Part 5 - Venting
B. Approved Materials for Exhaust Vent and Intake Pipe
Item
Pipe and Fittings Approved for Intake
ONLY
Pipe Approved for
Intake OR Exhaust Vent
Pipe Fittings
Pipe Cement
Pipe Primer
Table 12 - Approved Materials for Exhaust Vent and Intake Pipe
DANGER
• The exhaust and intake components installed with this appliance
must be used for near appliance piping BEFORE transitioning to the
approved materials listed above. DO NOT REMOVE these installed
components. Doing so WILL VOID appliance warranty.
• In the US/Canada, PVC vent pipe and fittings SHALL NOT BE USED
within the closet or alcove. Only approved CPVC, Polypropylene, or
Stainless Steel vent pipe and fittings may be used.
• PVC / CPVC pipe and fittings of the same diameter are considered
interchangeable.
• The use of cellular core PVC (ASTM F891), cellular core CPVC, or
Radel® (polyphenolsulfone) in exhaust venting systems is prohibited.
• Covering non-metallic vent pipe and fittings with thermal insulation is
prohibited.
• The boiler's vent and air intake connections are designed to accept 3"
PVC/CPVC and Polypropylene directly. DO NOT insert PVC piping
into the boiler's exhaust connection. When venting with PVC, insert the
factory supplied 5" length of CPVC before transitioning to PVC.
• When installing AL29-4C vent piping, install a PVC-to-stainless
adapter at the boiler vent connection, and at the termination when
using a PVC termination kit. DO NOT mix AL29-4C piping from
different manufacturers unless using adapters specifically designed
for the purpose by the manufacturer.
• DO NOT mix components from different venting systems without
proper adapters. The vent system could fail, causing leakage of
flue products into the living space. Use only the approved pipe and
fitting materials, and primer and cement specifically designed for the
material used, as listed in the above table.
• A double wall vent or insulated material may be used when using
stainless steel vent material in a freezing climate.
• *ABS may be used for air intake applications ONLY.
• Contact the venting material manufacturer if there is any question
about the applicability of the proposed venting material.
Failure to follow these directions will result in substantial property
damage, severe personal injury, or death.
34
Material
ABS*
PVC Schedule 40/80
PVC-DWV Schedule 40/80
CPVC Schedule 40/80
Polypropylene
Stainless Steel AL29-4C
PVC Schedule 40 UL-1738, ANSI/ASTM D2466 or D2665
PVC Schedule 80 UL-1738, ANSI/ASTM D2467 or D2665
CPVC Schedule 40
CPVC Schedule 80
ABS*
PVC
CPVC
PVC / CPVC
CAUTION
High heat sources (generating heat 100°F / 37°C or greater,
such as boiler flue pipes, space heaters, etc.) may damage plastic
components of the boiler as well as plastic vent pipe materials. Such
damages ARE NOT covered by warranty. It is recommended to keep
a minimum clearance of 8" from high heat sources. Observe heat
source manufacturer instructions, as well as local, state, provincial,
and national codes, laws, regulations, and ordinances when installing
this boiler and related components near high heat sources.
NOTE: The use of double-wall vent or insulated material for the
combustion air intake pipe is recommended in cold climates to
prevent the condensation of airborne moisture in the incoming
combustion air.
You must not use "B" vent in an exhaust application. "B" vent is for
intake applications ONLY. Using "B" vent in an exhaust application
will result in serious injury or death.
1. Installations must be made with a vent pipe system certified to
ULC-S636.
2. The first three (3) feet of vent pipe from the boiler flue outlet must
be readily accessible for visual inspection.
3. The components of the certified vent system must not be
interchanged with other vent systems or unlisted pipe / fittings.
Standards for Installation In:
United States
ANSI/ASTM D2661
UL-1738 or ANSI/ASTM D1785
UL-1738 or ANSI/ASTM D2665
UL-1738 or ANSI/ASTM F441
UL-1738 or ULC-S636
Certified for Category IV and Direct Vent Appliance Venting
UL-1738 or ANSI/ASTM F438
UL-1738 or ANSI/ASTM F439
ANSI/ASTM D2235
ANSI/ASTM D2564
ANSI/ASTM F493
ASTM F656
DANGER
C. Additional Requirements for Installation
in Canada
Canada
ANSI/ASTM D2661
UL-1738 or ULC-S636
UL-1738 or ULC-S636
ANSI/ASTM D2235
ULC-S636 Approved Cements
and Primers
