electrical service requirements. See Section 5-4 for information on connect-
ing input power.
�
This equipment will deliver rated output at an ambient air temperature up to 104°F ( 40°C).
AC or DC
Model
Rated Output**
SubArc AC/DC 1000 A at 44 V,
Digital, 1000 Amp 100% Duty Cycle
SubArc AC/DC 1250 A at 44 V,
1250 Digital 60% Duty Cycle
4-5.

SubArc System Compatibility

The following accessory models will function with the SubArc AC/DC Digital Series power sources. The interface will automatically detect the
power source and wire drive type connected.
Interfaces:
300936 − SubArc Interface Digital
300937 − SubArc Interface Analog
Wire Drives:
300938 − SubArc Wire Drive 400 Digital Low Voltage
300938001 − SubArc Wire Drive 400 Digital Low Voltage For Tractors
300939 − SubArc Strip Drive 100 Digital Low Voltage
300940 − SubArc Strip Drive 100 Digital Low Voltage w/Mounting Bracket
300941 − SubArc Wire Drive 780 Digital Low Voltage
Flux Hopper:
300942 − SubArc Flux Hopper Digital Low Voltage
OM-265364 Page 13
SECTION 4 – SPECIFICATIONS
and are incorporated by reference herein.
Amperage/Voltage
Range AC/DC
300 − 1250 A
in AC Mode
20 − 44 V
in Subarc Mode
RMS Amps Input at
Rated Output,
3-Phase at NEMA Load
Max.
Voltages and Class 1 Rating
Open-Circuit
Voltage
380V
(50 Hz) (50 Hz)
—
93 Vpk
179
(3*)
KVA
400V 460V
(60 Hz)
122 98
—
(3*) (2.37*)
176 122
—
(3*) (2.37*)
KW
53
(0.95*)
67
(0.96*)
