Ransburg RANS FLEX 80544 RXQ Service Manual

Applicators
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
AH-15-03.1
AUGUST - 2016
MODEL: 80544 AND 80565 RXQ & RFXQ
IMPORTANT: Before using this equipment, carefully read SAFETY
PRECAUTIONS, starting on page 1, and all instructions in this manual.
Keep this Service Manual for future reference.
®
APPLICATORS
By Ransburg
Service Manual Price:
$50.00 (U.S.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RANS FLEX 80544 RXQ and is the answer not in the manual?

Questions and answers

Related Manuals for Ransburg RANS FLEX 80544 RXQ

Summary of Contents for Ransburg RANS FLEX 80544 RXQ

  • Page 1 AH-15-03.1 AUGUST - 2016 ® APPLICATORS By Ransburg MODEL: 80544 AND 80565 RXQ & RFXQ IMPORTANT: Before using this equipment, carefully read SAFETY PRECAUTIONS, starting on page 1, and all instructions in this manual. Keep this Service Manual for future reference.
  • Page 2 Ransflex Applicators - REVISIONS NOTE: This manual has been changed from revision AH-15-03 to revision AH-15-03.1. Reasons for this change are noted under “Manual Change Summary” on page 62 of this manual. AH-15-03.1...

  • Page 3: Table Of Contents

    Ransflex Applicators - CONTENTS CONTENTS PAGE SAFETY: Safety Precautions ..........................1 Hazards / Safegaurds ........................... 2 ATEX/FM: 6-13 European Atex Directive ........................6 European Atex Labels .......................... 7 FM Configuration Drawings ........................8 FM Configuration Drawings ........................11 INTRODUCTION: 14-18 General Description ..........................14 Ransflex New Features...

  • Page 4: Safety

    Before operating, maintaining or servicing any Ransburg W A R N I N G electrostatic coating system, read and understand all of the technical and safety literature for your Ransburg The user MUST read and be familiar with the †...

  • Page 5: Hazards / Safegaurds

    Ransflex Applicators - SAFETY SAFEGUARDS HAZARD AREA Tells how to avoid the hazard. Tells where hazards Tells what the hazard is. may occur. Spray Area Fire Hazard Fire extinguishing equipment must be present in the spray area and tested periodically. Improper or inadequate operation and maintenance Spray areas must be kept clean to prevent the...
  • Page 6 Ransflex Applicators - SAFETY SAFEGUARDS HAZARD AREA Tells how to avoid the hazard. Tells where hazards Tells what the hazard is. may occur. Explosion Hazard Spray Area Electrostatic arcing must be prevented. Safe Improper or inadequate oper- sparking distance must be maintained between ation and maintenance proce- the parts being coated and the applicator.
  • Page 7 Ransflex Applicators - SAFETY SAFEGUARDS HAZARD AREA Tells how to avoid the hazard. Tells where hazards Tells what the hazard is. may occur. Spray Area / Electrical Discharge High Voltage Parts being sprayed and operators in the spray There is a high voltage device Equipment area must be properly grounded.
  • Page 8 Ransflex Applicators - SAFETY SAFEGUARDS HAZARD AREA Tells how to avoid the hazard. Tells where hazards Tells what the hazard is. may occur. Electrical Discharge Electrical Unless specifically approved for use in hazard- Equipment ous locations, the power supply, control cabi- High voltage equipment is net, and all other electrical equipment must be utilized in the process.

  • Page 9: Atex/Fm

    Ransflex Applicators - ATEX EUROPEAN ATEX DIRECTIVE 94/9/EC, ANNEX II, 1.0.6 The following instructions apply to equipment covered of the user to take suitable precautions that prevent by certificate number Sira 14ATEX5343: it from being adversely affected, thus ensuring that the type of protection provided by the equipment The equipment may be used with flammable is not compromised.

  • Page 10: European Atex Labels

    80559 Special conditions for safe use: The Ransflex 80544/80565 Applicators shall only be used with associated Ransburg 79727-XX Air Hose Assembly. It is the end users responsibility to insure the air hose is properly grounded to true earth ground. Label Resistance of this air hose assembly must be .5 MW...

