ASSEMBLY INSTRUCTIONS
1. Take out 2PCS Pull strap (66), 2PCS Locking buckle (42), as shown in the figure, connect 2PCS Pull
strap (66), 2PCS Locking buckle (42) to the left and right wire rope interface respectively.
2. Take out the Left long limiting bracket and Right long limiting bracket (24, 58), Left double bar rack and
Right double bar rack (25, 59), Left short limiting bracket and Right short limiting bracket (26, 61),
according to the diagram, put these components on the slide tube.
3. Take out 2PCS Sponge stick sleeve (112), 2PCS foam cover (113), 1PC Bracket for placing legs (111),
1PC Elastic pin (130), 1PC Ball head long pin (131) and 1PC Ball head short pin (124), and put these
components on the slide tube as shown in the figure.
