- Page 1 Release Version 1.1 8-channel EoU Transmission kit with built-in PoE Switch HUB SC-IPC0708HU User Manual TRANSMITTER RECEIVER...
- Page 2 Release Version 1.1 Precaution and Safety Guidelines The content of this guideline is intended to protect user safety and prevent property damage. Please read these operating instructions carefully and use the device properly. Warning (If you do not keep any of the below guidelines, you may get seriously injured or cause somebody’s death.) ■...
- Page 3 Release Version 1.1 Caution (Failure to follow any of the following guidelines could result in personal injury or property damage.) ■ Avoid installing near strong magnetic fields or radio waves and wireless devices such as radio or TV. - Install in a place that is free from magnetic, radio, or excessive vibration. ■...
-
Page 4: Product Components
Release Version 1.1 1. Introduction 1-1. summary This product is composed of transmitter, a 1-channel power superimposed IP transmission device, and 8-channel receiver with Switch HUB function. Using an existing UTP cable, it transmits power to the transmitter and IP camera with one UTP cable, and at the same time receives the IP camera signal and transmits multi-channel IP camera data to NVR 1Port. -
Page 5: Name And Function Of Each Part
Release Version 1.1 3. Name and function of each part 3-1. Receiver ① ② ③ ④ ⑤ ⑦ ⑥ ⑧ ⑨ ① POWER : Power ON/OFF Switch ② 1~8channel Status LED: Power status of each channel and Link/Act. information display. Name State State Description... - Page 6 Release Version 1.1 3-2. Transmitter ① ② ③ ④ ① CAMERA PoE: Switch for setting the power supply of the IP PoE camera. ※ When connecting an IP PoE camera, set the CAMERA PoE switch to ON. ※ When the product is shipped, the PoE switch is set to PoE ON. ※...
- Page 7 Release Version 1.1 4. CABLE PIN Array (10/100, Mode B) Number Color 10/100 T568A T568B Mode B white + green white + orange green Orange white + orange white + green blue blue white + blue white + blue Orange green white + brown white + brown...
- Page 8 Release Version 1.1 6. Power supply table (Actual value) Transmission Loop Bandwidth 48V SMPS distance(Cat.5e) Resistance ※ The cables in the table above are based on Cat.5e made by LS. ※ Cable transmission distance may vary depending on specifications such as camera and NVR. ※...
-
Page 9: Product Specification
Release Version 1.1 8. Product specification Model name Transmitter Power input PoE (Power input from Receiver via PoE) Power output Midspan PoE support (Type B only, PoE Switch On/Off available) Bandwidth 100Mbps Full Duplex RJ-45 (TIA/EIA568B RJ-45 (TIA/EIA568B Type) Type) Connection port RJ-45 (TIA/EIA568B... -
Page 10: Troubleshooting
Release Version 1.1 9. Troubleshooting Symptom Identification method <Transmitter> • Check if the receiver's PoE LED is on and the transmitter's PWR LED is on. • Check the UTP cable connection. No Power. <Receiver> • Check the AC power cable. •... -
Page 11: Warranty Certificate
Release Version 1.1 10. Warranty Certificate This product has passed thorough quality control and test, and if this gets broken during normal use, we provide the two-year warranty service. Model No. Serial No. Distributor Date you purchased Place you purchased Warranty Period Two (2) year from the date of purchase Name... - Page 12 Release Version 1.1 SeeEyes Co., Ltd #503~509, 511~512, Sunil Technopia, 555 Dunchon-daero, Jungwon-gu, Seongnam City, Gyeonggi Province, Korea (Zip Code: 13215) TEL: +82-(0)31-730-5831/5833 FAX: +82-(0)31-777-3512 EMAIL: overseas@sscctv.com http://www.sscctv.com/eng...