  • Page 11: Fm Configuration Drawings

    Ransflex Applicators - ATEX RANSFLEX RXQ - SOLVENT BASE 80544 - ABCDEF Base Optional Model No. Designations (Ordering Information Only) CONFIGURATION DWG. 80559 REV. A Return To Contents AH-15-03.1...
  • Page 12 Ransflex Applicators - ATEX “T” (Pressure Reducer) “R” (Air Cap) “S” (Fluid Nozzle) ATOMIZATION - TABLE OF “A” DASHES “R” “S” “T” “A” Dash No. “A” Description V SERIES 1.2mm 80265-00 80264-12 79809-00 V SERIES 1.4mm 80265-00 80264-14 79809-00 V SERIES 1.8mm 80265-00 80264-18 79809-00...
  • Page 13 Ransflex Applicators - ATEX “W” 80269-45 79879-01 FLUID INLET - TABLE OF “D” DASHES “D” Dash No. “D” Description “W” STD FLUID INLET TUBE 80269-45 COILED FLUID TUBE, COVER 79879-03, 79890-00 FLUID HOSE - TABLE OF “E” DASHES “E” Description “X”...

  • Page 14: Fm Configuration Drawings

    Ransflex Applicators - ATEX RANSFLEX RFXQ - SOLVENT BASE 80565 - ABCDEF Base Optional Model No. Designations (Ordering Information Only) CONFIGURATION DWG. 80561 REV. A Return To Contents AH-15-03.1...
  • Page 15 Ransflex Applicators - ATEX “T” (Pressure Reducer) “R” (Air Cap) “S” (Fluid Nozzle) ATOMIZATION - TABLE OF “A” DASHES “R” “S” “T” “A” Dash No. “A” Description V SERIES 1.2mm 80265-00 80264-12 79809-00 V SERIES 1.4mm 80265-00 80264-14 79809-00 V SERIES 1.8mm 80265-00 80264-18 79809-00...
  • Page 16 Ransflex Applicators - ATEX “W” 80269-45 79879-01 FLUID INLET - TABLE OF “D” DASHES “D” Dash No. “D” Description “W” STD FLUID INLET TUBE 80269-45 COILED FLUID INLET TUBE 79879-01 FLUID HOSE - TABLE OF “E” DASHES “E” Description “W” “E”...

  • Page 17: Introduction

    Ransflex Applicators - INTRODUCTION INTRODUCTION GENERAL DESCRIPTION RANSFLEX NEW FEATURES The Ransflex is an air atomizing applicator powered • Light weight and easy to maneuver. only by a pressurized air source. Pressurized air creates • Ergonomic handle design to reduce rotation of a turbine generator that powers a cascade.

  • Page 18: Specifications

    Ransflex Applicators - INTRODUCTION 80544 RANSFLEX SOLVENTBORNE SPECIFICATIONS Environmental/Physical Applicator Length: 254mm (10-inches) Weight: (Without Hose) 600 grams (21.3 oz.) Hose 79727-XX Lengths (Std): 10m, 15m, 20m, and 30m Electrical Operating Voltage: 45kV DC (-) maximum Current Output: 140 microamperes maximum Paint Resistance:* .1 MW to ∞...

  • Page 19: Specifications

    Ransflex Applicators - INTRODUCTION 80565 RANSFLEX SOLVENTBORNE SPECIFICATIONS Environmental/Physical Applicator Length: 273mm (10.75-inches) Weight: (Without Hose) 620 grams (22 oz.) Hose 79727-XX Lengths (Std): 10m, 15m, 20m, and 30m Electrical Operating Voltage: 65kV DC (-) maximum Current Output: 120 microamperes maximum Paint Resistance:* .1 MW to ∞...

