PUMP
INSTALLATION AND OPERATING INSTRUCTIONS
PumpSpy Technology | support@PumpSpy.com
ELECTRONICS AND PUMP COMPONENTS ASSEMBLED IN THE USA
MONITORING SOFTWARE AND TECHNOLOGY MADE IN THE USA
PumpSpy
The PumpSpy System requires a 12V Deep Cycle Battery (not included), 40 amp/hr
minimum, 75 amp/hr or higher recommended. SLA/AGM Battery strongly recommended.
READ ALL INSTRUCTIONS CONTAINED IN THIS MANUAL BEFORE USING THIS PRODUCT.
Save these instructions for future reference. Failure to read and follow the warnings and instructions
within this instruction manual could result in property damage, serious injury or death.
© PumpSpy Technology, LLC Questions? Email Tech Support:
SPY
34000 Lear Industrial Parkway, Avon, OH 44011
PS2000
™
IMPORTANT!
WIFI CONNECTED BATTERY BACKUP
®
SUMP PUMP & MONITORING SYSTEM
24/7 AUTOMATED REMOTE SUMP PUMP MONITORING
SPECIFICATIONS
12 VDC Sump Pump
Power Supply Requirements
Motor
AMP Rating
Temperature Rating
Discharge
MAX Flow
System Solid State Pump Controller
Power Supply Requirements
Electrical Ratings
Relative Humidity
Storage Temperature
Operating Temperature
support@pumpspy.com
12 VDC
Brushless DC
18 Amps
40°F to 120°F
1 1/2" NPT
3000 GPH
120 VAC, 60 Hz,
15 AMP
12Amps @ 120 VAC;
18 Amps @ 12 VDC
0 to 80%
0° to 70°C
0° to 50°C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PumpSpy PS2000
Summary of Contents for PumpSpy PS2000
- Page 1 0° to 70°C Operating Temperature 0° to 50°C The PumpSpy System requires a 12V Deep Cycle Battery (not included), 40 amp/hr minimum, 75 amp/hr or higher recommended. SLA/AGM Battery strongly recommended. IMPORTANT! READ ALL INSTRUCTIONS CONTAINED IN THIS MANUAL BEFORE USING THIS PRODUCT.
-
Page 2: Safety First
Do not attempt to disassemble the PumpSpy controller or Backup Pump. There are no field serviceable parts or repair options! RISK OF EXPLOSION. TO REDUCE THIS RISK, OBSERVE THE FOLLOWING WARNINGS: WARNING! Do not use to pump flammable or explosive liquids such as gasoline, fuel oil, kerosene, etc. -
Page 3: Installation
PumpSpy at support@pumpspy.com for replacement. ™ The PumpSpy System requires a 12V Deep Cycle Battery with a minimum 40 AMP/HR rating, 75 AMP/HR rating (or higher) recommended. AGM Battery is strongly recommended. INSTALLATION... - Page 4 3 times per week. ™ WARNING! PUMPSPY SYSTEM TESTS MAY OCCUR AT ANY TIME. THE BACKUP PUMP MAY CYCLE AT ANY TIME WITHOUT NOTICE. This pump was not designed to handle salt water, brine, laundry...
- Page 5 REFILL BASIN WITH WATER. Cycle the Primary Sump Pump. The alarm will stop and MAIN PUMP will be green. WIFI will turn GREEN after the completing the WiFi setup with the PumpSpy app. © PumpSpy Technology, LLC Questions? Email Tech Support:...
- Page 6 Your PumpSpy system, once online, connects to PumpSpy’s Remote Monitoring Service. PumpSpy watches over your system automatically, 24 hours a day. PumpSpy collects operating data on your sump pumps and battery and analyzes this information to make sure your pumps are always in top working condition.
- Page 7 ADDING YOUR DEVICE MANUALLY If you hare having issues with setting up your PumpSpy device via the app, you can manually set up the device. This process works on all Apple and Android devices. • On your Apple/Android device, go to Wi-Fi settings and connect to the PumpSpy device’s Wi-Fi network...
-
Page 8: Limited Three-Year Warranty
PumpSpy™ product is warranted against original defects in material and workmanship for a full three years from date of purchase (the “Warranty Period”). During the warranty period, PumpSpy™ will repair or replace at no cost to you, to correct such defects in products found upon examination by PumpSpy™ to be defective in materials or workmanship.
