Parts List - snode SNODEALL9 Instruction Manual

PART NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26

PARTS LIST

Name&Specification
Left rear riser frame
Right rear riser frame
Rear connecting bracket
Left bottom bracket
Upper left top bracket
Upper right top bracket
Bottom connection plate
Top connection plate
Side riser
Barbell placement fittings
Safety Hanger L
Safety Hanger R
Lower fixed U-holder
Upper fixed U-holder
Left barbell pendant weldment
Right barbell pendant weldment
Barbell bar casing frame
Slip Tube
Right handle adjustment bracket
Left handle adjustment bracket
Pivot Pulley Rack
Top beam cross-tube bracket 1
Right bottom bracket
Left long limiting bracket
Left double bar rack
Left short limiting bracket
4
QTY
1 PC
1 PC
2 PCS
1 PC
1 PC
1 PC
4 PCS
4 PCS
2 PCS
4 PCS
1 PC
1 PC
2 PCS
2 PCS
1 PC
1 PC
2 PCS
2 PCS
1 PC
1 PC
2 PCS
1 PC
1 PC
1 PC
1 PC
1 PC