  • Page 20: Ransflex Solventborne Electrostatic Spray Applicator

    Ransflex Applicators - INTRODUCTION Figure 1: Ransflex Solventborne Electrostatic Spray Applicator 80544 / 80565 RANSFLEX SOLVENTBORNE ELECTROSTATIC SPRAY APPLICATOR 80544 / 80565 Description Description Fluid Hose Needle/Electrode Barrel Voltage On/Off Switch Trigger Handle Compensation Valve Fan Adjustment (Not Active) Fluid Adjustment Air Cap / Fluid Nozzle Quick Fan Control Button Air Hose...

  • Page 21: Typical Solvenborne Installation

    Ransflex Applicators - INTRODUCTION Figure 2: Ransflex Typical Solventborne Installation RANSFLEX SOLVENTBORNE TYPICAL INSTALLATION Description Description Ransflex 80544 / 80565 Fluid Supply (Grounded) Ball Valve Fluid Regulator Air Regulator with Pressure Gauge Air Hose (79727-XX) Air / Water Separator Air Hose Ground Wire Main Air Supply Line Fluid Line Return To Contents...

  • Page 22: Installation

    (RH) of the air should be 5%. 1. Operator must make skin contact with handle of 2. Ransburg recommends that a fluid filter be installed applicator. If gloves are required use either gloves at the output of the fluid supply (pressure pot, with palm and finger cut out or conductive gloves.

  • Page 23: Installation

    Ransflex Applicators - INSTALLATION 2. All objects inside spray area must be grounded - 2. Turn off power. reference EN 50 176 and/or NFPA-33. Resistance to earth ground must be less than 1 meg Ohm. 3. Flammable liquids must be contained in approved metalic grounded containers.

  • Page 24: Operation

    Ransflex Applicators - OPERATION OPERATION APPLICATOR OPERATION 1. Set fluid pressure using flow regulator. 6.9 bar (100psig) Max 4. Release trigger stop material flow. 1 - Fluid Supply 2 - Flow Regulator 5. Re-connect air supply. 2. Disconnect the air to the applicator. OR...
  • Page 25 Ransflex Applicators - OPERATION C-31 AIR CAP 80231-00 Static Pressure at Wall Dynamic Pressure at Wall 79727-XX Length psig psig 30 m 20 m 15 m 10 m T-40 AIR CAP 80240-00 Static Pressure at Wall Dynamic Pressure at Wall 79727-XX Length psig psig...

  • Page 26: Flushing / Color Change Procedure

    Ransflex Applicators - OPERATION (Horns Vertical) 13. Fan pattern full open. 16. Adjust compensation valve with small driver. NOTE † The compensation valve adjustment is used to adjust fan and atomization pressure at the same time when the pressure to run the turbine is higher than the atomization fan pressure desired.

  • Page 27: Fluid Nozzle / Air Cap

    Ransflex. 2. Disconnect air to applicator. CAUTION † Nozzles from previous Ransburg design are not compatable with the Ransflex design. Use of these nozzles could cause equipment malfunction and possible damage.

  • Page 28: Nozzle Selection

    Ransflex Applicators - OPERATION To identify the nozzle, each is engraved with the air cap it must be paired up with. NOZZLE SELECTION 80265-00 / 80264-XX Nozzle Part Number For Use With Air Cap P/N Color Nozzle Opening 80264-07 80265-00 Black 0.7 mm 80264-10...
  • Page 29 Ransflex Applicators - OPERATION 80231-00 / 80230-XX C SERIES Nozzle Part Number For Use With Air Cap P/N Color Nozzle Opening 80230-12 80231-00 1.2 mm 80230-14 80231-00 Grey 1.4 mm 80230-18 80231-00 Green 1.8 mm 80240-00 / 80239-XX T SERIES Nozzle Part Number For Use With Air Cap P/N Color...

  • Page 30: Air Cap / Nozzle Performance

    Ransflex Applicators - OPERATION AIR CAP / NOZZLE PERFORMANCE V-65 - 80265-00 Pattern Orfice ID *Fluid Delivery Pattern Length Width Nozzle Spray Type Pressure Reducer (mm/in) (ml/min) (mm/in) (mm/in) 80264-12 1.2/.047 Air Spray 355/14.0 76/3.0 79809-00 (Yellow) 80264-14 1.4/.055 Air Spray 343/13.5 76/3.0 79809-00 (Yellow)

  • Page 31: Maintenance

    (i.e. high flash Naphtha). If there are any questions as to what solvents are † DO NOT operate a faulty applicator! best for cleaning , contact your local Ransburg distributor and/or your paint supplier. † When using cleaning solvent, standard health and safety precautions should apply.

