  • Page 1 User manual Washing machine HW110-BD14397U1S...
  • Page 2 Thank You Thank you for purchasing a Haier Product. Please read these instructions carefully before using this appliance. The instructions contain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance.

  • Page 3: Table Of Contents

    Content 1- Safety information ................................ 4 2- Product description ..............................7 3- Control panel .................................. 8 4- Programmes ................................14 5- Consumption ................................15 6- Daily use ..................................16 7- hOn ....................................21 8- Eco-friendly washing ..............................24 9- Care and cleaning ............................... 25 10- Troubleshooting...............................

  • Page 4: 1-Safety Information

    1-Safety information Before switching on the appliance for the first time read the following 1-Safety information safety hints! WARNING! Before first use ► Make sure there is no transport damage. ► Make sure all transport bolts are removed. ► Remove all packaging and keep out of children's reach. ►...
  • Page 5 1-Safety information WARNING! Daily use ► Do not remove or insert the plug in the presence of flammable gas. ► Do not hot wash foam rubber or sponge-like materials. ► Do not wash any laundry which is polluted with flour. ►...
  • Page 6 1-Safety information WARNING! Installation Install or use the appliance only where the temperature is above 5 °C. ► Do not place the appliance directly on a carpet, or close to a wall or ► furniture. Do not install the appliance in direct sunlight or in the near of heat ►...

  • Page 7: 2-Product Description

    2-Product description 2-Product description Notice Due to technical changes and different models, the illustrations in the following chapters may differ from your model. 2.1 Picture of appliance Front (Fig. 2-1): Rear side (Fig. 2-2): Detergent / Softener drawer Transportation bolts (T1 -T4) Worktop Backcover Control panel...

  • Page 8: 3-Control Panel

    3-Control panel 3-Control panel 1 "Power" button 3 Display 5 "Start/Pause” button 2 Programme selector 4 Function buttons 3.1 "Power" button Touch this button (Fig. 3-2) gently to switch on, the display is shining, the indicator of the "Start/Pause” button is flashing.
  • Page 9 3-Control panel Symbol Meaning Appliance is connected to Wi-Fi. Softener in drawer. Detergent in drawer. l-time. Refresh. Ultra fresh. Steam:Smart Al,Shirt,Babycare,Allergy Care have steam washing function by default. Control panel is locked. Drum door is locked. 3.4 Function buttons This five buttons (Fig.3-5) are special function buttons, which can be selected as required.
  • Page 10 3-Control panel Touch this button again, fresh air icon will close,screen display"Ultra Fresh off" (Fig.3-7). 3.4.2 Function buttons Touch this button, refresh icon will light up,screen display"Refresh on"(Fig.3-8),it is used for fresh odor removal, dust removal, mites removal, and moisture removal. Touch this button again,refresh icon will close,screen display "Refresh off "(Fig.3-9).
  • Page 11 3-Control panel 3.4.4 Function buttons Touch this button, i-time icon will light up, the washing time can be set as needed. This function is not available for some programs(Fig.3-11). 3.4.5 Function buttons Touch this button,wifi icon will light up,the function button can be used to bind and unbind the Internet of things(Fig.3-12).
  • Page 12 3-Control panel 3.5.4 Detergent function Touch " Detergent "button(Fig.3-16)to select the the detergent dosage (OFF/40%/70%/100%/120%). 3.5.5 Softener function Touch "Softener" button (Fig.3-17)to select on or off the softener function (OFF/100%). 3.5.6 Delay End function Touch "Delay End "button (Fig.3-18)to select delay end time.
  • Page 13 3-Control panel 3.7 Child lock Choosing a programme and the start,touch "— "(Fig.3-21) 3 seconds,child lock function is enabled,screen display"Child lock on"(Fig.3-22). Touch "—" 3 seconds again, child lock function off, screen display "Child lock off" (Fig.3-23). Note: Child lock The child lock which is set up manually must be cancelled manually or will be canceled ►...

