  • Page 1 ROSS CONTROLS...
  • Page 2 In-line Relief Valves MINIATURE Series Port Sizes: 1/8 & 1/4 – Flow to 40 scfm Pressure Range psig (bar) Port Port 1-15 (0.07-1.0) 1-30 (0.07-2.1) 1-50 (0.07-3.4) 1-140 (0.07-9.6) Size Threads Model Number Model Number Model Number Model Number NPTF...
  • Page 3 In-line Relief Valve HIGH-FLOW Series Port Sizes: 1 – Flow to 450 scfm Model Number Port Size NPTF Threads G Threads 5X00D6012 C5X00D6012 Port A Dimensions inches (mm) Port B Weight Port Size lb (kg) Depth ISO Symbol 4.4 (111) 4.8 (122) 2.5 (62) 2.9 (72)

  • Page 4: Mounting Accessories

    Mounting Accessories Brackets & Bracket Kits FRL’s Series Mounting Screws for BANTAM Models Usage Models Kit Number BANTAM models mounts with long screws that extend through end plates. BANTAM 859K77 Mounting Brackets for Regulators and Integrated Filter/Regulators MINIATURE Regulators and integrated filter/regulators can be mounted to a surface with a bracket that attaches to the regulator.
  • Page 5 Large O-Ring (for outlet or mating ports) 861K77 10 mm 871K77 IMPORTANT NOTE: CAUTIONS, WARNINGS Please read carefully and thoroughly all of the on the inside back cover. Online Version E6.4 © ROSS CONTROLS . All Rights Reserved. ® 04/05/19...
  • Page 6 Lubricants, Polycarbonate Bowl Cautions Compatible Lubricants Although air line lubrication is not required for most ROSS valves, other mechanisms in the system may need such lubrication. When a lubricator is used, it should be supplied only with oils which are compatible with the materials used in the valves for seals and poppets.

  • Page 7: Standard Warranty

    When bowl gets dirty, replace it or wipe it with a clean dry cloth. All products sold by ROSS CONTROLS are warranted for a one-year period [with the exception of all Filters, Regulators and Lubricators (“FRLs”) which are...
  • Page 8 ROSS ASIA K.K. ROSS CONTROLS ROSS EUROPA GmbH rosscontrols.com rossasia.co.jp rosseuropa.com Customer Service 1-800-GET-ROSS (438-1800) United Kingdom India Technical Service ROSS CONTROLS INDIA Pvt. Ltd. ROSS UK Ltd. 1-888-TEK-ROSS (835-7677) +44-1543-671495 rosscontrols.com sales.uk@rosscontrols.com Canada rossuk.co.uk China ROSS CANADA ROSS CONTROLS (CHINA) Ltd.
