NTI TRX II Series Installation Start-Up Maintenance page 78

Part 9 - Controls
Description
Note
4. 2. 3 Heating Curve Offset
When the Reset Curve results in a boiler target
temperature that is too high or too low (i.e., heats the
building too quickly or slowly), Parallel Shift can be used
to offset the curve up or down to increase or decrease the
boiler target temperature.
NOTE: Adjusting Parallel Shift is only possible when Auto
Boost is OFF (4.7.5 = 0).
4. 2. 4 Room Sensor Influence
Adjusts the influence of room temperature on target
boiler temperature - a higher setting causes a greater
increase to the boiler target temperature as the indoor
temperature drops below room setpoint.
Only applicable when using an optional NTI Room
Sensor and when 4.2.1 = 2 or 4.
4. 2. 5 Max Temperature
4.2.5 sets the allowable boiler operating temperature
range for Zone 1 heating, limiting Automatic Temperature
Control and manual adjustments from the User Menu.
4. 2. 6 Min Temperature
4.2.6 sets the allowable boiler operating temperature
range for Zone 1 heating, limiting Automatic Temperature
Control and manual adjustments from the User Menu.
4 2. 8 Quick night setback
4 2. 9 Heat request mode
4. 3 DIAGNOSTICS
4. 3. 0 Room Temperature
Only applicable when using an NTI room sensor
4. 3. 1 Room Temperature
Setpoint
Only applicable when using an NTI room sensor
4. 3. 4 Zone 1 Heat Call
4. 3. 8 Zone flow temperature
setpoint
4. 7 ZONE REGULATION PARAMETERS
4. 7. 5 Auto Slope Boost
See L. Auto Boost.
5 ZONE 2 PARAMETERS
5. 0 TEMPERATURE SETTINGS
5. 0. 0 Room Setpoint
(Comfort)
Only applicable when using an NTI room sensor
5. 0. 1 Room Setpoint
(Reduced)
Only applicable when using an NTI room sensor
5. 0. 2 Zone 2 Fixed Water
Temp
78
Value
-25 - +25 0
0 - 20 4
68 - 179 °F 179
68 - 1179 °F 95
0 = OFF 0
1 = ON
0 = Standard 1
1 = RT time Programs
Exclusion
2 = Heat demands
forcing
Read only
Read only
0 = OFF
1 = ON (Read only)
Read only
0 = OFF 0
1 = ON
50 - 86 °F 66
32 - 86 °F 61
68 - 179 °F 179
Description
Note
5. 0. 3 Room Setpoint (Holiday/
Anti-frost)
Only applicable when using an NTI room sensor
Changes all zones
5. 0. 5 CH Target temperature
logic
5. 1 AUTOMATIC WINTER MODE
5. 1. 0 Warm weather
shutdown
5. 1. 1 WWSD threshold
5. 1. 2 WWSD Switchoff delay
5. 2 ZONE 2 SETTINGS
5. 2. 1 Auto Temperature
control mode
5. 2. 2 Heating Curve Slope
See graph and description of Parameter 422.
5. 2. 3 Heating Curve Offset
See description of Parameter 4.2.3
5. 2. 4 Room Sensor Influence
Adjusts the influence of room temperature on target
boiler temperature - a higher setting causes a greater
increase to the boiler target temperature as the indoor
temperature drops below room setpoint.
Only applicable when using an optional NTI Room
Sensor and when 5.2.1 = 2 or 4.
5. 2. 5 Max Temperature
5.2.5 sets the allowable boiler operating temperature
range for Zone 2 heating, limiting Automatic Temperature
Control and manual adjustments from the User Menu.
5. 2. 6 Min Temperature
5.2.6 sets the allowable boiler operating temperature
range for Zone 2 heating, limiting Automatic Temperature
Control and manual adjustments from the User Menu.
5. 2. 8 Quick night setback
5. 2. 9 Heat request mode
5. 3 DIAGNOSTICS
5. 3. 0 Room Temperature
Only applicable when using an NTI room sensor
5. 3. 1 Room Temperature
setpoint
Only applicable when using an NTI room sensor
5. 3. 4 Zone 2 Heat Call
5. 3. 8 Zone flow temperature
setpoint
Value
36 - 75 °F 41
1
0 = Max active zone
target
1= Z1,Z2,Z3....etc.
2= Min active zone
taget
0 = OFF 0
1 = ON
50 - 86 °F 68
0 - 300 minutes 2
0 = Fixed Outlet 3
1 =Basic On/Off
2 =Room Temp
3 =Outdoor Temp
4 =Room&Outdoor
0.2 - 3.5 1.3
-25 - +25 0
0 - 20 4
68 - 179 °F 179
68 - 179 °F 95
0 = OFF 0
1 = ON
0 = Standard 1
1 = RT time Programs
Exclusion
2 = Heat demands
forcing
Read only
Read only
0 = OFF
1 = ON (Read only)
Read only
420012001300 - Rev. 04 - 031524