  • Page 14: 4-Programmes

    4-Programmes 4-Programmes Detergent compartment for: Softner Detergent • ◦ Yes, Optional, / No Laundry Powder Preset Max. load Temperature Function spin speed in rpm in kg in °C selectable HW100/ Programme Fabrics type range HW110 ◦ ◦ ◦ ◦ ◦ ◦ ◦ ◦ ◦ ◦ ◦ Eco 40-60 10/11 -- to 60...

  • Page 15: 5-Consumption

    5-Consumption 5-Consum ption Scan QR code on energy label for energy consumption information. The actual energy consumption may differ from the declared one according to local conditions. Test program according to the EU-Ecodesign-Regulation and EU-Energy Label-Regulation. Select Eco 40-60, then touch the start button, enter the washing performance programme. Indicative information (as per Commission Regulation (EU) 2019/2023): Effective Rated...

  • Page 16: 6-Daily Use

    6-Daily use 6.1 Power supply 6-Daily use Connect the washing machine to a power supply (220V to 240V~/50Hz; Fig. 6-1). Please refer also to section INSTALLTION (see P29). 6.2 Water connection Before connecting check the cleanliness and ► clarity of the water inlet. Turn on the tap (Fig.6-2).
  • Page 17 6-Daily use Care chart Washing Washable up to 95°C Washable up to 60°C Washable up to 60°C normal process normal process mild process Washable up to 40°C Washable up to 40°C Washable up to 40°C normal process mild process very mild process Washable up to 30°C Washable up to 30°C Washable up to 30°C...
  • Page 18 6-Daily use 6.5 Selecting detergent Washing efficiency and performance is determined by detergent quality. ► Use only machine wash approved detergent. ► If needed use specific detergents, e.g synthetic and woolen fabric. ► See tips for countertop detergent stickers. ► Do not use dry cleaning agents such as trichloroethylene and similar products.
  • Page 19 6-Daily use 6.6 Adding detergent 1. Slide out the detergent drawer. 2. Put the required chemicals into corresponding compartments (Fig. 6-4). 3. Push back the drawer gently. Note: Odour removal Remove detergent residues before next wash cycle from the detergent drawer. ►...
  • Page 20 6-Daily use 6.10 Start wash programme Touch "Start/Pause" button (Fig. 6-8) to start. The LED of the "Start/ Pause" button stops flashing and lights up continuously. Appliance operates according to present settings. Changes are only possible by cancelling the programme. 6.11 Interrupt/ cancel wash programme To interrupt a running programme touch gently "Start/Pause".

  • Page 21: 7-Hon

    Wi-Fi icon appears on the display. 7.3 Download and installation of hOn App: Download the hOn App on your device by framing the following QR code: or by the link: go.haier-europe.com/download App Frequency rate(OFR) 2400 MHz-2483.5 MHz Max.
  • Page 22 7-hOn 7.4 Registration and App Pairing 1. Connect the smartphone to the home Wi-Fi network you want to connect the product 2. Open the App. 3. Create the user profile (or log-in if it is already created previously). 4. Press the " "...
  • Page 23 7-hOn 7.8 Configuration information deleted 1. Long press" " button for 5 seconds, " Do you want to reset the Wi-Fi credentials?" displayed on the control panel; 2. Press "Yes" to confirm; 3. Configuration information is deleted. Note: Network credentials cancellation/reset Follow this procedure only if you are going to sell your washer.

  • Page 24: 8-Eco-Friendly Washing

    8-Eco-friendly washing 8-Eco-friendly washing Environmentally responsible use To achieve best use of energy, water, detergent and time you should use the ► recommended maximum load size. Do not overload (hand width clearance above laundry). ► For slightly soiled laundry select the Quick 15' programme. ►...

