- Page 1 DGPW2600V-F Gasoline high pressure washer USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. INTRODUCTION ............................. 2 2. TECHNICAL SPECIFICATIONS ......................2 3. SAFETY RULES ............................3 4. PRESSURE WASHER FEATURES ......................6 5. PRESSURE WASHER PARTS ASSEMBLY ................... 7 6. PRESSURE WASHER PARTS LIST ....................... 8 7. OPERATION ............................13 8. MAINTENANCE ............................ 16 9. -
Page 3: Introduction
1. INTRODUCTION Thank you for purchasing this superior quality pressure washer from Daewoo. When operating and maintaining this product as instructed in this manual, your pressure washer will give you many years of reliable service. 2. TECHNICAL SPECIFICATIONS Model: DGPW2600V-F Power: 6 hp/ 4.47 kW... -
Page 4: Safety Rules
3. SAFETY RULES SAFETY SYMBOLS Indicates a potentially hazardous WARNING! Never point the jet at situation which could result in people, animals, the serious injury or death if not avoided. device itself or live electrical devices. Indicates a potentially hazardous situation which could result CAUTION! in damage to equipment or property. - Page 5 Risk of explosion - Do not spray flammable liquids. WARNING! WARNING! High pressure cleaners shall not be used by children or untrained personnel. High pressure hoses, fittings and coupling are important for the safety of the machine. Use WARNING! only hoses, fittings and couplings recommended by the manufacturer. To ensure machine safety, use only original spare parts from the manufacturer or approved WARNING! by the manufacturer.
- Page 6 Stay alert and use common sense. Do not operate this unit if you are under the influence of WARNING! alcohol, drugs, medication or you feel tired. High pressure jets can be dangerous if subject to misuse. The jet must not be directed at WARNING! persons, live electrical equipment or the machine itself.
-
Page 7: Pressure Washer Features
4. PRESSURE WASHER FEATURES A - High pressure hose H - Choke B - Pull cord I - Engine switch C - Detergent tank J - Wheels D - Handle K - Depstick E- Fuel tank L - High pressure hose outlet F - Spray gun M - Water inlet G - Locking trigger... -
Page 8: Pressure Washer Parts Assembly
5. PRESSURE WASHER PARTS ASSEMBLY (10) (10) 10 11 12 13 (10) (10) 14 15 16 (10) 17 18 (18) -
Page 9: Pressure Washer Parts List
6. PRESSURE WASHER PARTS LIST 1. Engine 2. Flat Key 3. Bolts With Flange 4. Water Pump Assembly 5. Siphon Tube 6. Hexagon Socket Button Head Screws 7. Flat Washer 8. Soap Tank Cap 9. Soap Tank 10. Lock Nut 11. - Page 10 Packing List • Pressure washer • Quick start guide • Operator’s manual • Spray gun • Extension wand with quick-connect fitting • High pressure hose • Spray nozzles (5) - 0°, 15°,25°, 40° and soap • Nozzle • Spray gun hook (upper) •...
- Page 11 Install handle (See fig 2) • Install upper frame (handle) onto the lower frame by sliding the handle over the two upright tubes on the lower frame and pressing down firmly until the handle is seated and the two detent pins snap in place.
- Page 12 Attaching the spray gun (See fig 5 & 6) • Screw the spray wand and the trigger handle together until they are secure. • Insert the inlet coupler of the spray hose into the threaded fitting on the high pressure spray gun and thread the black nut on by turning clockwise until it is hand tight.
- Page 13 CAUTION! Oil must be added to unit prior to first use. CAUTION! To avoid spillage, do not overfill fuel tank as gasoline expands. FIG 8 Connecting garden hose to pressure washer (See fig 9) • Run water through the hose for a few seconds to flush any debris from the hose. •...
-
Page 14: Operation
Connect high pressure hose to pump (See Fig 10) • Attach end of high pressure hose to the high pressure outlet on pump. • Follow the same procedure with opposite end to attach high pressure hose to spray wand. FIG 10 7. - Page 15 Starting pressure washer (See Fig 11-12) • Place pressure washer on a level surface. • Turn on water. • Purge the system’s pump of air by releasing the safety and squeezing the trigger of the spray gun. • Attach wand/lance to spray gun. •...
- Page 16 Using the spray gun (See Fig 14 - 15) • Flip the lock tab behind the trigger up or down until it clicks to apply or remove the safety. Pull back on the trigger to begin operating pressure washer. • To stop water flow, release trigger. SLOT LOCK OUT TRIGGER...
-
Page 17: Maintenance
Applying detergent • Rinse surface with cool water before applying cleaner. • Prepare detergent as required by job. For best results follow detergent directions as supplied from manufacturer. • Remove cap from detergent container and fill. • Spray detergent on surface. For best results use long, even, and overlapping strokes. Allow deter- gent to set for about 3 minutes before rinsing, but do not allow detergent to dry on surface or it may cause streaking or cause damage to the surface. - Page 18 Remove debris • Use a damp cloth to wipe exterior surfaces. If dirt is caked on, use a soft bristle brush. • Clean any debris that has collected around or behind the muffer, cleaning system, and controls. After each use Follow the following procedure after each use: Release water pressure by pointing spray gun in a safe direction and squeezing the trigger.
- Page 19 Checking detergent siphoning tube • Check the detergent siphoning tube for clogs, leaks, or tears. • Make sure the tube fits tightly to the pump fitting. • Replace siphoning tubes if damaged. WARNING! Never repair high pressure hose or use unit if hose is damaged. If hose is damaged replace with identical Ducar part.
- Page 20 Air filter A dirty air filter will reduce the life span of the engine, make starting the engine difficult, and reduce the unit`s performance. • To clean, remove the air filter cover. • Carefully pull the air filter out by lifting up along the edges. •...
- Page 21 9. TROUBLESHOOTING PROBLEM CAUSE SOLUTION Engine does not start 1. Out of fuel 1. Fill fuel tank 2. Engine oil low 2. Add engine oil 3. Spark plug wire disconnected 3. Connect spark plug wire from spark plug 4. Replace spark plug 4.
-
Page 22: Diagram
10. DIAGRAM Ignition switch Oil alert unit Spark plug Ignition coil Oil sensor BLACK YELLOW... - Page 23 Manufactured under license of Daewoo International Corporation, Korea...
