- Page 1 DAX100-1200/DAX100-1400 High pressure washers USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. IMPORTANT SAFETY PRECAUTIONS, TIPS, WARNINGS, AND USAGE INSTRUCTIONS ....................2 2. ASSEMBLY INSTRUCTIONS ........................6 3. OPERATING INSTRUCTIONS, INFORMATION FOR USAGE..............9 4. CLEAN-UP AND STORAGE ........................12 5. CLEANING TIPS ............................ 13 6. TECHNICAL DATE ..........................14 7. -
Page 3: Important Safety Precautions, Tips
1. IMPORTANT SAFETY TIPS Never point the high-pressure nozzle at people or animals. Never drink alcohol or use drugs while operating the pressure cleaner. Never operate the pressure cleaner while standing in water. Never touch the electrical plug with wet hands. Never let electrical connections rest in water. - Page 4 the earth circuit. (Only for recommend). 1. Read all instructions before using the product. Save all safety instructions. 2. Do not operate the pressure cleaner when fatigued or under the influence of alcohol or drugs. 3. Risk of injection or injury – do not direct the high pressure water stream at any people or animals. 4.
- Page 5 10. Must be connected to the water supply before use,then open gun trigger and open the cleaner switch. 11. After the machine long-stalled again before use, please dial the few motor power is in the state of the impeller, and then start the machine according to operation instruction. SYMBOLS The labels on your tools and manual may show symbols.
- Page 6 SERVICING OF A DOUBLE-INSULATED APPLIANCE In a double-insulated product, two systems of insulation are provided instead of grounding. No means of grounding is provided on a double-insulated product, nor should a means for grounding be added to the product. Servicing a double-insulated product requires extreme care and knowled- ge of the system, and should be done only by qualified service personnel.
-
Page 7: Assembly Instructions
2. ASSEMBLY INSTRUCTIONS UNPACKING THE CARTON After opening the carton, please remove all parts and check them against the following list of com- ponents that are included: 1. Gun & Accessories holder 2. High pressure hose hook 3. Power washer unit 4. - Page 8 the extension wand(8). Insert the Turbo nozzle in the same manner, depending upon which attach- ment is best suited to the surface you are cleaning. Only one attachment can be inserted into the.extension wand(8) at a time. All attachments must be inserted into the extension wand(8) for proper use.
- Page 9 STEP 4 Attach the high pressure hose(11)to the gun(9). Insert and quick-connect it tight to avoid leaka- ge.When the pieces are joined properly, you cannot separate the two components by pulling strai- ght out from the gun(11) Push the hose lock button, then you can pull out high pressure hose. STEP 5 Insert the detergent nozzle(5) into the gun(9).
-
Page 10: Operating Instructions, Information For Usage
3. OPERATING INSTRUCTIONS WARNING: THIS UNIT IS INTENDED TO BE USED WITH COLD WATER ONLY! DO NOT USE HOT WATER IN THIS PRESSURE CLEANER! WARNING: High pressure hose must not loop. Starting Up Warning: ALWAYS turn off the unit's motor BEFORE turning off the unit's water supply. Serious damage could occur to the motor if the unit is run without water. - Page 11 CAUTION: Never disconnect the high -pressure discharge hose from the machine while the system is still pressurized . To depressurize the unit, turn off the motor,turn off the water supply and squeeze the trigger 2-3 times. 2. Hold the gun Whenever you use the high pressure washer , we suggest you grip the in the right position,with one hand on the handle and the other on the adjustable spray nozzle.
- Page 12 5. Adjustable Spray Nozzle The adjustable nozzle will allow you to use any variety of spray patterns from a full fan spray (dia- gram 1) to a direct stream spray (diagram 2). When using the pressure cleaner to clean wood decks, siding, vehicles etc., always start using the fan spray and begin spraying from a minimum 36”...
-
Page 13: Clean-Up And Storage
4. CLEAN-UP AND STORAGE Shutting Down the Pressure Cleaner WHEN FINISHED USING THE PRESSURE CLEANER, FOLLOW THESE STEPS TO SHUT DOWN THE UNIT: • Turn the pressure cleaner to the OFF position. • Turn off the water supply. • Before disconnecting high-pressure hose connection, point the gun in a safe direction and discharge the high-pressure water. -
Page 14: Cleaning Tips
5. CLEANING TIPS WARNING: ALWAYS TEST THE SPRAY IN AN AREA FREE AND CLEAR OF PEOPLE AND OBJECTS BEFORE YOU SPRAY AT THE INTENDED CLEANING SURFACE. Wood and Vinyl Decks Rinse deck and surrounding area with fresh water. If using detergent, fill the detergent reservoir and apply to the area being cleaned at low pressure. -
Page 15: Technical Date
6. TECHNICAL DATA Model DAX100-1200 DAX100-1400 Voltage/Frequency 110-240V/50-60Hz Power 1200 W 1400 W Rated pressure 55-65 bar 80 bar Max pressure 100 bar 110 bar Rated flow 4.8 +/- 0.2 l/min 5.5 l/min Max flow 6.5 l/min 6.5 l/min Max pressure inlet water 1.2 MPa... -
Page 16: Warranty
THE PRESSURE CLEANER MAKES EXCESSIVE NOISE PROBABLE CAUSE SOLUTION Intake is blocked Check the intake valves Valves are worn, dirty, or clogged Check, clean or replace valves Filter is dirty Check, clean, or replace filter THE MOTOR STOPS RUNNING WHILE IN USE PROBABLE CAUSE SOLUTION Net voltage lower than suggested... - Page 17 Manufactured under license of Daewoo International Corporation, Korea...