  • Page 25: 9-Care And Cleaning

    9-Care and cleaning 9.1 Cleaning the detergent drawer 9-Care and clea ning Take always care there are no detergent residues. Clean the drawer regularly (Fig. 9-1): 1. Pull out the drawer until it stops. 2. Press the release button and remove the drawer. 3.
  • Page 26 9-Care and cleaning 9.5 Long periods of disuse If the appliance is left idle for a longer period: 1. Pull out the electrical plug (Fig. 9-6). 2. Turn off water supply (Fig. 9-7). 3. Open the door to prevent formation of moisture and odours.
  • Page 27 9-Care and cleaning 9. Clean carefully pump filter, e.g. using running water (Fig. 9-14). 10. After cleaning, reinstall the handle and tighten it until it does not move. At this time, the handle is in vertical state (Fig. 9-15). 11. Close service flap. CAUTION! Pump filter sealing has to be clean and unhurt.

  • Page 28: 10-Troubleshooting

    10-Troubleshooting Many occuring problems could be solved by yourself without specific expertise. In case of 10- Troubleshooting a problem please check all shown possibilities and follow below instructions before you contact an after sales service. See CUSTOMER SERVICE. WARNING! Before maintenance, deactivate the appliance and disconnect the mains plug from ►...
  • Page 29 10-Troubleshooting 10.2 Troubleshooting without display code Problem Cause Solution Washing machine fails to  Programme is not yet started.  Check programme and start it. operate.  Door is not properly closed.  Close the door properly.  Machine has not been switched on. ...
  • Page 30 10-Troubleshooting Problem Cause Solution  Detergent quantitiy was not  Choose the detergent acc.to the sufficient. degree of pollution and according to manufacture specifications.  Maximum load has been exceeded.  Reduce loading.  Laundry was unevenly distributed in  Loose the laundry. the drum.

  • Page 31: 11-Installation

    11-Installation 11.1 Preparation 11- Installation Take the appliance out of the packaging. ► Remove all packaging material including protecting film on cabinet, polystyrene base, ► keep them out of children's reach. While opening the package, water drops may be seen on plastic bag and porthole. This normal phenomenon results from water tests in the factory.
  • Page 32 11-Installation Note: Keep in safe place Keep all parts of the transport protection in a safe place for later use. Whenever the appliance is to be moved at first reinstall the protection parts. 11.4 Moving the appliance If the machine is to be moved to a distant location, replace the transportation bolts removed before installation to prevent damage: The assembly takes place in reverse order.
  • Page 33 11-Installation 11.6 Drain Water Connection Fix the water drain hose properly to the piping. The hose has to reach at one point a height between 80 and 100 cm above the appliance bottom line! If possible keep always drain hose fixed to the clip at the appliance back. WARNING! Use only the supplied hose set for the connection.
  • Page 34 11-Installation 11.7 Fresh Water Connection Make sure that the gaskets are inserted. 1. Connect the water inlet hose with the angled end to the appliance (Fig.11-12). Tighten the screw joint by hand. 2. The other end connect to a water tap with a 3/4" thread (Fig.11-13).

  • Page 35: 12-Technical Data

    12-Technical data 12.1 Additional technical data 12- Technical data HW100-BD14397U1 Voltage in V 220-240V~/50Hz Current in A Max. power in W 2000 Water pressure in MPa 0.03≤P≤1 Net weight in kg FRONT VIEW WALL TOP VIEW PRODUCT DIMENSIONS HW100-BD14397U1 Overall height of product mm Overall width of product mm Overall depth of product (To main control panel) mm...

  • Page 36: 13-Customer Service

    13-Customer service We recommend our Haier Customer Service and the use of original spare parts, and the 13- Customer s ervice minimum period during which the spare parts for the household washing machine is 10 years. If you have a problem with your appliance, please first check section Troubleshooting.
  • Page 37 13-Customer service Model information is available in the product database at https://eprel.ec.europa.eu/ by searching for the model identifier reported in the field Model of the product label affixed on the product: the link to the model in the product database can be found here below for each model identifier: HW100-BD14397U1...