  • Page 32: Routine Schedule

    Ransflex Applicators - MAINTENANCE CAUTION CAUTION † Nozzles from previous Ransburg design † NEVER remove the fluid nozzle assembly are not compatable with the Ransflex design. while paint is in the applicator or paint may enter Use of these nozzles could cause equipment into the air passages.
  • Page 33 Ransflex Applicators - MAINTENANCE • Check that atomizer assembly is clean and undamaged. NOTE † Standard electrode is "snap back" spray wire electrode. • Straighten the applicator electrode if necessary. • Clean the fluid filter, if used. Bi-Yearly • Check air hose resistance. If resistance is greater than .5 MW the hose should be replaced.
  • Page 34 Ransflex Applicators - MAINTENANCE 2. Clean and replace as necessary. 3. Install in reverse order. 3. Install fluid nozzle using 80353-00 wrench. Tighten till nozzle seats on O-ring and then 1/8 additional turn. Fluid Nozzle Removal W A R N I N G †...
  • Page 35 Ransflex Applicators - MAINTENANCE 2. Remove fluid tube. 2. Carefully disconnect harness by pulling connector on both sides by hand and rocking it side to side to remove. 3. Pull barrel away. 3. Replace cascade as necessary. 4. Apply LSCH 0009 grease to end of cascade. Remove/Replace Cascade 5.
  • Page 36 Ransflex Applicators - MAINTENANCE Packing Removal/Replace 5. Remove all parts, clean with non-polar solvent. Inspect for any discolored areas. Replace parts as required. 1. Remove barrel from handle. 2. Use 80353 wrench to remove nut. 6. Prior to installation apply dielectric grease inside packing tube, completely full.
  • Page 37 Ransflex Applicators - MAINTENANCE Re-Install Needle Shaft Into Barrel 10. Install Bellville washers in sequence shown. 1. Install needle shaft into barrel with die-electric grease. 11. Install rear nut. Install jam nuts finger tight. 2. Tighten packing using wrench. Pull back and forth on the needle shaft till a slight amount of drag is felt.
  • Page 38 Ransflex Applicators - MAINTENANCE 2. Tighten barrel screws. 2. Remove fan air cartridge with 10mm wrench. 3. Re-install fluid tube. 3. Remove rear cover and cartridge with 15mm wrench. 4. Re-install trigger. 4. Disconnect motor connector from handle wire harness connector. Motor Removal 1.
  • Page 39 Ransflex Applicators - MAINTENANCE 2. Remove screw and retainer. NOTE † Block must be pulled out with fingers rocking the part side to side while pulling. NOTE † Only remove fluid valve cartridge if parts are being changed. 5. Remove fluid valve cartridge O-ring. Remove motor assembly by pulling out on 3 arms, pull motor out.
  • Page 40 Ransflex Applicators - MAINTENANCE 2. Align motor slots with 3 tab arms. NOTE NOTE † Only one way to position † There is only one way to install the motor. 5. Install light pipe. 6. Install fluid valve cartridge. 3. Install cartridge then o-ring (if removed). 7.
  • Page 41 Ransflex Applicators - MAINTENANCE Air Valve Remove/Replace 8. Push rear cover assembly into handle and tighten cartridge. 1. Remove trigger. 2. Remove rear cover assembly. 3. Remove air valve and spring. 9. Install fan air valve cartridge. 4. Remove air valve packing nut and packing. 10.
  • Page 42 Ransflex Applicators - MAINTENANCE Fluid Bracket Removal 4. O-ring, gasket and bracket. 1. Loosen fluid nut. 2. Remove air fitting. 5. Install air fitting. 3. Remove bracket, gasket and o-ring. 6. Tighten fluid nut. Return To Contents AH-15-03.1...
  • Page 43 Ransflex Applicators - MAINTENANCE Remove Quick Fan Valve 3. Remove lower fluid nut. 1. Remove fan valve. Gun Wrench Functions 4. Air fiting. 80353-00 1. Adjust packings. 5. Remove rear cartridge. 2. Remove nozzles For V Series For C & T Series Return To Contents AH-15-03.1...

