- Page 1 Nightstand Assembly Instructions - Please keep for future reference. 3J-A -Length 15.9 inch - Width 16.5 inch - Height 23.1 inch Important– Please read these instructions before assembly.
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly. Please check if all the components and tools listed Please assemble the product as close to its on pages 3 - 4 are received. final position as possible. Please remove all fittings from the plastic bags and Do not place furniture directly in front of separate them into homologous groups.
- Page 3 Components Please check if all the pieces listed below are received. List Reference Description Specifications(mm) Quantity Material Side frame 420*369*22 Steel Upper elbow 401*370*19 Steel Front tube 317*19 Steel Side tube 378*20*28 Steel 372*330*10 Bottom plate Steel 372*372*15 Middle plate Particle board Top plate 372*372*15...
- Page 4 Components Please check if all the pieces listed below are received. A *4 B *4 C *4 Adjusting feet Connectors Screws D *12 E *1 F *1 Screws Screws Screws G *1 H *1 I *1 Screws Spanner Spanner J *2 Screws...
- Page 5 Assembly Instructions Please use the screws correctly, otherwise the product will be seriously damaged ! Step 1 x 4 pcs Step 2 x 4 pcs x 4 pcs...
- Page 6 Assembly Instructions Step 3 x 4 pcs Step 4 x 4 pcs Tighten the screw when adjusting to the appropriate position.
- Page 7 Assembly Instructions Step 5 x 1 pcs x 1 pcs Step 6 x 4 pcs x 2 pcs...
