Cudy POE40 Quick Installation Manual

4
Specifications
Model POE40
Data Speed
10/100/1000 Mbps half/full duplex
Power over Ethernet Pin Assignment and Polarity:
input Both 1/2, 3/6 and 4/5, 7/8
Pin Assignment and Polarity:
1/2 (+), 3/6 (-)
Power over Ethernet
Output
Output Power: Up to 12W for 4 PSE
or MAX 30W for 2 PSE
Power indicator: PoE enabled
Indicator
Powered success: Power
Network indicator: Link/Act
Shielded RJ-45, EIA 568A and 568B
Connectors
Shielded category 5 (or higher)
Network cables
Dimensions 119mm x 85mm x 28mm
Mounting Wall or shelf
Environment Indoor
Regulatory Compliance IEEE 802.3af (15.4W)
IEEE 802.3at (30W)
IEEE802.3bt 4Pairs (60W)
Operating Temperature 0 to 40℃
Operating Humidity Maximum 90%, Non-condensing
Storage Temperature
-40 to 60℃
Storage Humidity Maximum 95%, Non-condensing
CE Mark Warning
This is a class B product. In a domestic environment, this product
may cause radio interference, in which case the user may be
required to take adequate measures.
EU declaration of conformity
Cudy hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of directives
2014/30/EU, 2014/35/EU, 2015/863/EU, 2009/125/EC and
2011/65/EU. The original EU declaration of conformity can be
found at http://www.cudy.com/ce
For support and warranty, please visit: http://www.cudy.com/.
Specifications are subject to change without notice. Cudy is a
registered trademark of Shenzhen Cudy Technology Co., Ltd.
Other brands and product names are trademarks or registered
trademarks of their respective holders.Copyright©2022 Shenzhen
Cudy Technology Co., Ltd. All rights reserved.