  • Page 44: Troubleshooting Guide

    Ransflex Applicators - MAINTENANCE TROUBLESHOOTING GUIDE General Problem Possible Cause Solution ELECTRICAL On-Off lever in wrong position Ensure the On/Off lever is in the On position. No kV Low pressure Ensure 2.8 bar (40 psig) at the applicator handle with applicator triggered. No ground connection Ensure the air hose is properly grounded to the earth ground.

  • Page 45: Parts Identification

    Ransflex Applicators - PARTS IDENTIFICATION PARTS IDENTIFICATION RANSFLEX RXQ - SOLVENT BASE 80544 - ABCDEF Base Optional Model No. Designations ATOMIZATION - TABLE OF “A” DASHES “1” “2” “3” / Color “A” Dash No. “A” Description V SERIES 1.2mm 80265-00 80264-12 79809-00 / YELLOW V SERIES 1.4mm...
  • Page 46 Ransflex Applicators - PARTS IDENTIFICATION FLUID CONTROL - TABLE OF “B” DASHES “B” Dash No. “B” Description “4” ADJUSTABLE FLUID 80262-00 NON-ADJUSTABLE FLUID 80262-01 TRIGGER - TABLE OF “C” DASHES “C” Dash No. “C” Description “5” 2 FINGER TRIGGER 80211-00 4 FINGER TRIGGER 80386-00* FLUID INLET - TABLE OF “D”...

  • Page 47: Ransflex Rfxq Solvent Base

    Ransflex Applicators - PARTS IDENTIFICATION RANSFLEX RFXQ - SOLVENT BASE 80565 - ABCDEF Base Optional Model No. Designations ATOMIZATION - TABLE OF “A” DASHES “1” “2” “3” / Color “A” Dash No. “A” Description V SERIES 1.2mm 80265-00 80264-12 79809-00 / YELLOW V SERIES 1.4mm 80265-00 80264-14...
  • Page 48 Ransflex Applicators - PARTS IDENTIFICATION FLUID CONTROL - TABLE OF “B” DASHES “B” Dash No. “B” Description “4” ADJUSTABLE FLUID 80262-00 NON-ADJUSTABLE FLUID 80262-01 TRIGGER - TABLE OF “C” DASHES “C” Dash No. “C” Description “5” 2 FINGER TRIGGER 80211-00 4 FINGER TRIGGER 80386-00* FLUID INLET - TABLE OF “D”...
  • Page 49 Ransflex Applicators - PARTS IDENTIFICATION Retaining Ring 80377-00 RETAINING RING 80377-00 Qty. Item No. Part No. Description 80377-00 NUT, RETAINING & O-RING ASSEMBLY (CONTAINS ALL PARTS) LSOR0005-17 O-RING, ENCAPSULATED Return To Contents AH-15-03.1...

  • Page 50: Items For Rxq (45Kv) Unit

    Ransflex Applicators - PARTS IDENTIFICATION ITEMS FOR RXQ (45KV) UNIT RXQ 45kV BARREL Item No. Part No. Description Qty. 80376-00 ASSEMBLY, BARREL & O-RING 80263-45 ASSEMBLY, NEEDLE SHAFT 80242-00 NUT, REAR JAM 80243-00 NUT, FRONT JAM 80258-00 SPRING, FLUID RETURN 80250-45 ASSEMBLY, CASCADE RXQ (45 kV) Barrel and O-Ring P/N 80376-00...
  • Page 51 Ransflex Applicators - PARTS IDENTIFICATION Needle Shaft Assembly 80263-45 RXQ 45kV NEEDLE SHAFT Qty. Item No. Part No. Description 70430-01 ASSEMBLY ELECTRODE, HIGH WEAR 74653-00 ADAPTER, MALE 14323-00 SEAL, CHEVRON, 3/8 DIA. 14323-00-K4 SEAL, CHEVRON (KIT OF 4) 18821-00 ADAPTER-FEMALE-CHEVRON 80257-45 TUBE, PACKING 80225-45...

