PUMP
INSTALLATION AND OPERATING INSTRUCTIONS
ELECTRONICS AND PUMP COMPONENTS ASSEMBLED IN THE USA
MONITORING SOFTWARE AND TECHNOLOGY MADE IN THE USA
READ ALL INSTRUCTIONS CONTAINED IN THIS MANUAL BEFORE USING THIS PRODUCT.
Save these instructions for future reference. Failure to read and follow the warnings and instructions
within this instruction manual could result in property damage, serious injury or death.
Contact Tech Support:
SPY
34000 Lear Industrial Parkway, Avon, OH 44011
(833) 786-7779
WIFI CONNECTED BATTERY BACKUP
®
SUMP PUMP & MONITORING SYSTEM
24/7 AUTOMATED REMOTE SUMP PUMP MONITORING
support@PumpSpy.com
Power Supply Requirements
Motor
AMP Rating
Temperature Rating
Discharge
MAX Flow
Power Supply Requirements
Electrical Ratings
Relative Humidity
Storage Temperature
Operating Temperature
support@pumpspy.com
12 VDC
Brushless DC
18 Amps
40°F to 120°F
1 1/2" NPT
3000 GPH
120 VAC, 60 Hz,
15 AMP
12Amps @ 120 VAC;
18 Amps @ 12 VDC
0 to 80%
0° to 70°C
0° to 50°C
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for PumpSpy PS2000
Summary of Contents for PumpSpy PS2000
- Page 1 ® SUMP PUMP & MONITORING SYSTEM 24/7 AUTOMATED REMOTE SUMP PUMP MONITORING INSTALLATION AND OPERATING INSTRUCTIONS support@PumpSpy.com 34000 Lear Industrial Parkway, Avon, OH 44011 ELECTRONICS AND PUMP COMPONENTS ASSEMBLED IN THE USA MONITORING SOFTWARE AND TECHNOLOGY MADE IN THE USA...
-
Page 2: Safety First
Cables should be protected at all times to avoid punctures, cuts and abrasions that may result in exposed wiring. Never handle connected power cords with wet hands. The PumpSpy System has not been investigated for use in or around swimming pools, marine areas, ™... -
Page 3: Installation
UNPACKING Inspect this unit before beginning installation. Occasionally, products are damaged during shipment. If the pump or any components are damaged, contact PumpSpy at support@pumpspy.com for replacement. ™ INSTALLATION WARNING • • • • • • 1. The backup pump has a 1-1/2 in. NPT discharge. - Page 4 Position all switches so they will not interfere with any portion of the plumbing, wiring, or sump pit. 3. Your PumpSpy system activates and tests the backup pump and battery health at least 3 times per week.
- Page 5 7. Connect the PumpSpy controller to the battery. Black to – (negative), Red to + (positive). Replace and lock the lid onto the battery case. The PumpSpy system will initialize and boot up. All status LEDs will initially be GREEN. Within 20 seconds, the Power and WiFi status LEDs will turn RED.
- Page 6 • After entering your info, press Done. Enter your WiFi Network Credentials • Press the home button on your device. • On the PumpSpy App. Your screen will go dark for a couple seconds. • PumpSpy Setup Screen appears STEP 3: Enable WiFi Setup Mode on the PumpSpy System •...
- Page 7 PumpSpy” appears, press Join • Return to the home screen on your device. • If “No Device Found” message appears , press “Try Again” “PumpSpy’ would like to find and connect to devices on your local STEP 3: network appears, press “OK”...
-
Page 8: What This Warranty Does Not Cover
PumpSpy™ product is warranted against original defects in material and workmanship for a full three years from date of purchase (the “Warranty Period”). During the warranty period, PumpSpy™ will repair or replace at no cost to you, to correct such defects in products found upon examination by PumpSpy™ to be defective in materials or workmanship.
