  • Page 1 USER MANUAL MICROWAVE OVEN MANUALE D'USO FORNO A MICROONDE F457MODMWLXC F457MODMWLNC...
  • Page 2: Table Of Contents

    Installation instructions......................27 Installation ..........................28 Dear Customer: Thank you for choosing this BERTAZZONI product. We ask you to read the instructions in this booklet very carefully as this will allow you to get the best results from using it.
  • Page 3: Safety Information

    Safety Information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. Children and Vulnerable People Safety Warning! Risk of suffocation, injury or permanent disability.
  • Page 4 • Cleaning and user maintenance shall not be made by children without supervision. General Safety • This appliance is intended to be used in household applications and not in hotels, shops, offices and other similar environments. • Internally the appliance becomes hot when in operation. Do not touch the heating elements that are in the appliance.
  • Page 5 • If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames. • Microwave heating of beverages can result in delayed eruptive boiling. Care must be taken when handling the container.
  • Page 6 • For toasting, use just the grilling function and watch the oven all the time. It you use a combined function to toast bread it will catch fire in a very short time. • Make sure you never catch the power cables of other electrical appliances in the hot door or the oven.
  • Page 7 • Do not use harsh abrasive cleaners or sharp metal scrapers to clean the glass door since they can scratch the surface, which may result in shattering of the glass. • Do not use a steam cleaner to clean the appliance. •...
  • Page 8 Avoid damaging the oven or other dangerous situations by following these instructions • Never switch on the microwave when it is empty. If there is no food inside there may be an electrical overcharge and the oven could be damaged. RISK OF DAMAGE! •...
  • Page 9: Advantages Of The Microwave Oven

    Advantages of the microwave oven In a conventional cooker, the heat that is The friction between the molecules generates radiated through the resistances or gas heat, which raises the temperature of the burners slowly penetrates the foods from the foods, defrosting or cooking them or keeping outside in.
  • Page 10: Description Of The Appliance

    Description of the appliance Control panel Turntable support Door window glass Turntable ring Lateral supports Turntable plate Catches Rectangular Glass tray Hot Air Output Rectangular Rack Control panel Function keys Clock/ Time display/ key – / + Keys Start key Temperature display/ key Stop key Power/Weight display/ key...
  • Page 11: Basic Controls

    Function Description Microwave Power Symbol Function Foods Output 200 W Slow defrosting for delicate foods; keeping food hot. Cooking with little heat; boiling rice. 400 W Rapid defrosting, heating baby food. 600 W Heating and cooking food. Microwave Cooking vegetables and food. 800 W Cooking and heating carefully.
  • Page 12: Cooking Functions

    2. Press – and + keys (2) to set the hours. If you want to see the clock display again, press the Clock/ Time display/ key (5) again 3. Press again the Clock/ Time display/ key for 3 seconds. (5) to set the minutes. The minute numbers will start to flash.
  • Page 13 NOTE: When 1000 W power is selected, the 2. Press the Temperature display/ key (3) to operating time is limited to a maximum of change the temperature. The respective 15 minutes. light will flash. If you do not press this key, the oven operates at 160 ºC.
  • Page 14: When The Oven Is Working

    6. Press the START key (6). The oven will 1. Press the Grill with Fan function start to operate. key. The function key lights up. The following table shows the defrosting by 2. Press the Temperature display/ key (3) to weight function programmes, indicating weight change the temperature.
  • Page 15: Defrosting

    Altering parameters Cancelling a cooking cycle The operating parameters (time, weight, If you wish to cancel the cooking process, power, etc.) can be altered when the oven is press the Stop key (7) for 3 seconds. operating or when the cooking process has You will then hear a beep and the time will been interrupted by proceeding as follows: appear on the display.
  • Page 16: Cooking With A Microwave Oven

    Defrosting Standing time Recommendation Food Weight (Min.) Time (Min.) Cream cheese 10-15 Creams 10-15 General tips for defrosting temperature, they will be ready to serve within a few minutes. In the case of deep- 1. Only use microwave-safe dishes for frozen cream, if there are little bits of ice, defrosting (porcelain,...
  • Page 17 necessary and you must keep a close eye state, temperature, moisture and type of food. on the cooking process. It is advisable to adjust the times and power • It is not possible to heat large quantities of levels to each situation. Depending on the exact characteristics of the food you may need oil (frying) in the microwave.
  • Page 18: Cooking With The Grill

    Addition of Power Time Standing Food Quantity (g) Instructions liquids (Watt) (min.) Time (min.) Cut into chunks or Paprika 25ml slices Keep covered Leek 50ml Turn once Keep covered Frozen Brussel 50ml sprouts Turn once Keep covered Sauerkraut 25ml 8-10 Turn once Tables and suggestions –...
  • Page 19 Tables and suggestions – Grill without microwave Food Quantity (g) Time (min.) Instructions Fish Spread lightly with butter. After half of Bass 18-24 cooking time turn spread with Sardines/gurnard 6-8 fish. 15-20 seasoning. Meat Sausages 6-8 units 22-26 Prick after half cooking time and turn. Frozen hamburgers 3 units 18-20...
  • Page 20: Roasting And Baking

    Please follow the standing times and don’t The values given in the tables are valid when forget to turn the meat pieces. the oven cavity is cold (it is not necessary to pre-heat the oven). Unless indicated to the contrary, use the turntable plate for cooking.
  • Page 21 Advice on ovenware cold or wet surface the glass may crack and break. Use oven gloves to take the ovenware Check that the ovenware fits inside the oven. out of the oven. Hot glass containers should be put on a dry kitchen cloth.
  • Page 22: What Type Of Containers May Be Used

    What type of containers may be used? • Keep mind manufacturer’s Microwave function recommendations written For the microwave function, keep in mind that packaging. microwaves are reflected by metal surfaces. • The aluminium containers cannot be more Glass, china, clay, plastic, and paper let than 3 cm high or come in contact with the microwaves pass.
  • Page 23: Cleaning And Maintenance

    Table of Ovenware The table below gives you a general idea of what type of ovenware is suitable for each situation. Operating Microwave mode Conventional Combined Type of functions functions dish Defrost / heat Cook Glass and porcelain 1) Domestic, non fire-resistant, may be washed in dishwasher Glazed ceramic Fire-resistant glass and porcelain...
  • Page 24 surface, which may result in shattering of of coffee in the cup to avoid the water boiling the glass. over. Heat the water for 2 to 3 minutes at maximum microwave power. use aggressive or abrasive cleaning products, scourers that scratch Oven ceiling surfaces or sharp objects, since stains If the oven ceiling is dirty, the grill can be...
  • Page 25: What Should I Do If The Oven Doesn't Work

    Accessories Make sure that the turntable plate and the respective support are always clean. Do not Clean the accessories after each use. If they switch on the oven unless the turntable and are very dirty, soak them first of all and then the respective support are in place.
  • Page 26: Technical Characteristics

    - Connect the oven again to the power supply. Technical characteristics Specifications • AC Voltage ..................(see characteristics plate) • Power required ....................3400 W • Grill power......................1500 W • Hot air power ..................... 1500W • Microwave output power................... 1000 W •...
  • Page 27: Installation Instructions

    Installation instructions Before installation After installation Check that the input voltage indicated on The oven is equipped with a power cable and the characteristics plate is the same as the a plug for single phase current. voltage of the power outlet you are going to If the oven is to be installed on a use.
  • Page 28: Installation

    Installation • Push oven completely into the cabinet and centre it. • Open microwave door and fasten the appliance to the cabinet using the four screws provided. Insert the screws through the front holes.