  • Page 52: Items For Rxq (65Kv) Unit

    Ransflex Applicators - PARTS IDENTIFICATION ITEMS FOR RFXQ (65KV) UNIT RFXQ 65kV BARREL Qty. Item No. Part No. Description 80379-00 ASSEMBLY, BARREL & O-RING 80263-65 ASSEMBLY, NEEDLE SHAFT 80242-00 NUT, REAR JAM 80243-00 NUT, FRONT JAM 80258-00 SPRING, FLUID RETURN 80250-65 ASSEMBLY, CASCADE RFXQ (65 kV) Barrel and O-Ring P/N 80379-00...
  • Page 53 Ransflex Applicators - PARTS IDENTIFICATION Needle Shaft Assembly 80263-65 RFXQ 65kV NEEDLE SHAFT Qty. Item No. Part No. Description 70430-01 ASSEMBLY, ELECTRODE, HIGH WEAR 74653-00 ADAPTER, MALE 14323-00 SEAL, CHEVRON, 3/8 DIA. 14323-00-K4 SEAL, CHEVRON (KIT OF 4) 18821-00 ADAPTER-FEMALE-CHEVRON 80257-65 TUBE, PACKING 80225-65...

  • Page 54: Components For All Models

    Ransflex Applicators - PARTS IDENTIFICATION HANDLE COMPONENTS FOR ALL MODELS HANDLE COMPONENTS Description Qty. Item No. Part No. 80538-00 INCLUDES HANDLE (80305-00) AND REAR COVER WITH MOTOR (80378-00) ASSEMBLY (ADJUSTABLE FLUID CONTROL) 80538-01 INCLUDES HANDLE (80305-01) AND REAR COVER WITH MOTOR (80378-00) ASSEMBLY (NON-ADJUSTABLE FLUID CONTROL) 80245-00 GASKET, BARREL...
  • Page 55 Ransflex Applicators - PARTS IDENTIFICATION Handle with Rear Cover with Motor 80538-00/01 HANDLE WITH REAR COVER W/MOTOR 80538-00/01 Qty. Item No. Part No. Description 80539-00 ASSEMBLY, HANDLE 80244-00 ASSEMBLY, VALVE, AIR 80533-00 SPRING, AIR VALVE 80262-00 ASSEMBLY, VALVE, ADJUSTABLE FLUID CONTROL 80262-01 ASSEMBLY, VALVE, NON-ADJUSTABLE FLUID CONTROL 80555-00...
  • Page 56 Ransflex Applicators - PARTS IDENTIFICATION Handle Assembly 80305 HANDLE ASSEMBLY 80539 Description Qty. Item No. Part No. 80539-00 ASSEMBLY, HANDLE INCLUDES ALL PARTS BELOW, MOTOR CONTROL BOARD AND HARNESSES 80274-00 SCREW, BARREL-HANDLE 80229-00 NUT, RETAINING, AIR VALVE 10051-05 CUP SEAL, SPRING LOADED Rear Cartridge Assembly 80262-00 (Adjustable Fluid Control) REAR CARTRIDGE ASSEMBLY 80262-00 Qty.
  • Page 57 Ransflex Applicators - PARTS IDENTIFICATION Rear Cartridge Assembly 80262-01 (Non-Adjustable Fluid Control) REAR CARTRIDGE ASSEMBLY 80262-01 Qty. Item No. Part No. Description 80262-01 ASSEMBLY, FLUID CARTRIDGE (NON-ADJUSTABLE) 79001-08 O-RING, SOLVENT PROOF 80555-00 Fan Air Cartridge 80555-00 FAN AIR CARTRIDGE Description Qty.
  • Page 58 Ransflex Applicators - PARTS IDENTIFICATION 80378-00 Rear Cover with Motor Assembly 80378-00 REAR COVER WITH MOTOR ASSEMBLY Item No. Part No. Description Qty. 80378-00 COVER, REAR ASSEMBLY (INCLUDES ALL PARTS BELOW) 80213-00 PIPE, LIGHT 80255-00 ASSEMBLY, MOTOR 79775-00 BLOCK, PORTING 7554-61 O-RING, SOLVENT RESISTANT 80275-00...
  • Page 59 Ransflex Applicators - PARTS IDENTIFICATION 80255-00 Motor Assembly 80255-00 MOTOR ASSEMBLY Qty. Item No. Part No. Description 80255-00 ASSEMBLY, MOTOR (INCLUDES ALL PARTS BELOW) 80217-00 COVER SUPPORT, MOTOR 79796-00 SCREW, MOTOR Return To Contents AH-15-03.1...
  • Page 60 Ransflex Applicators - PARTS IDENTIFICATION 80254-00 Rear Cover Assembly 80254-00 REAR COVER ASSEMBLY Qty. Item No. Part No. Description 80254-00 COVER, REAR (CONTAINS PARTS BELOW) 80274-00 M4 X .7 SHCS Return To Contents AH-15-03.1...

