Remove the mop cloth from the mopping
module. Wash and air dry the mop cloth.
Notes:
• After cleaning, always remove the mop cloth to
prevent dirty water from leaching back into the clean
water tank.
• A dirty mop cloth will compromise the washing
performance. Clean it before use.
Filter Components
C8
* Replace them every 1 to 3 months
C8-1—Mop Attachment Slot
1. Move your finger along the notch to
remove each filter.
2. Insert new filter components and make
sure they are properly installed.
Note: To ensure cleaning performance, replace the filter
components every 1 to 3 months, depending on the
water quality and how often you use the robot.
Dust Bag Replacement
C9
* Replace as required.
C9-1— Remove the dustbin cover vertically
as shown.
C9-2— Lift the dust bag out of the dustbin
and discard it.
The dust bag handle seals the bag on removal to
Note:
prevent dust leakage.
C9-3— Clean the filter with a dry cloth.
C9-4— Install a new dust bag in place along
the slot and put the dustbin cover
back.
Air Duct
C10
* Clean as required.
C10-1— Unscrew the screws (10) and
remove the cover.
C10-2— Wipe the air duct and cover with a
dry cloth.
C10-3— Reinstall the cover and screw it
back in place.
Charging Contact Areas
C11
* Clean as required.
Use a soft dry cloth to wipe the charging
contacts on the robot. Clean the dock
location beacon, charging contacts, and
electrode brushes on the dock.
Battery
The robot is equipped with a high-
performance lithium-ion rechargeable
battery pack. To maintain battery
performance, keep the robot charged during
normal use.
If the robot will be left unused for a long period,
Note:
turn it off and charge it at least every three months to
avoid battery damage caused by over-discharge.
12
Environmental protection
description
The chemical substances contained in the
built-in lithium-ion battery of this product
can cause environmental pollution.
Before disposing of this product, remove
the battery. The battery should then be
properly recycled either through local
authorities or by providing the batteries to a
battery recycling facility.
How to remove the battery:
Note: The following information is only suitable for the
situation that the robot will be disposed of or its battery
cannot function normally after recharging.
1. Operate the robot without connecting to
the dock until it runs out of battery.
2. Turn off the robot.
3. Unscrew the battery cover.
4. Remove the battery cover.
5. Press the clip to pull out the battery connector.
6. Remove the battery.
Notes:
• Before removing the battery, make sure it is fully
drained. Do not attempt to remove the battery if the
robot is connected to the charging dock.
• Remove the entire battery pack. Avoid damaging the
battery pack casing to avoid short-circuits or leakage
of hazardous substances.
• In the event of accidental contact with battery fluid,
rinse thoroughly with water and seek immediate
medical care.
