SM-EZ
Series
Box contents
1 Speaker
1 U-bracket
3 U-bracket screws
2 Screw caps
1 Allen wrench
1 Back plate
1 Port plug
1 Safety cable
1 Strain relief bushing
Safety cable
Strain relief bushing
U- bracket
Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
Install Instructions For:
SM52-EZ-BK, SM52-EZ-WH, SM52-EZ-WX-BK, SM52-EZ-WX-WH,
SM82-EZ-II-BK, SM82-EZ-II-WH, SM82-EZ-II-WX-BK & SM82-EZ-II-WX-WH
Back plate
Screw cap
U-bracket screw
© 2023 SoundTube Entertainment, Inc. All rights reserved. PN INS-SM -EZ Rev 5-24-2023
Warning
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
|
913.663.5600
www.soundtube.com