  • Page 61: Accessories

    Ransflex Applicators - PARTS IDENTIFICATION ACCESSORIES INCLUDED WITH RX OR RFX 79862-02 3mm Hex Driver 80353-00 Gun Wrench 80395-00 LSCH 0009 Grease ACCESSORIES Part # Description 27141-081 Wrap, Spiral 59972-00 Pack of 4 LSCH0009 Grease 76102-00 Applicator Mounting Bracket 76652-01 HV Probe 76652-02 Spayability and SCI Paint Test Meter...

  • Page 62: Spare Parts Kits

    Ransflex Applicators - PARTS IDENTIFICATION SPARE PARTS KITS Description Part # 79001-07-K3 Fluid inlet o-ring of barrels 80264-XX-K3 V Series nozzles in kits of 3 (XX = 12, 14 or 18) 80464-XX-K3 V Series high wear nozzles in kits of 3 (XX = 14, 18) 80230-XX-K3 C Series nozzles in kits of 3 (XX = 12, 14 or 18) 80239-XX-K3...

  • Page 63: Recommended Spare Parts

    Ransflex Applicators - PARTS IDENTIFICATION RANSFLEX RECOMMENDED SPARE PARTS (Quantities Per Applicator) Part # Description 80264-XX Nozzle, Fluid V Series (See page 42) 80264-XX-K3 Nozzle, Fluid V Series (See page 42) (Kit of 3) 80230-XX Nozzle, Fluid C Series (See page 42) 80230-XX-K3 Nozzle, Fluid C Series (See page 42) (Kit of 3) 80239-XX...

  • Page 64: Warranty Policies

    EXCLUSIONS: under normal operating conditions. Normal wear items are excluded. If, in Ransburg’s opinion the warranty item in question, or other items damaged by this part was improperly THE USE OF OTHER THAN RANSBURG APPROVED installed, operated or maintained, Ransburg will assume PARTS, VOID ALL WARRANTIES.
  • Page 65 Ransflex Applicators - MANUAL CHANGES MANUAL CHANGE SUMMARY Supersedes Service Manual AH-15-03 with the following changes: 1. Update version number — All Pages. 2. Update item 2 in Fluid Inlet Table — Page 10. 3. Update item 2 in Fluid Inlet Table — Page 45. 4.
  • Page 66 Ransburg Manufacturing 1910 North Wayne Street Angola, Indiana 46703-9100 Telephone: 260-665-8800 Fax: 260-665-8516 Technical Service — Assistance 320 Phillips Ave. Toledo, Ohio 43612-1493 Telephone (toll free): 800-233-3366 Fax: 419-470-2233 Technical Support Representative will direct you to the appropriate telephone number for ordering Spare Parts.

This manual is also suitable for:

Rans flex 80544 rfxqRans flex 80565 rxqRans flex 80565 rfxq
