Cudy P4 Quick Installation Manual

3
Check the LED.
When the LED is in yellow or white,
the router is connected to the cellular
network.
If the LED is in red, please continue
to configure the router.
Status 5G Model
Name
Off
Flash
Solid
Off
Red
Yellow 4G/3G/2G
White 5G/WAN
Off
Flash
Solid
Off
Red
Yellow
White
Note: If the signal is still too weak indoors, try installing your
extension antennas (not included in the box) to the SMA
connector and placing the antennas outdoors.
Cudy- **** -5G
Auto Connect
Cudy- **** -5G
Password
Next
Go to Step 5 and continue.
SIM
Nano SIM
1
4
Connect to the router via
method.
B
Wired:
computer and connect it to the router's
LAN
port via an Ethernet cable.
Connect
LAN
Cancel
2
A or B
Turn off the Wi-Fi on your
1
According to the engraved SIM
direction, insert your Nano SlM card
into the slot until you hear a clicking
sound.
Note: No hot-swapping. Please insert or remove the SIM
card while the system is powered off.
2
Connect the power adapter to the
router, and wait for 2~5 minutes until
the system LED turns solid on.
Here to install antennas when necessary.
A
Wi-Fi: Connect your device to the
router's Wi-Fi using the SSID (network
name) and Password printed on the
bottom of the router.
2.4G SSID:
5G SSID:
Password:
5
Open a browser and follow
below pictures to log in the router.
Edge Chrome Firefox Safari
http://cudy.net/
http://cudy.net/
http://cudy.net/
Create an administrator password
Create a password
Confirm
