- Page 1 Release Version 1.0 IP Over Coaxial Transmission Solution SC-IPC0704H(SC-IPT07P + SC-IPR0704H) User Guide SC-IPT07P SC-IPR0704H...
- Page 2 Release Version 1.0 Precaution and Safety Guidelines The content of this guideline is intended to protect user safety and prevent property damage. Please read this user guide carefully and use the device properly Warning (Failure to adhere to any of the following guidelines could result in serious injury or death for someone.) ■...
- Page 3 Release Version 1.0 Caution (If you do not keep any of the below guidelines, you may get injured or suffer property loss.) ■ Avoid installing near strong magnetic fields or radio waves and wireless devices such as radio or TV. - Install in a place that is free from magnetic, radio, or excessive vibration.
- Page 4 1. 1. Introduction 1-1. Overview SC-IPC0704H consists of SC-IPT07P (transmitter), a 1-channel power overlapping IP transmission device, and SC-IPR0704H (4-channel receiver) dedicated to EoC (Ethernet over Coax.) equipped with Switch HUB function. By using an existing coaxial cable, power can be transmitted to the transmitter...
- Page 5 Release Version 1.0 3. Product Parts and Functions 3-1. 1CH Transmitter ① ② ③ ④ ① CAMERA PoE: Switch to set power supply to PoE IP camera. ※ In case of connecting PoE IP camera, set CAMERA PoE switch as ON. ※...
- Page 6 ② ③ ① ④ ⑤ ⑥ ⑦ ① COAXIAL LINK / TX Side : SC-IPT07P(Transmitter) connection port(BNC 4Port). ② NVR Side : NVR or Network equipment connection port(RJ-45 1Port). Name Color Status Description Flashing When transmitting and receiving data normally...
- Page 7 Release Version 1.0 4. CABLE PIN Configuration Color 기능 White Orange Orange White Green PWR+ Blue White Blue PWR+ Green White Brown PWR- PWR- Brown 5. Sample of connection ※ It is not recommended for products to touch each other or be tied together. ※...
-
Page 8: Transmission Distance
Release Version 1.0 6. Transmission Distance 1) The power supply of the receiver cannot exceed 90W. 2) The maximum power supplied to one channel of the receiver cannot exceed 37W. 3) The power indicated in the table refers to the transmitter output power depending on the cable distance. 6-1. -
Page 9: Specifications
(set the CAMERA PoE switch on the transmitter to OFF). 7. Specifications Model SC-IPT07P Power Input PoC (from SC-IPR0704H) Power Output Midspan PoE (Type B Only, PoE SW ON/OFF) -
Page 10: Troubleshooting Method
Release Version 1.0 8. Troubleshooting Method Condition Check Method • Check the power cable connection state. Power is not • Check if the exclusive adapter is used. • Check the PoE switch hub connection state. supplied. • Check the CABLE PIN configuration state. •... -
Page 11: Warranty Certificate
Release Version 1.0 9. Warranty Certificate This product has passed thorough quality control and test, and if this gets broken during normal use, we provide the two-year warranty service. Model No. Serial No. Distributor Date you purchased Place you purchased Warranty Period Two (2) year from the date of purchase Name... - Page 12 Release Version 1.0 SeeEyes Co., Ltd #503~509, 511~512, Sunil Technopia, 555 Dunchon-daero, Jungwon-gu, Seongnam City, Gyeonggi Province, Korea (Zip Code: 13215) TEL: +82-(0)31-730-5833 FAX: +82-(0)31-777-3512 EMAIL: overseas@sscctv.com http://www.sscctv.com/eng...
