Cudy POE220 Quick Installation Manual

4
Specifications
Model POE220
No. of channels 2
Pass Through Data Rates 10/100/1000Mbps
Pin Assignment and Polarity 1/2 (-), 3/6 (+),
Output Power Voltage 54Vdc
User Port Power Up to 30W per port
AC Input Voltage 100 to 240 Vac
AC Input Current 0.8A 100-240 Vac
AC Frequency
50 to 60 Hz
System Indicator AC Power
User Indicator Channel Power
Connectors Shielded RJ-45, EIA 568A and 568B
Operating Ambient
0 to 40℃
Temperature
Maximum 80%, Non-condensing
Operating Humidity
Storage Temperature -20 to 70℃
Maximum 80%, Non-condensing
Storage Humidity
IEEE 802.3af (15.4W)
Regulatory Compliance
IEEE 802.3at (30W)
CE Mark Warning
This is a class B product. In a domestic environment, this product
may cause radio interference, in which case the user may be
required to take adequate measures.
EU declaration of conformity
Cudy hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of directives
2014/30/EU, 2014/35/EU, 2015/863/EU, 2009/125/EC and
2011/65/EU. The original EU declaration of conformity can be
found at http://www.cudy.com/ce
For support and warranty, please visit: http://www.cudy.com/.
Specifications are subject to change without notice. Cudy is a
registered trademark of Shenzhen Cudy Technologies Co., Ltd.
Other brands and product names are trademarks or registered
trademarks of their respective holders.Copyright©2023 Shenzhen
Cudy Technology Co., Ltd. All rights reserved.
Quick Installation Guide
Model: POE220
810600180
